Features
Run Big Acres with Confidence
When the day calls for heavy draft work, PTO power, or road runs between fields, 7 Series tractors deliver the muscle and efficiency to keep you moving. Strong power-to-weight, transmission choices, and smart power management help maintain speed under load - so you cover more acres with fewer compromises.
Turn Every Pass into Better Decisions
Don’t let performance stop at the cab. With connectivity and documentation through John Deere Operations Center, 7 Series tractors help you track work, verify coverage, and stay on schedule - whether you’re in the field or back at the office. Turn trusted machine data into better decisions and smoother seasons ahead.
Stay Comfortable and In Control All Day
Long days get easier when the tractor fits the operator. 7 Series tractors pair an automotive-inspired cab with comfort options and intuitive controls, so steering, shifting, and implement functions stay at your fingertips. The result is less fatigue, better control, and consistent job quality from first pass to last.
Specifications
Front PTO
| PTO Speed | 1000 |
| Front PTO Rotation | Counter-clockwise rotation (when facing PTO) |
| Front Number of Splines | 21 |
Engine
| Engine Make | John Deere |
| Engine Family | MJDXL06.8309 |
| Emissions Certifications | Final Tier 4 |
| Displacement | 415 cu in. |
| Displacement | 6.8 L |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series |
| Number of Cylinders | 6 |
| Cylinder Liners | Wet-sleeve cylinder liners with four valves in head |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) |
| Intelligent Power Management (IPM) | 22.1 kW, 30 PS (hp ISO) |
| Rated Engine Power | 227 hp |
| Rated Engine Power | 169 kW |
| Rated Engine Power | 230 PS |
| Maximum Engine Power | 250 hp |
| Maximum Engine Power | 186 kW |
| Maximum Engine Power | 253 PS |
| Maximum Engine Torque | At 1600 rpm: 1077 Nm 794 lb-ft |
| Fuel Type | Diesel |
Front Axle
| Front Axle Type | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm 60 to 88 in.; Optional: TLS: Tread range 1524 to 2235 mm; TLS with front brakes available with 40 km/h 24.9 mph; TLS with front brakes standard with 50 km/h 31 mph |
| Front Axle Differential Lock | 1300 Series MFWD: Limited slip; TLS: Limited slip; TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) |
Additional Information
| Country of Manufacture | USA |
| Date Collected | 03 April 2025 |
Hydraulics
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing |
| Available Flow at a Single Rear SCV | 35 gpm(132 L/min) |
Front Hitch
| Front Hitch Category | Category 3N, ground engaging |
| Electric Power | Seven-pin connector |
Machine Configuration
| Wheel or Track Configuration | Wheel |
Drawbar
| Drawbar Category | Standard: Category 3; Optional: Category 3 with heavy-duty support Category 4 |
| Maximum Vertical Load | Standard: Category 3: 1837 kg 4050 lb; Optional: Category 3 with heavy-duty support: 4536 kg 10,000 lb |
Operator Station
| Cab Suspension | Optional: Adjustable cab suspension |
| Instructional Seat | Standard |
Electrical System
| Battery Voltage | 12 V |
| Battery Cold Cranking Amps | 1900 CCA |
| Alternator Capacity | Standard: 210 amp Optional: 250 amp |
| Working Lights | Standard: 18 halogen; Available: 18 light-emitting diode (LED) and two halogen or 22 LED and two halogen |
Rear Power Take-Off (PTO)
| Engine rpm at Rated PTO Speeds (540/1.000) | 1950 |
| Engine rpm at Rated PTO Speeds (540/540E/1.000) | 1950/1750 |
| Engagement Method | Electric switch with adjustable modulation |
Technology Integration
| Guidance | Integrated AutoTrac™ |
| Connectivity | JDLink™ |
| Remote Diagnostics | ServiceADVISOR™ Remote: available with JDLink™ hardware and activations; Remote Display Access: available with JDLink™ hardware and activations |
Rear Hitch
| Maximum Lift Capacity Directly at Coupling Points | Standard (Category 3): 5443 kg 12,000 lb; Optional (Category 3N): 6894 kg 15,200 lb; Standard (Category 3 with hook ends): 5443 kg; Optional (Category 3 with hook ends): 6894 kg 15,000 lb |
Rear Axle
| Rear Axle Type | Inboard planetary three pinion |
