Features
Category 1 and 2 Implement Compatibility
The 4M Heavy-Duty Tractor’s 3-point hitch system offers high implement versatility with Category 1 and 2 compatibility, telescoping draft links, and a lift capacity of up to 3130 lb (1420 kg) at the lift link ends. Its position control lever, rate-of-drop valve, and adjustable stabilizers ensure precise, consistent implement depth and easy attachment without tools.
Excellent Visibility Provided by Standard Lighting Equipment
Standard lighting equipment includes wide-angle halogen headlights with premium automotive-style bezels, amber flashing warning lights, and fender-mounted working lights, all compliant with ASAE S279 standards.
Maximize Productivity With an eHydro™ Transmission
The eHydro™ transmission offers seamless operation with an infinitely variable ground speed, no clutching for direction changes, and integrated Twin Touch™ foot controls for quick and easy forward/reverse movement. It maximizes tractor productivity, reduces powertrain shock loads, and enhances operator comfort by providing high torque for startup.
Specifications
Rear Axle
| Rear Axle Type | Flange |
| Rear Differential Lock | Electrohydraulic |
| Differential Controls | Electrohydraulic |
| Final Drive | Inboard planetary |
Hydraulics
| Hydraulic System Type | Standard: Open center; Optional: Pressure-and-flow compensated (PFC) system |
| Pump Rated Output | Standard: 94 L/min / 24.7 gpm; Optional: 117 L/min / 31 gpm |
| Available Flow at a Single Rear SCV | 70 L/min / 18.4 gpm; Optional: 100 L/min / 26.4 gpm |
| SCV Control | Mechanical |
Electrical System
| Alternator Capacity | 90 amp |
| Working Lights | Standard: Halogen; Optional: LED |
| Driving Lights | Standard: Halogen; Optional: LED |
Rear Hitch
| Rear Hitch Category (SAE Designation) | Category 2; convertible to 1 |
| Sensing Type | Top link |
| Draft Control Sensing | Mechanical or Electrohydraulic |
Rear Power Take-Off (PTO)
| PTO Category | 540/540E; Optional: 540/540E/1000 |
| Engagement Method | Electrohydraulic |
Engine
| Engine Make | John Deere PowerTech™ 4045 PWL |
| Emissions Certifications | Final Tier 4 |
| Aspiration | Turbocharged |
| Cylinder Liners | Wet sleeved |
| Aftertreatment Type | ERG/DOC/SCR |
| Rated Engine Speed | 2600 rpm |
| Rated Engine Power | 65 hp |
| Rated Engine Power | 49 kW |
| Rated Engine Power | 66 PS |
| Maximum Engine Torque | 500 Nm / 369 lb-ft |
Capacities
| Fuel Tank Capacity | 29.6 (PowrReverser™) / 38.0 (PowrQuad™ PLUS/Powr8™) gal. |
| Fuel Tank Capacity | 112 (PowrReverser™) / 144 (PowrQuad™ PLUS/Powr8™) L |
Operator Station
| ROPS Type | Foldable, two-post |
| Gearshift Location | Floor |
| Seat Suspension | Low Profile |
| Instructional Seat | Not Available |
| Primary Display | Automotive style light-emitting LED instrument cluster |
| Radio | Optional |
Front Axle
| Front Axle Type | Mechanical Front Wheel Drive (MFWD) |
Technology Integration
| Guidance | Optional: AutoTrac™ with AutoTrac Basic |
| Connectivity | JDLink™ Modem |
| Remote Diagnostics | Yes |
| ISOBUS Ready | Optional for cab models |
Drawbar
| Drawbar Category | Category 2 |
| Maximum Vertical Load | Road/field use (250-mm extended): 1450 kg / 3197 lb; Field use (350-mm extended): 1200 kg / 2646 lb; Field use (400-mm extended): 1200 kg / 2646 lb |
Transmission
| Transmission Type | PowrReverser™ 16F/16R; Optional: PowrQuad™ PLUS 16F/16R, Powr8™ 32F/16R |
| Creeper | Cab: Powr8™ 32F/16R with creeper |
| Reverser | Yes |
| Clutch | Wet |
Additional Information
| Country of Manufacture | Saltillo, Mexico |
| Date Collected | 2023_01_06T00:00:00.0000000 |
Tires
| Rear Tires Size | 19.5L–24 in. 10PR R4 Bias |
| Wheel Tread Range | Front: 1299–1997 mm / 51.1–78.6 in |
Machine Configuration
| Wheel or Track Configuration | Wheel |
Steering & Brakes
| Primary Brakes | Hydraulic wet disc |
