Features

Adjustable Skid Shoes Increase Durability

Close-up studio view of skid shoe on the underside of the SB13 Snowblower

The adjustable steel skid shoes on the SB13 Series increase the durability and life of the snowblowers.

Hydraulic Drum Rotation

Close up studio view of the hydraulic drum on a SB1309 Snowblower

On all SB13R models, the hydraulic drum rotation is standard and is great for operators who want to move large amounts of snow at a faster rate of speed while consuming less horsepower when discharging snow out the drum door. The drum door is hydraulically opened and closed, allowing operators to discharge snow to the side when it is open or discharge snow through the chute when the door is closed. All of this can be done without ever leaving the seat of the tractor.

Hydraulic Chute Rotation Blows Snow Anywhere

Close-up of a green snowblower housing showing a rotating chute base with gear teeth, hydraulic hoses, and safety decals

All SB13 Series Snowblowers are equipped with hydraulic chute rotation. Chute rotation adds versatility by allowing the operator to blow snow exactly where they want it to go.

Specifications

Warranty period

Gear Box Warranty Period1 year
Machine Warranty Period1 year

Auger

Auger Diameter55.9 cm
Auger Diameter22 in.
Auger Speed170 rpm
Auger Overload ProtectionSingle, dual is optional

Weights

Operating Weight1670 lb.
Operating Weight757.5 kg
Shipping Weight778 kg
Shipping Weight1715 lb.

Hitch

Quick CouplerYes
Hitch CompatibilityCategory 2

Chute

Chute Rotation Degrees270 degree (angle)
Chute TypeTwo-part or three-part
Chute Diameter32.4 cm
Chute Diameter 12.75 in.
Standard Chute Deflector AdjustmentManual
Chute Rotation TypeHydraulic
Optional Chute Deflector AdjustmentHydraulic cylinder

Dimensions

Height40 in.
Transport Width224.8 cm
Height101.6 cm
Transport Width88.5 in.
Working Width88 in.
Working Width223.5 cm
Length158.75 cm
Length62.5 in.

Setup Time

Set-Up Time Labor Hours1.5 hours

Tractor Compatibility

PTO Overload ProtectionShearbolt
PTO SpeedStandard: 540 rpm; Optional: 1000 rpm rpm
Minimum Power33.6 kW
Minimum Power45 hp
Maximum Power70.8 kW
Maximum Power95 hp

Housing

Side Panel Thickness1.59 cm
Side Panel Thickness0.63 in.
Impeller Housing Thickness0.64 cm
Impeller Housing Thickness0.25 in.

Skid Shoes

Skid Shoe TypeSteel, adjustable
Skid Shoe MaterialSteel

Chain

Chain Roller80
Chain Idler AdjustmentAutomatic

Impeller

Optional Secondary Auger Diameter14 in.
Optional Secondary Auger Diameter35.6 cm
Impeller Width12 in.
Impeller BladesFour
Impeller Width30.48 cm
Impeller Diameter28 in.
Impeller Diameter71.2 cm
Impeller Speed540 rpm

Cutting Edge

Cutting Edge TypeBolt on reversible

Drum

Drum RotationStandard
