Features

Anti-Burying Plate

Studio close-up of the anti-burying plate on a black post hole digger's auger

The anti-burying plate positions the teeth at a steeper angle, ensuring aggressive soil penetration. This design prevents the auger from screwing itself into the ground, allowing soil to pulverize efficiently.

Auger Positioning Handle

PHD395 post hole digger with auger positioning handle standing in a shop

The auger positioning handle allows the operator to easily align the auger into the desired position from the operator’s seat prior to digging. The auger positioning handle is in base equipment on all PHD Series Post-Hole Diggers.

Hook-Up Parking Stand

Side view of a post hole digger with green hook-up parking stand set up in a workshop

The removable hook-up parking stand makes mounting and detaching the post hole digger to the tractor a safer, easier, one-person job. While in-between jobs, the parking stand allows the post hole digger to be stored in the upright position.

Specifications

Auger

Auger Dimensions6x48, 9x48, 12x48 in.
Auger Flighting TypeSemi-Double Flighting
Auger Weight15 (6x48 in.), 18.6 (9x48 in.), 27.2 (12x48 in.) kg
Auger Weight33 (6x48 in.), 41 (9x48 in.), 60 (12x48 in.) lb.
Model NumberPHD235
Auger PointsSpiral Point or Cast Ductile Iron
Cutting EdgesReplaceable Carbide Cutting Edge

Auger Speed

Rotations Per Minute185

Weight

Shipping (2 Per Case)356 lb.
Shipping (2 Per Case)213.2 kg
Unit90.7 kg
Unit178 lb.

Tractor Compatibility

PTO HP Range20-35 hp
PTO HP Range13.4-29 kW

Dimensions

Yoke OD7.9 cm
Yoke OD3.11 in.
Boom OD3.5 in.
Boom OD8.9 cm

Gearbox

Gear Ratio2.92:1

3-Point Hitch

CategoryCategory 1
