Features
Turn Application Data Into Confident Decisions
Application doesn’t end at the field - it continues with the insights you gain. John Deere Operations Center connects your machines and data, giving you near real-time visibility into job progress, performance, and outcomes. With clear records and actionable insights, you can verify results, make informed adjustments, and continuously improve your application strategy for stronger performance season after season.
Stay Ahead of the Application Window
Application timing can make or break yield potential, but unpredictable weather and tight windows make it difficult to execute at the right moment. John Deere application solutions help you stay prepared and ready, with integrated technology and equipment that streamline setup, reduce delays, and keep you moving - so you can apply when conditions are right and protect crop performance across every acre.
Make Every Drop and Pass Count
Achieving consistent results across every acre requires precision you can trust. John Deere application equipment and technology deliver uniform coverage, accurate placement, and reliable rate control - helping ensure every pass is productive. By reducing overlap, minimizing waste, and maximizing efficiency, you can cover more acres per day while protecting inputs and maintaining high-quality application results.
Specifications
Dimensions & Weights
| Crop Clearance | 147.3 cm |
| Crop Clearance | 58 in. |
| Crop Clearance (Standard) | 147 cm |
| Crop Clearance (Standard) | 58 in. |
| Wheelbase | 430 cm |
| Wheelbase | 169.3 in. |
| Turning Radius | 9.2 m / 30.2 ft |
| Total Weight With 36-m Steel Boom (Empty Solution Tank) | 17225 kg |
| Total Weight With 120-ft Steel Boom (Empty Solution Tank) | 37974 lb. |
Solution System
| Solution Tank Capacity | 6057 L |
| Solution Tank Capacity | 1600 gal. |
| Solution Tank Material | Stainless steel |
| Split Tank Option | Tank 1: 600 gal. (2,271L); Tank 2: 1,000 gal. (3,785 L) |
| Rinse Tank Capacity | 606 L |
| Rinse Tank Capacity | 160 gal. |
| Quick Fill Size | 7.6 cm |
| Quick Fill Size | 3 in. |
| Rate Control Make | John Deere Section Control (optional) |
| Solution System Control | Automatic Solution Control (ASC) with optional Pressure Recirculation & Product Reclaim and optional ASC Premium with Pressure Recirculation & Product Reclaim |
| Fill Location | Side fill, front fill (optional) |
| Chemical Eductor Material | Stainless steel |
| Chemical Eductor Capacity (Size) | 32 L |
| Chemical Eductor Capacity (Size) | 8.5 gal. |
| Suction Strainer | 20 mesh |
| Pressure Strainer | 50 mesh |
| Boom Strainer | 80 mesh |
| See & Spray Gen 2 | 90, 100, 120, 132 ft |
| See & Spray Gen 2 | 27.4, 30.5, 36.6, 40.2 m |
| Chemical Injection Method | Raven Direct Injection System |
Capacities
| Fuel Tank Capacity | 565 L |
| Fuel Tank Capacity | 149.2 gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 29.5 L |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 7.8 gal. |
| Hydraulic Reservoir Capacity | 98.4 L |
| Hydraulic Reservoir Capacity | 26 gal. |
Steering & Brakes
| Parking Brake | Spring-engaged, hydraulically disengaged wet disk pack |
| Primary Brakes | Hydrostatic |
Transmission
| Transmission Type | Hydrostatic, Full-time four-wheel drive (4WD) |
| Shifting | Infinitely Variable – Operator Programmable |
| Spray Speed Range | 0 - 40.2 km/h |
| Spray Speed Range | 0 - 25 mph |
| Maximum Transport Speed | 56.3 km/h / 35 mph |
Chassis
| Dry Compatible | Yes: 200 or 300 cu ft (5.7 or 8.5 m³) |
| Dry Compatible - Size | 5.7 / 8.5 m³ |
| Dry Compatible - Size | 200 / 300 cu ft |
| Suspension | Dual-strut independent wheel air-ride suspension |
| Ladder Raise/Lower | Hydraulic |
| Tread Adjust | Hydraulic |
Boom
| Boom Length Options | Steel: 90, 100, or 120 ft (27.4, 30.5, or 36.5 m) / Carbon Fiber: 120 or 132 ft (36.5 or 40 m) |
| Boom Height Control | BoomTrac Pro 2 - five sensor (optional) |
| Sprayline Material | Stainless or polypropylene |
| Boom Material Options | Steel or carbon fiber |
| Boom Height Range | 50 - 245 cm |
| Boom Height Range | 19.6 - 96.5 in. |
| Boom Sections | 15 sections (nozzle control), 13 sections with boom length: 132 ft (40.2 m), 11 sections with boom length: 120 ft (36.6 m), 9 sections with boom length: 100 ft (30.5 m), 7 sections with boom length: 90 ft (27.4 m) |
| Nozzle Spacings | 38.1 / 50.8 cm |
| Nozzle Spacings | 15 / 20 in. |
Engine
| Engine Make | John Deere |
| Engine Model | Tier IV/ Stage V |
| Emissions Certifications | Final Tier 4 (FT4) |
| Rated Engine Power | 280 kW |
| Rated Engine Power | 375 hp |
| Maximum Engine Power | 309 kW |
| Maximum Engine Power | 415 hp |
| Number of Cylinders | 6 |
| Displacement | 9 L |
| Displacement | 549 cu in. |
Additional Information
| Date Collected | 2021-03-01 |
Machine Configuration
| Drive Type | CommandDrive™ - Hydrostatic full-time four-wheel drive (4WD) |
Tires
| Front Tires Size | 380/105 R50, 420/95 R50, or 480/80 R50 |
| Rear Tires Size | 380/105 R50, 420/95 R50, or 480/80 R50 |
| Flotation Tires | 620/70 R46 or 800/55 R46 |
| Wheel Tread Range | 305 to 406.4 cm / 120 to 160 in |
Miscellaneous
| Foam Marker Capacity | Injection foamer |
