Features
Stay Focused and In Control All Day
When long days demand focus and precision, 8 Series tractors deliver an elevated operator experience with improved visibility, intuitive controls, and a refined cab environment. Everything is designed to reduce fatigue and simplify operation—so you can stay in control, maintain accuracy, and keep performance consistent from the first pass to the last.
Put Power Down Efficiently Across Every Pass
Getting the most out of every acre means turning power into productivity. 8 Series tractors combine strong horsepower with traction and efficiency technologies that help reduce slip, maintain consistent speeds, and protect soil conditions. The result is more work done per hour, better fuel efficiency, and dependable performance across varying field conditions.
Connect Your Tractor to the Rest of Your Operation
Productivity doesn’t stop at the cab - it extends across your entire operation. With integrated precision technology and connectivity through John Deere Operations Center, 8 Series tractors help you document work, monitor performance, and make informed decisions. Turn every pass into insight and plan your next move with greater confidence.
Specifications
Rear Power Take-Off (PTO)
| PTO Category | 45 mm (1.75 in.) 20-spline, 1000 rpm |
| Rated PTO Power | 257 hp |
| Rated PTO Power | 191 kW |
| Rated PTO Power | 260 PS |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1,000 PTO rpm: 2,000 rpm |
| Engine rpm at Rated PTO Speeds (1000/1000E/1.300) | 1,000 PTO rpm at 2,000 engine rpm |
| Engagement Method | Electrohydraulic with adjustable modulation |
| Number of Splines | 20 |
Dimensions & Weights
| Base Machine Weight | 34400 lb. |
| Base Machine Weight | 15600 kg |
| Maximum Ballast Level | 39000 lb. |
| Maximum Ballast Level | 17700 kg |
| Maximum Permissible Weight | 40100 lb. |
| Maximum Permissible Weight | 18200 kg |
Hydraulics
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing |
| Pump Rated Output | 85-cc pump: 227.1 L/min (60 gpm) |
| Number of Rear Selective Control Valves (SCVs) | Standard: 1.3-cm (1/2-in.) ISO couplers: 4; Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available |
| Available Flow at a Single Rear SCV | 1.3-cm (1/2-in.) couplers: 132 L/min (35 gpm) |
| SCV Control | Electronic |
Engine
| Engine Make | John Deere |
| Engine Model | JD9 |
| Engine Family | VJDXL09.0333 |
| Emissions Certifications | Final Tier 4 |
| Displacement | 549 cu in. |
| Displacement | 9 L |
| Aspiration | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation |
| Number of Cylinders | 6 |
| Cylinder Liners | Wet-sleeve |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR) |
| Rated Engine Speed | 2100 rpm |
| Rated Engine Power | 306 hp |
| Rated Engine Power | 228 kW |
| Rated Engine Power | 310 PS |
| Engine Torque at Rated Speed | 1070 lb-ft |
| Engine Torque at Rated Speed | 1452 Nm |
| Maximum Engine Power | 336 hp |
| Maximum Engine Power | 251 kW |
| Maximum Engine Power | 341 PS |
| Maximum Engine Torque | At 1600 rpm: 1452 Nm / 1070 lb-ft |
| Power Bulge | 10 % |
| Fuel Type | Diesel |
| Alternative Fuel Type | B30 Diesel Compatible |
| Torque Rise | 40 % |
Electrical System
| Battery Voltage | 12 V |
| Battery Cold Cranking Amps | 1900 CCA |
| Alternator Capacity | 200 amp / 330 amp optional |
| Working Lights | 18–24 LED |
| Driving Lights | LED |
Rear Hitch
| Rear Hitch Category (SAE Designation) | Category 4N/3 at 610 mm (24 in.) behind hitch point: 9072 kg / 20,000 lb; Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg / 15,000 lb |
| Maximum Lift Capacity at 610-mm Behind Hitch Point | Standard (at 610-mm [24-in.] behind hitch point): 12,124 kg 26,729 lb |
| Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point | Standard (at 610-mm [24-in.] behind hitch point): 12,124 kg 26,729 lb |
| Sensing Type | Electrohydraulic |
Rear Axle
| Final Drive | Inboard planetary three pinion |
Operator Station
| Seat Suspension | Air suspension |
| Degree of Seat Swivel, Left Hand | 25 degree (angle) |
| Degree of Seat Swivel, Right Hand | 40 degree (angle) |
| Cab Suspension | Four-post cab suspension |
| Instructional Seat | Standard |
| Primary Display | G5ᴾˡᵘˢ 12.8 in. (325 mm) |
| Radio | AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna |
| Inner Cab Volume | 114 cu ft |
| Inner Cab Volume | 3.24 m³ |
| Cab Glass Area | 70.18 sq ft |
| Cab Glass Area | 6.52 m² |
Capacities
| Fuel Tank Capacity | 202 gal. |
| Fuel Tank Capacity | 764 L |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 8.3 gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 31.3 L |
| Cooling System Capacity | 11.2 gal. |
| Cooling System Capacity | 42.3 L |
| Transmission - Hydraulic System | 52 gal. |
| Transmission - Hydraulic System | 197 L |
| Crankcase Oil Volume | 6.8 gal. |
| Crankcase Oil Volume | 25.7 L |
Transmission
| Transmission Type | Standard: e23™ PowerShift™ 40K, 40 km/h (24.9 mph); Optional: John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h (0.03-26 mph) |
| Maximum Speed Forward | Standard: 40 km/h (25 mph); Optional: 42 km/h (26 mph) |
| Minimum Speed Forward | 0.05 km/h (0.03 mph) |
Steering & Brakes
| Steering Type | Electric command steering with electric pump backup |
Technology Integration
| Guidance | Integrated AutoTrac™ |
| Connectivity | JDLink™ hardware standard, activations, and Ethernet harnesses (availability dependent upon destination) |
| Remote Diagnostics | JDLink™ hardware standard |
Drawbar
| Drawbar Category | Category 4 with heavy-duty support; Optional: Category 4 |
| Maximum Vertical Load | 4950 lb / 11,000 lb; Optional: 2245 kg / 4950 lb |
Additional Information
| Country of Manufacture | USA |
| Date Collected | April 3, 2025 |
Tracks
| Track Drive Type | Camso AG 4500 (MICHELIN BIBTRACK 150) Friction Drive |
| Track Tread Spacing | 1828.8 to 3048 mm / 72 to 120 in. |
| Track Width | Standard: 635 mm / 25 in.; Available: 419 mm / 16.5 in.; 457 mm / 18 in.; 609 mm / 24 in.; 762 mm / 30 in. |
| Number Of Mid Rollers | Three |
Machine Configuration
| Wheel or Track Configuration | 2-Track |
