Features
Turn Application Data Into Confident Decisions
Application doesn’t end at the field - it continues with the insights you gain. John Deere Operations Center connects your machines and data, giving you near real-time visibility into job progress, performance, and outcomes. With clear records and actionable insights, you can verify results, make informed adjustments, and continuously improve your application strategy for stronger performance season after season.
Stay Ahead of the Application Window
Application timing can make or break yield potential, but unpredictable weather and tight windows make it difficult to execute at the right moment. John Deere application solutions help you stay prepared and ready, with integrated technology and equipment that streamline setup, reduce delays, and keep you moving - so you can apply when conditions are right and protect crop performance across every acre.
Make Every Drop and Pass Count
Achieving consistent results across every acre requires precision you can trust. John Deere application equipment and technology deliver uniform coverage, accurate placement, and reliable rate control - helping ensure every pass is productive. By reducing overlap, minimizing waste, and maximizing efficiency, you can cover more acres per day while protecting inputs and maintaining high-quality application results.
Specifications
Dimensions & Weights
| Crop Clearance | 188 cm |
| Crop Clearance | 74 in. |
| Wheelbase | 386 cm |
| Wheelbase | 152 in. |
| Turning Radius | With Four-Wheel Steer on: 17.3 ft (5.3 m); With Four-Wheel Steer off (center of outside tire): 25.6 ft (7.8 m) |
| Total Weight With 36-m Steel Boom (Empty Solution Tank) | 15377 kg |
| Total Weight With 120-ft Steel Boom (Empty Solution Tank) | 33900 lb. |
| Total Weight With 36-m Steel Boom (Solution Tank Filled With Water) | 19916 kg |
| Total Weight With 120-ft Steel Boom (Solution Tank Filled With Water) | 43908 lb. |
Solution System
| Solution Tank Capacity | 4542 L |
| Solution Tank Capacity | 1200 gal. |
| Fill Pump Capacity | 1136 L/min |
| Fill Pump Capacity | 300 gpm |
| Application Pump Capacity | 757 L/min |
| Application Pump Capacity | 200 gpm |
| Solution Tank Material | Stainless steel |
| Rinse Tank Capacity | 454 L |
| Rinse Tank Capacity | 120 gal. |
| Quick Fill Size | 7.6 cm |
| Quick Fill Size | 3 in. |
| Rate Control Make | John Deere |
| Nozzle Control Technology | ExactApply™ |
| Solution System Control | SprayStar™ |
| Fill Location | Standard: Side and Front |
| Chemical Eductor Material | Poly |
| Chemical Eductor Capacity (Size) | 19 L |
| Chemical Eductor Capacity (Size) | 5 gal. |
| Pressure Strainer | 50 mesh |
| Boom Strainer | 80 mesh |
| Chemical Injection Method | John Deere ExactInject™ |
Capacities
| Fuel Tank Capacity | 511 L |
| Fuel Tank Capacity | 135 gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 29 L |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 7.7 gal. |
| Hydraulic Reservoir Capacity | 113.6 L |
| Hydraulic Reservoir Capacity | 30 gal. |
Steering & Brakes
| Parking Brake | Integrated in final drives |
| Primary Brakes | Drive system dynamic braking |
| Four-Wheel Steer Available | Standard |
Transmission
| Transmission Type | CommandDrive™ hydrostatic transmission |
| Shifting | Infinitely variable - Operator programmable |
| Spray Speed Range | 0.8-40 km/h |
| Spray Speed Range | 0.5-25 mph |
| Maximum Transport Speed | 35 mph (56 km/h) |
Chassis
| Frame Type | Modular ladder frame |
| Dry Compatible | Montag® Fortifier |
| Dry Compatible - Size | 5.1 m³ |
| Dry Compatible - Size | 180 cu ft |
| Suspension | Independent air-ride |
| Ladder Raise/Lower | Cab entry: Hydraulic; Service platform: Manual |
| Tread Adjust | Hydraulic |
Boom
| Boom Length Options | 60/90, 60/100, 60/120, or 70/132 ft (18/27, 18/30, 18/36, or 21/40 m) |
| Boom Height Control | BoomTrac Pro 2 |
| Sprayline Material | Stainless steel |
| Boom Material Options | Hybrid - Steel and Aluminum |
| Boom Height Range | 58-272 cm |
| Boom Height Range | 23-107 in. |
| Boom Sections | On 90-ft (27-m) boom: 7 sections On 100-, 120-, and 132-ft (30-, 36-, and 40-m) booms: 9 sections |
| Nozzle Spacings | 38, 51 cm (27/30/36/40 m. booms); 56 cm only on 40 m boom cm |
| Nozzle Spacings | 15, 20 in. (90/100/120/132 ft booms); 22 in. only on 132 ft boom in. |
Miscellaneous
| Pressure Washer | Optional |
| Foam Marker Capacity | 3.79 L, 1 gal. Concentrate |
Engine
| Engine Make | John Deere |
| Emissions Certifications | Final Tier 4 (FT4) |
| Rated Engine Power | 221 kW |
| Rated Engine Power | 300 hp |
| Power Bulge | 22.1 kW |
| Power Bulge | 30 hp |
| Maximum Engine Power | 243 kW |
| Maximum Engine Power | 330 hp |
| Number of Cylinders | 6 |
| Displacement | 9 L |
| Displacement | 548 cu in. |
Electrical System
| Alternator Capacity | 300 amp |
Technology Integration
| Guidance | AutoTrac™ |
| Secondary Display | G5Plus Extended Monitor |
| Receiver | StarFire™ 7500 |
| Connectivity | JDLink™ |
| Remote Diagnostics | JDLink™ |
Additional Information
| Date Collected | 2026-01-26 |
Machine Configuration
| Drive Type | Full-time four-wheel drive (4WD) |
Tires
| Front Tires Size | VF320/105R54, VF380/90R54, VF380/105R50, VF420/95R50, VF480/80R50 |
| Rear Tires Size | VF320/105R54, VF380/90R54, VF380/105R50, VF420/95R50, VF480/80R50 |
| Flotation Tires | VF480/80R50, IF710/65R46 |
| Wheel Tread Range | Hydraulic |
Hydraulics
| Traction Drive Pump | CommandDrive™ |
Operator Station
| Primary Display | G5 Plus |
