Features

Turn Application Data Into Confident Decisions

Wide view of a green agricultural sprayer driving through a large, neatly planted field, with long rows of crops stretching into the distance under a clear blue sky

Application doesn’t end at the field - it continues with the insights you gain. John Deere Operations Center connects your machines and data, giving you near real-time visibility into job progress, performance, and outcomes. With clear records and actionable insights, you can verify results, make informed adjustments, and continuously improve your application strategy for stronger performance season after season.

Stay Ahead of the Application Window

Large green agricultural sprayer with wide extended booms applying liquid across a dense, leafy crop field, with fine mist spraying onto the plants under an overcast sky

Application timing can make or break yield potential, but unpredictable weather and tight windows make it difficult to execute at the right moment. John Deere application solutions help you stay prepared and ready, with integrated technology and equipment that streamline setup, reduce delays, and keep you moving - so you can apply when conditions are right and protect crop performance across every acre.

Make Every Drop and Pass Count

Two people standing in a green crop field look at a smartphone together, while a large green agricultural sprayer with yellow wheels is parked nearby under a partly cloudy sky

Achieving consistent results across every acre requires precision you can trust. John Deere application equipment and technology deliver uniform coverage, accurate placement, and reliable rate control - helping ensure every pass is productive. By reducing overlap, minimizing waste, and maximizing efficiency, you can cover more acres per day while protecting inputs and maintaining high-quality application results.

Specifications

Engine

Peak Rated Engine Power173 hp
Peak Rated Engine Power129 kW
EmissionsFinal Tier 4 (FT4)/Stage V
Number Of Cylinders4
Displacement275 cu in.
Displacement4.5 L
Alternator120 amp
Fuel Tank Capacity90 gal.
Fuel Tank Capacity340.7 L
Diesel Exhaust Fluid (DEF) Tank Capacity5.7 gal.
Diesel Exhaust Fluid (DEF) Tank Capacity21.6 L

Detasseling toolbar

Toolbar Outriggers - 12-Row134 in.
Toolbar Outriggers - 12-Row340.4 cm
Row Configurations12
Detasseling Control SystemTasseltrol
Cutter Height Range28.5 to 101.5 in / 72.4 to 257.8 cm
Puller Height Range24.8 to 97.8 in / 62.9 to 248.4 cm
Quad Puller Operating Speed450 rpm
Cutter Operating Speed2800 rpm

Drivetrain

TypeHydrostatic
DriveFull-time four-wheel drive (4WD)
ShiftingDual speed range
Hydraulic Reservoir Capacity17.25 gal.
Hydraulic Reservoir Capacity65.3 L
Detasseling Speed Range0 to 13 mph
Detasseling Speed Range0 to 20.9 km/h
Detasseling Speed Range - Low Range0 to 10 mph
Detassling Speed Range - Low Range0 to 16.1 km/h
Detasseling Speed Range - High Range0 to 13 mph
Detasseling Speed Range - High Range0 to 20.9 km/h
Maximum Transport Speed13 mph
Maximum Transport Speed20.9 km/h

Detasseling configuration options

Option 1Quad puller - 12 Row 6 Lift
Option 2Cutter - 12 Row 6 Lift

Chassis

Dry CompatibleNo
SuspensionIndependent air-ride
Crop Clearance With Standard Tires77 in.
Crop Clearance With Standard Tires195.6 cm
Front TiresTitan® 12.4 x 38
Rear TiresTitan 12.4 x 38
Hydraulic Tread AdjustManual only
Wheel Tread Spacing100 to 120 in.
Wheel Tread Spacing254 to 304.8 cm
Wheelbase121 in.
Wheelbase307.3 cm
Turning Radius18 ft
Turning Radius5.5 m
Parking BrakeIntegrated in final drives
Primary BrakesDrive system dynamic braking
Ladder Raise/LowerFixed ladder
Approximate Dry Weight15357 lb.
Approximate Dry Weight6965.8 kg

Cab

Glass58.7 sq ft
Glass5.45 m²
SeatAir suspension
Instructional SeatStandard
Windshield WiperSingle blade

Additional Information

Date Collected2023-08-23
