Features
Uniform Placement, Built Into the Tool
With features like dual knife openers and engineered placement consistency, John Deere air drills help keep seed and fertilizer placement steady across the machine—so your crop starts more evenly and you can feel good about what you put in the ground, acre after acre.
Place Seed and Fertilizer With Confidence, Not Hope
Air drilling is about repeatability. John Deere air drills are built for consistent placement and the kind of even start you can see at emergence—helping protect yield potential when timing is tight and you need every pass to count the first time.
Know It’s Flowing - So You Can Keep Rolling
You shouldn’t have to stop to wonder if product is making it to the ground. RelativeFlow™ blockage monitoring helps you spot problems from the cab and address them early—so you avoid thin streaks, protect the stand, and keep momentum when the window is short.
Specifications
Drive System
| Base | Electric drive: 56 V |
Additional Information
| Recommended Tractor Horsepower | 8030, 8R, 8RX, 8030T, and 8RT Series Tractor (power take-off [PTO] power of 183 kW [245 hp] or more); 3-point lift capacity of greater than 6700 kg (14,775 lb) minimum; Three or four selective control valves (SCVs) for power beyond, load sense, and case drain hydraulic connections are required, depending on machine options; SCV 1 – wing downforce/gull wing (when equipped), SCV 2 – fold/unfold, SCV 3 – CCS, SCV 4 – vacuum; Power beyond – Individual Row Hydraulic Downforce (IRHD), ExactRate™ fertilizer, or PDF compressor with load sense; Load sense – IRHD, ExactRate fertilizer, or PDF compressor with load sense; Case drain – vacuum or PDF compressor with load sense Independent-Link Suspension (ILS™) or 1500 mechanical front-wheel drive (MFWD) tractor front axle required; Rear duals and full set of front weight |
| Recommended Tractor Hydraulics | Hydraulic oil required to operate the planter: 227 L/min (60 gpm); Hydraulic system standby pressure: 15,513 kPa (155 bar) (2250 psi); Hydraulic system working pressure: 20,684 kPa (207 bar) (3000 psi); Hydraulic system burst pressure: 82,737 kPa (827 bar) (12,000 psi) |
Rows and Row Spacing
| Number Of Rows | 12 |
| Row Spacing | 30 in. |
| Row Spacing | 76.2 cm |
Seed Meters
| Base Seed Meter | Vacuum |
| Central Commodity System (CCS) | Yes |
| CCS Seed Capacity | 55 bu |
| CCS Seed Capacity | 1938 L |
Row Units
| Type | ExactEmerge™ row units |
| Opener | Tru-Vee Double Disk |
| Row Unit Seed Hoppers | Not available |
| Row Unit Down Force | Individual Row Hydraulic Downforce (IRHD) |
Dimensions
| Transport Width (Without Markers) | 17.92-22.17 ft |
| Transport Width (Without Markers) | 5.5-6.8 m |
| Transport Height | 5.17-13.17 ft |
| Transport Height | 1.6-4.01 m |
| Transport Underframe Clearance | 13.2 ft |
| Transport Underframe Clearance | 4 m |
Frame
| Frame Fold Configuration | Vertical fold |
| Frame Flexibility - Up | 10 degree (angle) |
| Frame Flexibility - Down | 7 degree (angle) |
Lift System
| Type | Semi-integral only |
Tires
| Base | 12.5L-15SL 20 ply implement: 303 kPa 3.0 bar 44 psi; 7.60-15 8 ply implement: 359 kPa 3.6 bar 52 psi; 7.6-15 6 ply - traction: 276 kPa 2.8 bar 40 psi |
Seed Monitor System
| Base | SeedStar™ 5 |
