Features
Run Big Acres with Confidence
When the day calls for heavy draft work, PTO power, or road runs between fields, 7 Series tractors deliver the muscle and efficiency to keep you moving. Strong power-to-weight, transmission choices, and smart power management help maintain speed under load - so you cover more acres with fewer compromises.
Turn Every Pass into Better Decisions
Don’t let performance stop at the cab. With connectivity and documentation through John Deere Operations Center, 7 Series tractors help you track work, verify coverage, and stay on schedule - whether you’re in the field or back at the office. Turn trusted machine data into better decisions and smoother seasons ahead.
Stay Comfortable and In Control All Day
Long days get easier when the tractor fits the operator. 7 Series tractors pair an automotive-inspired cab with comfort options and intuitive controls, so steering, shifting, and implement functions stay at your fingertips. The result is less fatigue, better control, and consistent job quality from first pass to last.
Specifications
Front PTO
| PTO Speed | 1000 |
| Front PTO Rotation | Counter-clockwise |
| Front Number of Splines | 21 |
Engine
| Engine Make | John Deere |
| Engine Family | MJDXL06.8309 |
| Emissions Certifications | Final Tier 4 |
| Displacement | 415 cu in. |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series |
| Cylinder Liners | Wet-sleeve cylinder liners |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) |
| Intelligent Power Management (IPM) | Power boost: 29.6 hp / 22.1 kW / 30 PS (hp ISO) |
| Rated Engine Power | 247 hp |
| Rated Engine Power | 184 kW |
| Rated Engine Power | 250 PS |
| Maximum Engine Power | 271 hp |
| Maximum Engine Power | 202 kW |
| Maximum Engine Power | 275 PS |
| Maximum Engine Torque | At 1600 rpm: 1171 Nm (864 lb-ft) |
| Fuel Type | Diesel |
Front Axle
| Front Axle Type | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm (60 to 88 in.); Optional: TLS: Tread range 1524 to 2235 mm; TLS with front brakes available with 40 km/h (24.9 mph); TLS with front brakes standard with 50 km/h (31 mph) |
| Front Axle Differential Lock | 1300 Series MFWD: Limited slip; TLS: Limited slip; TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) |
Additional Information
| Country of Manufacture | USA |
| Date Collected | 4/3/2025 12:00:00 AM |
Hydraulics
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing |
| Available Flow at a Single Rear SCV | 35 gpm (132 L/min) |
Electrical System
| Battery Capacity | 2 x 950 CCA |
| Alternator Capacity | Standard: 210 amp, Optional: 250 amp |
| Driving Lights | Standard: 65-W halogen; Available: LED |
Rear Axle
| Final Drive | Inboard planetary three pinion |
Front Hitch
| Front Hitch Category | Category 3N, ground engaging |
| Electric Power | Seven-pin connector |
Machine Configuration
| Wheel or Track Configuration | Wheel |
Operator Station
| Cab Suspension | Adjustable cab suspension (Optional) |
| Instructional Seat | Standard |
Rear Power Take-Off (PTO)
| Engine rpm at Rated PTO Speeds (540/1.000) | 1950 |
| Engine rpm at Rated PTO Speeds (540E/1000/1.000E) | 1750 |
| Engagement Method | Electric switch with adjustable modulation |
Technology Integration
| Guidance | Integrated AutoTrac™ |
| Connectivity | JDLink™ |
Drawbar
| Drawbar Category | Category 3; Optional: Category 3 with heavy-duty support; Category 4 |
Rear Hitch
| Maximum Lift Capacity Directly at Coupling Points | Standard (Category 3): 6894 kg (15,200 lb); Optional (Category 3N): 7847 kg (17,300 lb); Standard (Category 3 with hook ends): 6984 kg, Optional (Category 3 with hook ends): 7847 kg (17,300 lb) |
