Features

Reversible Cutting Edges

Close-up of a green curved metal blade featuring a black reinforced cutting edge secured with bolts

The heat-treated steel cutting edge is reversible, doubling durability and work life. This efficiency makes it ideal for long periods of demanding use in various terrains. The reversible nature ensures that both sides can be utilized, minimizing downtime for edge replacements.

Hydraulic Angle Adjustment

Rear right studio view of AF Series Front Blade highlighting the hydraulic connections

The hydraulic angle can be adjusted up to 30 degrees on each side, allowing the operator to tackle challenging spots with ease. This adjustment not only saves time but also ensures professional-grade results in difficult-to-reach places.

Heavy-Duty Frame Construction

Green hydraulic-powered front blade with a curved blade, mounting brackets, and two hydraulic hoses extending from the frame

The loader-mounted front blade is crafted from heavy-duty steel to resist bending. This construction provides long-term reliability and wear capability, making it perfect for extensive fieldwork and robust applications.

Specifications

Dimensions

Width108 in.
Width274.3 cm
Height32 in.
Height81.3 cm
Depth55 in.
Depth139.7 cm
Cutting Width108 in.
Cutting Width274.3 cm
Weight, Shipping1315 lb.
Weight, Shipping596.5 kg
Weight, Operating1265 lb.
Weight, Operating573.8 kg

Skid Shoes

Skid Shoes StandardYes

Weight

Operational Weight1265 lb.
Operational Weight573.8 kg
Shipping Weight1315 lb.
Shipping Weight596.5 kg

Hydraulic Cylinders

Hydraulic Cylinder TypeTwo double-acting

Moldboard

Moldboard Thickness0.13 in.
Moldboard Thickness3.4 mm
Moldboard Thickness10 gauge
Moldboard Height31.8 in.
Moldboard Height808 mm

Setup Time

Setup Time Labor Hours0.5 hr

Warranty

Warranty Time PeriodOne year

Attachment Carrier

Current Series Style600, 700

Angle/Pivot

Angle/Pivot Standard AdjustmentHydraulic
Angle/Pivot Degrees (Each Side)30
