Features
Master Your Planting Window
Hitting the right window can add 4–10 bu./acre to yield, making timely field access critical. John Deere solutions like ExactEmerge™ deliver fast, accurate planting at speeds up to 10 mph, supporting uniform emergence. EasyStart and the 56V Tractor Power Tether Harness help streamline setup and get you planting faster.
Uniform Stands. Maximum Seed Potential
Uneven emergence drives inter-plant competition and reduces yield potential, making consistent seed depth critical. Solutions like ExactDepth™ ensure precise placement, while FurrowVision™ and Easy Adjust Row Cleaners improve residue management. Downforce Automation helps maintain optimal pressure to prevent compaction or furrow collapse.
Feed the Seed
Proper nutrient management can boost yields by 10–15 bu./acre (870.8–1,306.2 L/ha)1, supported by solutions like ExactShot™, which places nutrients precisely in the furrow— both supporting your best yield outcomes and cutting in-furrow nutrient costs up to 60%2.
Specifications
Drive System
| Base | Hydraulic variable rate drive |
Row Units
| Type | Standard: MaxEmerge™ 5 row units; Optional: ExactEmerge™ row units MaxEmerge 5e row-units |
| Opener | Tru-Vee™ double disk |
| Seed Hopper Capacity | 0.062 bu |
| Seed Hopper Capacity | 2.2 L |
Dimensions
| Transport Width (With Markers) | 13.27 ft |
| Transport Width (With Markers) | 4.043 m |
| Transport Length | 34.2 ft |
| Transport Length | 10.425 m |
| Transport Height | 13.37 ft |
| Transport Height | 4.075 m |
| Field Operation Width | 43.35 ft |
| Field Operation Width | 13.212 m |
| Field Operation Length | 25.96 ft |
| Field Operation Length | 7.913 m |
Additional Information
| Recommended Tractor Horsepower | Minimum required for 9.1 m (30 ft) models: 201 kW 270 hp; Minimum required for 12.2 m (40 ft) models: 268 kW 360 hp |
| Recommended Tractor Hydraulics | Hydraulic oil pump required to operate ExactEmerge™ planter: 227 L/min 60 gpm; Tractor standby pressure: 15,500 kPa 155 bar (2300 psi); Hydraulic system working pressure: 20,684 kPa 207 bar (3000 psi); Hydraulic system burst pressure: 82,737 kPa 827 bar (12,000 psi) |
Fertilizer
| Tank Capacity | 420 gal. |
| Tank Capacity | 1590 L |
| ExactRate Fluid Transfer System | Available |
Rows and Row Spacing
| Number Of Rows | 24 |
| Row Spacing | 20 in. |
| Row Spacing | 51 cm |
Seed Meters
| Base Seed Meter | Vacuum |
| CCS Seed Capacity - Without Liquid Tank | 130 bu |
| CCS Seed Capacity - Without Liquid Tank | 4581 L |
| CCS Seed Capacity - With Liquid Tank | 100 bu |
| CCS Seed Capacity - With Liquid Tank | 3524 L |
Lift System
| Type | Wheel modules with rephasing hydraulic cylinders |
Frame
| Frame Flexibility - Up | 15 degree (angle) |
| Frame Flexibility - Down | 15 degree (angle) |
Tires
| Base | Wing tires: 7.50-20 6PR implement tire; Center tires: VF295/75R22.5 |
Seed Monitor System
| Base | SeedStar™ on GreenStar™ displays |
Markers
| Type | Automatic alternating or independent control |
