John Deere AY11E - 72 in.

New Products / John Deere / John Deere Products / Tractors / Tractor Attachments and Implements / AY11E - 72 in.

Double tap to zoom



Features

Serrated Edge to Grasp Material

Front left view of an AY11 series 4-in-1 bucket with serrated edge full of gravel

The AY11E Series is equipped with serrated edges that enhance the bucket's ability to firmly grasp material, ensuring secure movement and improving overall performance.

Fast, Easy Attachment

Studio left-side view of a green AY11 series 4-in-1 bucket and hitch

Designed for fast and easy attachment, the bucket fits 300 to 500 Series Loaders. It utilizes quick-change and global attaching systems to streamline the process of lining up connecting points and locking in place.

Strong and Robust Frame for Added Durability

Side left view of an AY11H 4-in-1 bucket attached to tractor dumping gravel on a pile at full arm extension

The AY11E Series Four-in-One Bucket features a robust steel frame with welded components and high-tensile, heavy-gauge steel to ensure maximum durability and strength during operations.

Specifications

Dimensions

Height26.94 in.
Height68.4 cm
Cutting Width72 in.
Cutting Width182.9 cm
Depth71.1 cm
Depth28.01 in.
Width187.7 cm
Width73.88 in.
Clam Opening72.3 cm
Clam Opening28.45 in.

Weight

Operational Weight192.8 kg
Operational Weight425 lb.
Shipping Weight204.1 kg
Shipping Weight450 lb.

Hydraulic Cylinders

Hydraulic Cylinders TypeTwo double-acting

Clamp force

Clamp Force Closed10577.9 N
Clamp Force Closed2378 lb-ft
Clamp Force Open16035.8 N
Clamp Force Open3605 lb-ft

Warranty

Warranty Time Period1 year

Attachment Carrier

Current Series Style300, 400, and 500

Setup Time

Set-Up Time Labor Hours0.25 hr
