Features
Stay Focused and In Control All Day
When long days demand focus and precision, 8 Series tractors deliver an elevated operator experience with improved visibility, intuitive controls, and a refined cab environment. Everything is designed to reduce fatigue and simplify operation—so you can stay in control, maintain accuracy, and keep performance consistent from the first pass to the last.
Put Power Down Efficiently Across Every Pass
Getting the most out of every acre means turning power into productivity. 8 Series tractors combine strong horsepower with traction and efficiency technologies that help reduce slip, maintain consistent speeds, and protect soil conditions. The result is more work done per hour, better fuel efficiency, and dependable performance across varying field conditions.
Connect Your Tractor to the Rest of Your Operation
Productivity doesn’t stop at the cab - it extends across your entire operation. With integrated precision technology and connectivity through John Deere Operations Center, 8 Series tractors help you document work, monitor performance, and make informed decisions. Turn every pass into insight and plan your next move with greater confidence.
Specifications
Rear Power Take-Off (PTO)
| PTO Category | Standard: 45 mm (1.75 in.) 20-spline, 1,000 rpm; Optional: 45 mm (1.75 in.), 20-spline, 1000/1000E rpm |
| Rated PTO Power | 310 hp |
| Rated PTO Power | 231 kW |
| Rated PTO Power | 314 PS |
| Economy PTO Speeds | 1000E rpm |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1810 / 1995 |
| Engine rpm at Rated PTO Speeds (540E/1000/1.000E) | -- / 1995 / 1590 |
| Engagement Method | Electrohydraulic with adjustable modulation |
| Number of Splines | 20 |
Hydraulics
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing |
| Pump Rated Output | Standard: 85-cc pump: 227.1 L/min (60 gpm); Optional: 85-cc plus 35-cc dual pump: 318 L/min (84 gpm) |
| Number of Rear Selective Control Valves (SCVs) | Standard: 1.3-cm (1/2-in.) ISO couplers: 4; Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available |
| Available Flow at a Single Rear SCV | 1.3-cm (1/2-in.) couplers: 132 L/min (35 gpm) |
| Available Flow at Front SCVs | 25 gpm |
| Available Flow at Front SCVs | 25 L/min |
| SCV Control | Electronic |
Engine
| Engine Make | John Deere |
| Engine Model | JD9 |
| Engine Family | VJDXL09.0333 |
| Emissions Certifications | Final Tier 4 |
| Displacement | 549 cu in. |
| Displacement | 9 L |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series; air-to-air aftercooling and cooled exhaust gas recirculation |
| Number of Cylinders | 6 |
| Cylinder Liners | Wet-sleeve |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR) |
| Rated Engine Speed | 2100 rpm |
| Rated Engine Power | 365 hp |
| Rated Engine Power | 272 kW |
| Rated Engine Power | 370 PS |
| Engine Torque at Rated Speed | 1277 lb-ft |
| Engine Torque at Rated Speed | 1732 Nm |
| Maximum Engine Power | 401 hp |
| Maximum Engine Power | 299 kW |
| Maximum Engine Power | 407 PS |
| Maximum Engine Torque | At 1600 rpm: 1732 Nm / 1277 lb-ft |
| Power Bulge | 10 % |
| Fuel Type | Diesel |
| Alternative Fuel Type | B30 Diesel Compatible |
| Torque Rise | 40 % |
Dimensions & Weights
| Wheelbase | 127.36 in. |
| Wheelbase | 3235 mm |
| Base Machine Weight | 43300 lb. |
| Base Machine Weight | 19600 kg |
| Maximum Ballast Level | 44100 lb. |
| Maximum Ballast Level | 20000 kg |
| Maximum Permissible Weight | 53000 lb. |
| Maximum Permissible Weight | 24000 kg |
Electrical System
| Battery Voltage | 12 V |
| Battery Cold Cranking Amps | 1900 CCA |
| Alternator Capacity | 200 amp / 330 amp optional |
| Working Lights | 18 halogen / 20–24 LED optional |
| Driving Lights | Halogen (65 W) / LED optional |
Rear Hitch
| Rear Hitch Category (SAE Designation) | Category 4N/3 |
| Maximum Lift Capacity at 610-mm Behind Hitch Point | 9072 kg / 20,000 lb |
| Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point | 15000 / 20000 lb (6803 / 9072 kg) |
| Sensing Type | Electrohydraulic |
Operator Station
| Seat Suspension | Air suspension |
| Degree of Seat Swivel, Left Hand | 25 degree (angle) |
| Degree of Seat Swivel, Right Hand | 40 degree (angle) |
| Cab Suspension | Four-post cab suspension |
| Instructional Seat | Standard |
| Primary Display | G5ᴾˡᵘˢ 12.8 in (325 mm) |
| Radio | AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna |
| Inner Cab Volume | 114 cu ft |
| Inner Cab Volume | 3.24 m³ |
| Cab Glass Area | 70.18 sq ft |
| Cab Glass Area | 6.52 m² |
Transmission
| Transmission Type | Standard: e23™ PowerShift™ 40K, 40 km/h (24.9 mph); Optional: John Deere eAutoPowr™ EVT™ 40K, 0.05-42 km/h (0.03-26 mph) |
| Maximum Speed Forward | 42 km/h (26 mph) |
| Minimum Speed Forward | 0.05 km/h (0.03 mph) |
Capacities
| Fuel Tank Capacity | 244 (e23), 219 (EVT) gal. |
| Fuel Tank Capacity | 924 (e23), 829 (EVT) L |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 9.8 gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 37.2 L |
| Cooling System Capacity | 11.2 (e23), 12.4 (EVT) gal. |
| Cooling System Capacity | 42.3 (e23), 46.9 (EVT) L |
| Transmission - Hydraulic System | 66.1 (76/80 in. tread), 68.8 (88/120 in. tread) gal. |
| Transmission - Hydraulic System | 250 (76/80 in. tread), 260.6 (88/120 in. tread) L |
| Crankcase Oil Volume | 7 gal. |
| Crankcase Oil Volume | 26.6 L |
Drawbar
| Drawbar Category | Standard: Category 4 with heavy-duty support; Optional: Category 4 |
| Maximum Vertical Load | Standard: 4,990 kg (11,000 lb); Optional: 2,245 kg (4,950 lb) |
Technology Integration
| Guidance | Integrated AutoTrac™; Autonomy Ready (available in select regions) |
| Connectivity | JDLink™ hardware standard, activations, and Ethernet harnesses (availability dependent upon destination) |
| Remote Diagnostics | JDLink hardware standard |
Additional Information
| Country of Manufacture | USA |
| Date Collected | 4/3/2025 12:00:00 AM |
Machine Configuration
| Wheel or Track Configuration | 4-Track |
| Drive Type | 4WD |
Tracks
| Track Drive Type | Camso® 4500 General Ag Series |
| Track Tread Spacing | 1930.4 mm (76 in.), 2032 mm (80 in.), 2235.2 mm (88 in.), 3048 mm (120 in.) |
| Track Width | 419 mm (16.5 in.), 457 mm (18 in.), 609 mm (24 in.), 762 mm (30 in.) |
| Number Of Mid Rollers | Front: Two, Rear: Three |
Rear Axle
| Rear Axle Type | Flange |
| Rear Differential Lock | Full-locking electrohydraulic |
| Final Drive | Inboard planetary |
Front Axle
| Front Axle Type | 1700 Series MFWD |
| Front Axle Differential Lock | Full-locking electrohydraulic (actuated at same time as rear diff-lock) |
Steering & Brakes
| Steering Type | Hydraulic power-steering with electric pump back-up |
