John Deere RT2383

New Products / John Deere / John Deere Products / Tractors / Tractor Attachments and Implements / RT2383

Double tap to zoom



Features

Cage Roller Adjustment for Firming Action Is Easy

Green Frontier soil‑conditioning or seedbed‑preparation attachment mounted behind a tractor, showing the rear leveling bar and guard with an orange safety slow‑moving vehicle sign visible above the implement.

The hand crank makes adjusting the depth of the roller easy on the RT22 and RT23 Series Rotary Tillers. Use a lower setting for more firming action, ideal for controlling wind erosion. The RT22 and RT23 Series have an optional hydraulic cage roller adjustment kit available to allow for depth adjustments without leaving the tractor seat.

Heavy-Duty Wear Shields for Added Gearcase Protection

Close‑up of a green Frontier agricultural mower attachment showing the curved protective side panel with the Frontier logo, mounted low to the ground with crop residue and soil around the cutting area.

The gearcase is protected from abrasion and premature wear by the heavy-duty wear shields.

Rotor Is Helical-Shaped for Higher Efficiency

Front studio view of helical rotors on the RT Series Rotary Tiller

The helical-shaped rotor decreases horsepower required to drive units. They are designed so they enter the field at different times for more efficiency.

Specifications

Safety And Markings

MarkingsStandard
Rear Door SupportMetal rod with double spring
Parking StandStandard

Tractor Compatibility

PTO Speed540 rpm
Maximum PTO Power121 hp
Maximum PTO Power90 kW
Minimum PTO Power41 kW
Minimum PTO Power55 hp

Depth Control

Maximum Working Depth27 cm
Maximum Working Depth10.6 in.
Depth Control TypeSkid shoes; Optional: cage roller

Weight

Operating with Cage Roller1015.1 kg
Operating with Cage Roller2238 lb.
Operating With Skid Shoes1763 lb.
Operating With Skid Shoes799.7 kg

Dimensions

Outside To Outside Width88 in.
Outside To Outside Width2235 mm
Working Width2083 mm
Working Width82 in.

Gearbox

Gearbox TypeMulti-speed

Hitch

Quick Coupler (Category 2)Yes
3-Point CompatibleCategory 2

Blade

Blade ShapeL-shape

Rotor

Blades (Quantity)6
Flanges (Quantity)9

Drive System

Drive System TypeGear side drive

Warranty

Time Period1 year

PTO Shaft

Clutch TypeFriction

Duty

Duty TypeHeavy duty
