John Deere GS4048L

Double tap to zoom

GS4048L

Tractor Attachments and Implements

Overview:

The Frontier™ GS4048L - 48 in. Ground Seeder boosts germination with a spiked drive roller and nylon cultipacker, while dual seed boxes are versatile for cool-season and legume seeds.

Built-In Seed Dispersal Rate Chart and Calibration
High-Precision Metering Seed Cups Handle Multiple Seed Varieties
3-Point Hitch Compatible
Ground Driven

Get a Quote

Get A Quote

Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

Loan Calculator

Use the Loan Calculator to help you determine the financing and payment options that are best for you.

**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Send To A Friend

Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

Share This Product:

Features
Specifications

Features

Front Gangs

Tractor pulling a rear‑mounted tillage or soil‑preparation attachment across a field, with the implement churning dry soil and residue.

The GS40L Series equips users with a choice between front notched disc blades for cutting seed openings or aggressive tillage, and front spiked rollers that form seed pockets and can uproot existing vegetation when angled sharply, making it adaptable across diverse field conditions.

Spiked Drive Roller

Standard equipment on the GS40L, the spiked drive roller will crush clods, push down seeds, and dimple soil to trap moisture.

Nylon Cultipacker for Improved Germination

Rear view of tractor pulling a mounted seed drill across a field showing the metal hopper, warning triangle reflectors, and rotating soil-conditioning rollers working the ground.

To increase germination, the in-base rear nylon cultipacker levels and breaks up soil clods, pressing the seed into the soil for improved seed-to-soil contact, firms the seed bed, and creates furrows to trap and channel water.

Specifications

Weight

Operational Weight	713 lb.
Operational Weight	323 kg
Spiked Roller And Primary Box	194 kg
Spiked Roller And Primary Box	427 lb.

Spike Roller

Roller Diameter (Front And Rear)	6.6 in.
Front Roller Positions	Four positions
Number Of Roller Pins (Front And Rear)	144
Roller Diameter (Front And Rear)	16.8 cm
Front Roller Positions - Angle	0-21 degree (angle)

Dimensions

Working Width	121.9 cm
Working Width	48 in.
Overall Width	56.75 in.
Overall Width	144.2 cm

Capacity

Hopper Capacity	35.2 m³
Hopper Capacity	1 bu

Front Disc

Disc Type	Notched
Number Of Discs	6
Disc Spacing	7.5 in.
Disc Spacing	19 cm
Disc Diameter	40.6 cm
Disc Diameter	16 in.
Front Disc Angle	0 / 5 / 10 / 15 degree (angle)

Hitch

3-Point Type	Limited Category 1
Quick Hitch Compatible	Yes
Category	Limited Category 1

Cultipacker

Diameter	9.5 in.
Diameter	24.1 cm
Number	20

Seedcups

Picker Wheels

Warranty

Time Period

1 year

Setup Time

Labor Hours

1 hr

Tractor Compatibility

Horsepower	15-35 hp
Horsepower	11-26 kW
