Features
Premium Cab
Enjoy a spacious cab that provides all day comfort with ergonomic controls, excellent visibility, and a sealed environment. Available Category IV filtration system protects operators from dust, aerosols, and vapors while maintaining fresh airflow.
PowrQuad™ PLUS and Powr8™ Transmissions
Operators can easily find the right working speed using push-button gear shifting, while PowrQuad™ PLUS and Powr8™ transmissions boost productivity with clutchless hydraulic shifting between forward and reverse. The ergonomically placed control lever and fingertip directional switch streamline gear changes and direction shifts, reducing clutch wear and enhancing efficiency in tight spaces.
Built-In Precision Ag Solutions
Integrated JDLink™ connectivity provides near real-time machine tracking, maintenance alerts, and utilization insights. This connected capability helps operators manage uptime, service planning, and fleet coordination and support across their operation.
Activation required. JDLink hardware comes standard with the machine. You can turn on JDLink Connected service in your John Deere Operations Center™ account for free. JDLink requires a cellular connection to transfer information from machine to a JDLink website. Consult your John Deere dealer for coverage availability.
Specifications
Rear Axle
| Rear Axle Type | Standard: flange‑type; Optional: rack‑and‑pinion rear axle (79‑mm shaft; standard/short lengths) |
| Rear Differential Lock | Electrohydraulically with oil‑cooled clutch |
| Final Drive | Three planetary gear reduction |
Hydraulics
| Hydraulic System Type | Standard: Pressure compensated (PC); Optional: Pressure‑and‑flow compensated (PFC) with Load Sensing |
| Pump Rated Output | Standard: 80 L/min (21 gpm); Optional: 114 L/min (30 gpm) |
| SCV Control | Mechanical/electrical |
Engine
| Engine Make | John Deere PowerTech™ EWL |
| Emissions Certifications | Final Tier 4 |
| Aspiration | Single turbocharger with wastegate |
| Aftertreatment Type | Diesel oxidation catalyst (DOC) and selective catalytic reduction (SCR) using diesel exhaust fluid (DEF) |
| Intelligent Power Management (IPM) | Power boost |
| Rated Engine Power | 105 hp |
| Rated Engine Power | 77 kW |
| Rated Engine Power | 105 PS |
| Maximum Engine Power | 110 hp |
| Maximum Engine Power | 81 kW |
| Maximum Engine Power | 110 PS |
Rear Hitch
| Rear Hitch Category (SAE Designation) | 2/3N |
| Sensing Type | Electronic lower link |
Steering & Brakes
| Steering Type | Dynamic load sensing, hydrostatic, flow metering |
| Primary Brakes | Oil‑cooled self‑equalizing, self‑adjusting, hydraulically actuated |
| Secondary Brake | Hydraulically actuated, integrated into primary brake |
| Trailer Brakes | Hydraulic and pneumatic trailer brakes |
| Parking Brake | Mechanical transmission park lock |
Capacities
| Fuel Tank Capacity | 46.2 gal. |
| Fuel Tank Capacity | 175 L |
Operator Station
| ROPS Type | Rollover protective structure, OOS |
| Gearshift Location | Console |
| Seat Suspension | Standard: Economy seat with mechanical suspension; Optional: Standard seat with air suspension |
| Cab Suspension | Optional: Mechanical Cab Suspension (MCS) |
| Instructional Seat | Optional |
| Primary Display | Cornerpost display (right‑hand A‑post); Performance monitor and individual settings |
| Radio | Optional integrated |
Front Axle
| Front Axle Type | Standard: MFWD; Optional: 2WD; TLS™ MFWD axle options |
| Front Axle Differential Lock | Self‑locking differential |
Rear Power Take-Off (PTO)
| Engagement Method | Electrohydraulically operated, oil‑cooled, multi‑disc design |
| PTO Clutch | Oil‑cooled, multi‑disc design |
Electrical System
| Alternator Capacity | Standard: 14 V/120 amp; Optional: 14 V/150 amp; 14 V/200 amp |
Technology Integration
| Guidance | Optional: AutoTrac™ on cornerpost display (straight track only), AutoTrac with 4240/4640 Universal Display |
| Secondary Display | 4240/4640 Universal Display |
| Connectivity | JDLink™ (telematics) |
| Remote Diagnostics | JDLink™ |
| ISOBUS Ready | ISOBUS ready |
Drawbar
| Drawbar Category | Category 2 |
| Maximum Vertical Load | Road/field use (250‑mm extended): 2000 kg / 4409.2 lb; Field use (350‑mm extended): 1400 kg / 3086.5 lb; Field use (400‑mm extended): 1200 kg / 2645.5 lb |
Transmission
| Transmission Type | PowrQuad™ transmission |
| Creeper | Optional |
| Reverser | Mechanical left-hand reverser |
Machine Configuration
| Wheel or Track Configuration | Wheel |
| Drive Type | 4WD |
Additional Information
| Country of Manufacture | Mexico |
Front Hitch
| Front Hitch Category | 3N |
| Electric Power | Seven‑pin electrical socket |
Tires
| Rear Tires Size | 600/65R38 (175) |
