Features
Put Product Where You Intend - Even in Varying Fields
Every pound counts. Precision metering, section control, and curve compensation help reduce skips, overlap, and guesswork - so you can trust what you’re placing, protect your investment, and feel confident you didn’t miss acres when the day gets long and the field gets awkward.
Bigger Options for Bigger Days: New XL C‑Series Carts
Some operations measure success in acres per day, not stops per hour. The C‑Series lineup now expands to the new XL carts - C1100T and C1450T - built for long run time and high productivity when your window is tight and your acres are anything but small.
Stay Seeding Longer Between Tender Stops
When the weather finally breaks, you don’t want to spend it refilling. John Deere air carts are built to keep the drill moving with more acres per fill and better visibility to what’s left - so you can push through the good conditions, not waste them waiting on the tender truck.
Specifications
Conveyance
| Conveyor Belt Width | 16 in. |
| Conveyor Belt Width | 40.6 cm |
| Conveyor Tube Diameter | 10 in. |
| Conveyor Tube Diameter | 25.4 cm |
| Conveyor Capacity (Wheat) | 66 buMin |
| Conveyor Capacity (Wheat) | 2325.8 L/min |
| Auger Diameter | 10 in. |
| Auger Diameter | 25.4 cm |
| Auger Capacity (Wheat) | 49 buMin |
| Auger Capacity (Wheat) | 1726.72 L/min |
Tires
| Front Tires- Base Equipment | 21.5L-16.1 I-3T 8PR (Duals) |
| Front Tires- High Flotation Option | 650/50R22.5 885 I-3 163D (Duals) |
| Front Tires- 3M Wheel Tread Option | 650/50R22.5 885 I-3 163D (Singles) |
| Front Tires- Row Crop Option | 16.5L-16.1 I-3T 6PR (Duals) |
| Rear Tires- Base Equipment | 710/70R-38R1W (Singles) |
| Rear Tires- High Flotation Option | 650/85R38 173B R-1W FS (Duals) |
| Rear Tires- 3M Wheel Tread Option | 710/70R-38R1W (Singles) |
| Rear Tires- Row Crop Option | 18.4R-42 R1 153A8 (Duals) |
Dimensions
| Height (Transport) | 13.17 ft |
| Height (Transport) | 4 m |
| Height (Field) | 13.75 ft |
| Height (Field) | 4.2 m |
| Length Overall | 27.08 ft |
| Length Overall | 8.27 m |
| Length (Hitch Pin to Axle) | 18 ft |
| Length (Hitch Pin to Axle) | 5.49 m |
| Width With Base Equipment Tires | 13.75 ft |
| Width With Base Equipment Tires | 4.2 m |
| Width With High Flotation Tires | 17.5 ft |
| Width With High Flotation Tires | 5.34 m |
| Width With 3M Tire Option | 12.33 ft |
| Width With 3M Tire Option | 3.75 m |
| Ground Clearance (Empty) | 27 in. |
| Ground Clearance (Empty) | 68.8 cm |
Cart Capacity
| Total | 350 bu |
| Total | 12333.68 L |
| Number of Tanks | 2 |
| Tank Splits | 160, 190 bu |
| Tank Splits | 5638.25, 6695.42 L |
Metering
| Number of Meters | 6 or 8 per tank |
| Meter Housing Material | Stainless steel |
| Type | Individual motor control per primary |
| Metering Drive | Electric: 56 V |
Air System
| Blower Options | Standard capacity |
| Number of Blowers | Single or dual |
| Max Meter Delivery Rate Per Blower - Standard Capacity Blower | 345 lb/acre |
| Max Meter Delivery Rate per Blower - Standard Capacity Blower | 386.7 kgPerHa |
| Drive | Hydraulic, per blower: up to 98.4 L/min (26 gpm) |
| Product Delivery Hoses | 2.5 in. |
| Product Delivery Hoses | 6.35 cm |
Shipping Weight
| Base Equipment | 16305 lb. |
| Base Equipment | 7396 kg |
| Shipping Weight - High Flotation Option | 19987 lb. |
| Shipping Weight - High Flotation Option | 9066 kg |
| 3M Wheel Tread Option | 15911 lb. |
| 3M Wheel Tread Option | 7217 kg |
| Row Crop Option | 17782 lb. |
| Row Crop Option | 8066 kg |
Additional Information
| Date Collected | 2024-02-28 |
