Features

Turn Application Data Into Confident Decisions

Wide view of a green agricultural sprayer driving through a large, neatly planted field, with long rows of crops stretching into the distance under a clear blue sky

Application doesn’t end at the field - it continues with the insights you gain. John Deere Operations Center connects your machines and data, giving you near real-time visibility into job progress, performance, and outcomes. With clear records and actionable insights, you can verify results, make informed adjustments, and continuously improve your application strategy for stronger performance season after season.

Stay Ahead of the Application Window

Large green agricultural sprayer with wide extended booms applying liquid across a dense, leafy crop field, with fine mist spraying onto the plants under an overcast sky

Application timing can make or break yield potential, but unpredictable weather and tight windows make it difficult to execute at the right moment. John Deere application solutions help you stay prepared and ready, with integrated technology and equipment that streamline setup, reduce delays, and keep you moving - so you can apply when conditions are right and protect crop performance across every acre.

Make Every Drop and Pass Count

Two people standing in a green crop field look at a smartphone together, while a large green agricultural sprayer with yellow wheels is parked nearby under a partly cloudy sky

Achieving consistent results across every acre requires precision you can trust. John Deere application equipment and technology deliver uniform coverage, accurate placement, and reliable rate control - helping ensure every pass is productive. By reducing overlap, minimizing waste, and maximizing efficiency, you can cover more acres per day while protecting inputs and maintaining high-quality application results.

Specifications

Capacity

Capacity Without Second Product Bin300 cu ft
Capacity Without Second Product Bin8.5 m³
Capacity With Second Product Bin162 cu ft
Capacity With Second Product Bin4.59 m³
Capacity Of Second Product Bin106 cu ft
Capacity Of Second Product Bin3 m³

Dimensions

Feedgate Height5 in.
Feedgate Height12.7 cm
Body Length132 in.
Body Length335.3 cm
Body Length - With Spinner Frame172 in.
Body Length - With Spinner Frame437.5 cm
Body Length Of Second Bin Insert60 in.
Body Length Of Second Bin Insert152.4 cm
Body Width120 in.
Body Width304.8 cm
Body Width - With Spinner Frame127 in.
Body Width - With Spinner Frame321.6 cm
Body Height68.77 in.
Body Height174.7 cm

Spread width range

Spread Pattern Width With Single-Product Bin60 to 105 ft
Spread Pattern Width With Single-Product Bin18.3 to 32 m
Spread Pattern Width With Second-Product Bin60 to 84 ft
Spread Pattern Width With Second-Product Bin18.3 to 25.6 m

Weight

Estimated Spreader Weight3740 lb.
Estimated Spreader Weight1696 kg
Second Product Bin Weight1120 lb.
Second Product Bin Weight508 kg

Application system

Compatible Series612R and 616R Self-Propelled Sprayers and 600R Dry Spinner Spreader
Product SpreadDry fertilizer
Second Product BinOptional
Spreader Material304 or painted 409 stainless steel
Conveyor System#4 belt over chain

Spinner

Disk Diameter24 in.
Disk Diameter61 cm
Fins Per Disk4

Additional Information

Date Collected2021-03-01
