Features

Turn Application Data Into Confident Decisions

Wide view of a green agricultural sprayer driving through a large, neatly planted field, with long rows of crops stretching into the distance under a clear blue sky

Application doesn’t end at the field - it continues with the insights you gain. John Deere Operations Center connects your machines and data, giving you near real-time visibility into job progress, performance, and outcomes. With clear records and actionable insights, you can verify results, make informed adjustments, and continuously improve your application strategy for stronger performance season after season.

Stay Ahead of the Application Window

Large green agricultural sprayer with wide extended booms applying liquid across a dense, leafy crop field, with fine mist spraying onto the plants under an overcast sky

Application timing can make or break yield potential, but unpredictable weather and tight windows make it difficult to execute at the right moment. John Deere application solutions help you stay prepared and ready, with integrated technology and equipment that streamline setup, reduce delays, and keep you moving - so you can apply when conditions are right and protect crop performance across every acre.

Make Every Drop and Pass Count

Two people standing in a green crop field look at a smartphone together, while a large green agricultural sprayer with yellow wheels is parked nearby under a partly cloudy sky

Achieving consistent results across every acre requires precision you can trust. John Deere application equipment and technology deliver uniform coverage, accurate placement, and reliable rate control - helping ensure every pass is productive. By reducing overlap, minimizing waste, and maximizing efficiency, you can cover more acres per day while protecting inputs and maintaining high-quality application results.

Specifications

Solution System

Solution Tank Capacity3800 L
Solution Tank Capacity1000 gal.
Solution Tank MaterialStainless Steel
Rinse Tank Capacity454.2 L
Rinse Tank Capacity120 gal.
Quick Fill Size7.6 cm
Quick Fill Size3 in.
Solution System ControlAutomatic Solution Control (ASC) with optional Pressure Recirculation & Product Reclaim and optional ASC Premium with Pressure Recirculation & Product Reclaim
Fill LocationSide fill, front fill (optional)
Chemical Eductor Capacity (Size)32 L
Chemical Eductor Capacity (Size)8.5 gal.
Suction Strainer20 mesh
Pressure Strainer50 mesh
Boom Strainer80 mesh
See & Spray Gen 290, 100, 120 ft
See & Spray Gen 227.4, 30.5, 36.6 m
Chemical Injection MethodExactInject™ Direct Injection System

Steering & Brakes

Parking BrakeSpring-engaged, hydraulically disengaged wet disk pack
Primary BrakesHydrostatic
Four-Wheel Steer AvailableYes

Dimensions & Weights

Crop Clearance (Standard)152 cm
Crop Clearance (Standard)60 in.
Wheelbase430 cm
Wheelbase169.3 in.
Turning Radius28.5 ft (8.7 m) with optional 4WS: 18.5 ft (5.6 m)

Capacities

Hydraulic Reservoir Capacity98 L
Hydraulic Reservoir Capacity26 gal.

Engine

Engine ModelTier IV/ Stage V
Rated Engine Power231 kW
Rated Engine Power310 hp
Maximum Engine Power246 kW
Maximum Engine Power330 hp
Number of Cylinders6
Displacement9 L
Displacement549 cu in.

Chassis

Dry CompatibleYes: 200 cu ft (5.7 m³)
SuspensionDual-strut independent wheel air-ride suspension
Ladder Raise/LowerAutomatic

Boom

Boom Length Options90, 100, 120, or 132 ft (27.4, 30.5, 36.5, or 40 m)
Boom Height ControlBoomTrac™ Pro 2 – five sensor (optional)
Boom Material OptionsSteel or carbon fiber
Boom Sections15 sections (nozzle control), 13 sections with boom length: 132 ft (40.2 m), 11 sections with boom length: 120 ft (36.6 m), 9 sections with boom length: 100 ft (30.5 m), 7 sections with boom length: 90 ft (27.4 m)
Nozzle Spacings38.1 / 50.8 cm
Nozzle Spacings15 / 20 in.

Miscellaneous

Foam Marker CapacityAir injection foamer: 5.7 L 1.5 gal

Tires

Flotation Tires520/85R38 or 620/70R38 (field installed only)

Transmission

ShiftingElectrohydraulic
