Features

Turn Application Data Into Confident Decisions

Wide view of a green agricultural sprayer driving through a large, neatly planted field, with long rows of crops stretching into the distance under a clear blue sky

Application doesn’t end at the field - it continues with the insights you gain. John Deere Operations Center connects your machines and data, giving you near real-time visibility into job progress, performance, and outcomes. With clear records and actionable insights, you can verify results, make informed adjustments, and continuously improve your application strategy for stronger performance season after season.

Stay Ahead of the Application Window

Large green agricultural sprayer with wide extended booms applying liquid across a dense, leafy crop field, with fine mist spraying onto the plants under an overcast sky

Application timing can make or break yield potential, but unpredictable weather and tight windows make it difficult to execute at the right moment. John Deere application solutions help you stay prepared and ready, with integrated technology and equipment that streamline setup, reduce delays, and keep you moving - so you can apply when conditions are right and protect crop performance across every acre.

Make Every Drop and Pass Count

Two people standing in a green crop field look at a smartphone together, while a large green agricultural sprayer with yellow wheels is parked nearby under a partly cloudy sky

Achieving consistent results across every acre requires precision you can trust. John Deere application equipment and technology deliver uniform coverage, accurate placement, and reliable rate control - helping ensure every pass is productive. By reducing overlap, minimizing waste, and maximizing efficiency, you can cover more acres per day while protecting inputs and maintaining high-quality application results.

Specifications

Chassis

Dry Compatible - Capacity200 cu ft
Dry Compatible - Capacity5.6 m³
SuspensionDual-strut independent wheel air-ride suspension
Crop Clearance With Standard Tires60 in.
Crop Clearance With Standard Tires152.4 cm
Front Tires320/90 R46, 380/90 R46, or 420/80 R46
Rear Tires320/90 R46, 380/90 R46, or 420/80 R46
Flotation Tires520/85R38 or 620/70R38 (field installed only)
Hydraulic Tread AdjustStandard
Wheel Tread Spacing120 to 160 in.
Wheel Tread Spacing305 to 406.4 cm
Wheelbase169.3 in.
Wheelbase430 cm
Turning Radius28.5 ft
Turning Radius8.7 m
Parking BrakeSpring-engaged, hydraulically disengaged wet disk pack
Primary BrakesHydrostatic
Ladder Raise/LowerAutomatic
Weight (Empty) - With DS2026636 lb.
Weight (Empty) - With DS2012082 kg

Engine

Engine MakeFinal Tier 4/ Stage V / PowerTech™ Plus
Rated Engine Power326 hp
Rated Engine Power243 kW
Maximum Engine Power382 hp
Maximum Engine Power285 kW
Number Of Cylinders6
Displacement549 cu in.
Displacement9 L
Fuel Tank Capacity149.2 gal.
Fuel Tank Capacity565 L
Diesel Exhaust Fluid (DEF) Tank Capacity7.8 gal.
Diesel Exhaust Fluid (DEF) Tank Capacity29.5 L

Drybox

Spread Width60 -105 ft
Spread Width18.6 - 32 m

Drivetrain

TypeCommandDrive™ - Hydrostatic 4WD
DriveFull-time, four-wheel drive (4WD)
ShiftingInfinitely Variable – Operator Adjustable
Hydraulic Reservoir Capacity26 gal.
Hydraulic Reservoir Capacity98.4 L
Spread Speed Range0 to 25 mph
Spread Speed Range0 to 40.2 km/h
Maximum Transport Speed35 mph
Maximum Transport Speed56.3 km/h
