Features
StarFire™ 7500 Receiver
Provides ultimate pass-to-pass accuracy of +/- 1 in. as well as season-to-season repeatability with SF-RTK and RTK correction sources.
Section Control
Automatically turns individual nozzles on and off to increase spraying efficiency and accuracy.
G5ᴾˡᵘˢ Universal Display is Designed for Efficiency
The G5ᴾˡᵘˢ Universal Display improves efficiency with precise multi‑product application, fast processing, a high‑resolution screen, and integrated guidance and monitoring tools.
Specifications
Alternator
| Size, Amp | 55 amp |
Dimensions
| Ground Clearance (Unloaded) | 168 mm |
| Ground Clearance (Unloaded) | 6.6 in. |
| Bed Height (Loaded) | 832 mm |
| Bed Height (Loaded) | 32.75 in. |
| Wheelbase | 167.6 cm |
| Wheelbase | 66 in. |
| Wheel Tread, Front | 123.2 cm |
| Wheel Tread, Front | 48.5 in. |
| Wheel Tread, Rear Standard | 129 cm |
| Wheel Tread, Rear Standard | 50.8 in. |
| Width, Overall (Standard Tires) | 158.6 cm |
| Width, Overall (Standard Tires) | 62.4 in. |
| Length, Overall (Standard Tires) | 319.2 cm |
| Length, Overall (Standard Tires) | 125.7 in. |
| Length, Overall With Box | 328.5 cm |
| Length, Overall With Box | 129.3 in. |
| Length, Overall Without Box | 319.2 cm |
| Length, Overall Without Box | 125.7 in. |
| Height, Overall | 193.6 cm |
| Height, Overall | 76.25 in. |
Capacities
| 2WD With Standard Suspension | 2449 kg |
| 2WD With Standard Suspension | 5400 lb. |
| 4WD With Standard Suspension | 2449 kg |
| 4WD With Standard Suspension | 5400 lb. |
| 2WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS | 2841 kg |
| 2WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS | 6264 lb. |
| Maximum Gross Vehicle Weight - 4WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS | 2841 kg |
| Maximum Gross Vehicle Weight - 4WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS | 6264 lb. |
| Cargo Box Internal Dimensions - Length | 165 cm |
| Cargo Box Internal Dimensions - Length | 65 in. |
| Cargo Box Internal Dimensions - Width | 128.3 cm |
| Cargo Box Internal Dimensions - Width | 50.5 in. |
| Cargo Box Internal Dimensions - Height | 26.7 cm |
| Cargo Box Internal Dimensions - Height | 10.5 in. |
| Towing Capacity (Rear Hitch) | 680.4 kg |
| Towing Capacity (Rear Hitch) | 1500 lb. |
| Fuel Capacity | 30.3 L |
| Fuel Capacity | 8 U.S. gal. |
Battery
| Battery Voltage | 12 V |
| Battery Cold Crank Amps | 500 CCA |
Transmission
| Maximum Speed (Standard Tires) | 30.7 km/h |
| Maximum Speed (Standard Tires) | 19.1 mph |
Turning Circle Clearance
| Turning Circle Clearance - Inside Diameter - 2WD - Radius | 431.8 mm |
| Turning Circle Clearance - Inside Diameter - 2WD - Radius | 17 in. |
| Turning Circle Clearance - Inside Diameter - 4WD - Radius | 1752 mm |
| Turning Circle Clearance - Inside Diameter - 4WD - Radius | 69 in. |
Engine
| Horsepower | 17.8 kW |
| Horsepower | 23.9 hp |
| High Idle Speed | 3450 rpm |
| Displacement | 1267 cc |
| Displacement | 77.3 cu in. |
Sound Level
| At Operator's Ear | 86 dBA |
