Features
Stay Focused and In Control All Day
When long days demand focus and precision, 8 Series tractors deliver an elevated operator experience with improved visibility, intuitive controls, and a refined cab environment. Everything is designed to reduce fatigue and simplify operation—so you can stay in control, maintain accuracy, and keep performance consistent from the first pass to the last.
Put Power Down Efficiently Across Every Pass
Getting the most out of every acre means turning power into productivity. 8 Series tractors combine strong horsepower with traction and efficiency technologies that help reduce slip, maintain consistent speeds, and protect soil conditions. The result is more work done per hour, better fuel efficiency, and dependable performance across varying field conditions.
Connect Your Tractor to the Rest of Your Operation
Productivity doesn’t stop at the cab - it extends across your entire operation. With integrated precision technology and connectivity through John Deere Operations Center, 8 Series tractors help you document work, monitor performance, and make informed decisions. Turn every pass into insight and plan your next move with greater confidence.
Specifications
Rear Power Take-Off (PTO)
| PTO Category | Standard: 45 mm (1.75 in.) 20-spline, 1,000 rpm; Optional: 45 mm (1.75 in.), 20-spline, 1000/1000E rpm |
| Rated PTO Power | 310 hp |
| Rated PTO Power | 231 kW |
| Rated PTO Power | 314 PS |
| Economy PTO Speeds | 1000E rpm |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1810 / 1995 |
| Engine rpm at Rated PTO Speeds (540E/1000/1.000E) | -- / 1995 / 1590 |
| Engagement Method | Electrohydraulic with adjustable modulation |
| Number of Splines | 20 |
Hydraulics
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing |
| Pump Rated Output | Standard: 85-cc pump: 227.1 L/min (60 gpm); Optional: 85-cc plus 35-cc dual pump: 318 L/min (84 gpm) |
| Number of Rear Selective Control Valves (SCVs) | Standard: 1.3-cm (1/2-in.) ISO couplers: 4; Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available |
| Available Flow at a Single Rear SCV | 1.3-cm (1/2-in.) couplers: 132 L/min (35 gpm) |
| SCV Control | Electronic |
Engine
| Engine Make | John Deere |
| Engine Model | JD9 |
| Engine Family | VJDXL09.0333 |
| Emissions Certifications | Final Tier 4 |
| Displacement | 549 cu in. |
| Displacement | 9 L |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series; air-to-air aftercooling and cooled exhaust gas recirculation |
| Number of Cylinders | 6 |
| Cylinder Liners | Wet-sleeve |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR) |
| Rated Engine Speed | 2100 rpm |
| Rated Engine Power | 365 hp |
| Rated Engine Power | 272 kW |
| Rated Engine Power | 370 PS |
| Engine Torque at Rated Speed | 1277 lb-ft |
| Engine Torque at Rated Speed | 1732 Nm |
| Maximum Engine Power | 401 hp |
| Maximum Engine Power | 299 kW |
| Maximum Engine Power | 407 PS |
| Maximum Engine Torque | At 1600 rpm: 1732 Nm / 1277 lb-ft |
| Power Bulge | 10 % |
| Fuel Type | Diesel |
| Alternative Fuel Type | B30 Diesel Compatible |
| Torque Rise | 40 % |
Dimensions & Weights
| Wheelbase | 120.1 in. |
| Wheelbase | 3050 mm |
| Base Machine Weight | 28000 lb. |
| Base Machine Weight | 12700 kg |
| Overall Length | 261.3 in. |
| Overall Length | 6636 mm |
| Drawbar Ground Clearance | 15.2 in. |
| Drawbar Ground Clearance | 385 mm |
| Maximum Ballast Level | 44100 lb. |
| Maximum Ballast Level | 20000 kg |
| Maximum Permissible Weight | 44100 lb. |
| Maximum Permissible Weight | 20000 kg |
Electrical System
| Battery Voltage | 12 V |
| Battery Cold Cranking Amps | 1900 CCA |
| Alternator Capacity | 200 amp / 330 amp optional |
| Working Lights | 18–24 LED |
| Driving Lights | LED |
Rear Hitch
| Rear Hitch Category (SAE Designation) | Category 4N/3 |
| Lift Capacity Through Full Lift Range at Coupling Points | 11464 |
| Maximum Lift Capacity at 610-mm Behind Hitch Point | 9072 |
| Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point | 15000 / 20000 lb (6803 / 9072 kg) |
| Sensing Type | Electrohydraulic |
Operator Station
| Seat Suspension | Air seat / ActiveSeat™ II Optional |
| Degree of Seat Swivel, Left Hand | 25 degree (angle) |
| Degree of Seat Swivel, Right Hand | 40 degree (angle) |
| Cab Suspension | Adjustable cab suspension optional |
| Instructional Seat | Standard |
| Primary Display | G5ᴾˡᵘˢ 12.8 in (325 mm) |
| Radio | AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna |
| Inner Cab Volume | 114 cu ft |
| Inner Cab Volume | 3.24 m³ |
| Cab Glass Area | 70.61 sq ft |
| Cab Glass Area | 6.56 m² |
Transmission
| Transmission Type | Standard: e23™ PowerShift™ 40K, 40 km/h (24.9 mph); Optional: e23™ PowerShift™ 50K, 50 km/h (31 mph); John Deere eAutoPowr™ EVT™ 40K, 0.05-42 km/h (0.03-26 mph); John Deere eAutoPowr™ EVT™ 50K, 0.05-50 km/h (0.03-31 mph) |
| Maximum Speed Forward | 50 km/h (31 mph) |
| Minimum Speed Forward | 0.05 km/h (0.03 mph) |
Steering & Brakes
| Steering Type | Hydraulic power-steering with electric pump back-up; Optional: Reactive Command Steering (RCS™) with electronic backup pump |
| Primary Brakes | Full-locking electrohydraulic |
| Trailer Brakes | Inboard planetary three pinion |
Capacities
| Fuel Tank Capacity | 192; CTIS: 172 gal. |
| Fuel Tank Capacity | 727; CTIS: 651 L |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 9.8 gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 37.2 L |
| Cooling System Capacity | 11.2 / 12.4 gal. |
| Cooling System Capacity | 42.3 / 46.9 L |
| Transmission - Hydraulic System | 48.8 / 54.7 gal. |
| Transmission - Hydraulic System | 184.6 / 207.2 L |
| Crankcase Oil Volume | 7.3 / 6.8 gal. |
| Crankcase Oil Volume | 27.6 / 25.8 L |
Drawbar
| Drawbar Category | Standard: Category 4 with heavy-duty support; Optional: Category 4 |
| Maximum Vertical Load | Standard: 4,990 kg (11,000 lb); Optional: 2,245 kg (4,950 lb) |
Technology Integration
| Guidance | Integrated AutoTrac™; Autonomy Ready (available in select regions) |
| Connectivity | JDLink™ hardware standard, activations, and Ethernet harnesses (availability dependent upon destination) |
| Remote Diagnostics | JDLink hardware standard |
Additional Information
| Country of Manufacture | USA |
| Date Collected | 4/3/2025 12:00:00 AM |
Machine Configuration
| Wheel or Track Configuration | Wheel |
| Drive Type | MFWD |
Tires
| Wheel Tread Range | Standard (ILS): 1524-3657 mm (60-144 in.); Optional (1500 Series MFWD): 1524-3657 mm |
| Central Tire Inflation System (CTIS) | Optional |
Tracks
| Number Of Mid Rollers | Optional |
Front PTO
| PTO Speed | 1000 |
| Front PTO Rotation | 35 mm (1.375 in.) 21 spline, 1000 rpm; 45 mm (1.75 in.) 20 spline, 1000 rpm (available through parts only); 35 mm (1.375 in.) 6 spline, 1000 rpm (available dependent on location) |
| Engine rpm (at Rated PTO Speeds) | 2000 rpm |
Front Hitch
| Front Hitch Category | Category 3N |
| Lift Capacity Through Full Lift Range at Coupling Points | 11464 lb. |
| Lift Capacity Through Full Lift Range at Coupling Points | 5200 kg |
Rear Axle
| Rear Axle Type | Standard: Long, 120 mm (4.72 in.) diameter by 3,010 mm (118.5 in.) length with Double Flat Wheel Hubs; Optional: Long, 120 mm (4.72 in.) diameter by 3,010 mm (118.5 in.) length with Double Taper Wheel Hubs; Short, 120 mm (4.72 in.) diameter by 2,550 mm (100.4 in.) length with Double Flat Wheel Hubs |
| Rear Differential Lock | Full-locking electrohydraulic |
| Differential Controls | Standard: 1500 Series MFWD Optional: ILS |
| Final Drive | Inboard planetary three pinion |
Front Axle
| Front Axle Type | Standard: ILS; Optional: 1500 Series MFWD |
| Front Axle Differential Lock | ILS / 1500 Series MFWD: Full-locking electrohydraulic |
