Features
eHydro™ Hydrostatic Pump and Standard GRIP AWD for Serious Hill-Climbing Capabilities
The electronically-controlled eHydro™ traction pump powers wheel motors for enhanced performance and traction, especially in undulating terrain. This linkage-free design significantly reduces parts in the traction system and maintenance requirements. For even more capability in tougher conditions, the optional GRIP All-wheel Drive system provides power to the two rear wheels. This system transfers hydraulic fluid from wheels that slip to wheels that grip, increasing traction on both hills and side slopes.
AutoPedal™ Lowers Sound Levels and Fuel Consumption During Transport
The dual pedal traction system electronically controls both the eHydro™ transmission and engine RPMs during transport. By utilizing only the RPMs and ground speed commanded by the operator pressing the foot pedals in transport, this innovative system also reduces the engine RPM to idle when neither pedal is depressed. Linking the engine and traction speed to the foot pedal position maximizes fuel savings and reduces noise during transport.
Passcode-Protected TechControl Display Puts the Supervisor in Control
Set maximum mow speed, turn speed, and transport speed to assist in providing consistency of performance from operator to operator. These settings are passcode-protected within the TechControl display, putting the supervisor in more control of each operator's cut quality and performance. Achieve more consistency from machine to machine and from operator to operator for a more uniform appearance across the course.
Specifications
Dimensions
| Height With ROPS | 220 cm |
| Height With ROPS | 87 in. |
| Length | 282.5 cm |
| Length | 111 in. |
| Transport Width | Quick Adjust QA7 (with 66 cm [26 in.]): 2194 mm (86.38 in.); Quick Adjust QA7 (with 76 cm [30 in.]): 2385 mm (93.90 in.) |
| Mowing Position Width | QA7 (66 cm [26 in.]): 3275 mm (129 in.); QA7 (76 cm [30 in.]): 3695 mm (145 in.) |
| Wheelbase | 158.5 cm |
| Wheelbase | 62.4 in. |
| Ground Speed - Mowing | 12.8 km/h |
| Ground Speed - Mowing | 8 mph |
| Ground Speed - Transport | 19.2 km/h |
| Ground Speed - Transport | 12 mph |
| Ground Speed - Reverse | 9.6 km/h |
| Ground Speed - Reverse | 6 mph |
Controls
| Throttle | Automatic controls with AutoPedal foot controls; manual control through TechControl display |
| Forward/Reverse | 2-pedal |
| Mower Lift | One-touch single handle |
| Parking Brake | Electric switch on CommandARM for internal wet disk brakes |
| Seat | Air Ride suspension seat with seat belts and arm rest; fore/aft adjustment; weight and lumbar adjustment |
| PTO | Electric switch on CommandARM |
| Ignition | Key start |
| Work Lights | Standard 3 front work lights |
| Tilt Steering | Left foot operated for easy adjustment |
| Operator Display | TechControl Display: Located on CommandARM; displays machine warnings, on-board electrical diagnostics; service timers on large easy to read screen; quick on the go settings for mow and transport speed; Turn Speed; LoadMatch™ and ON/OFF Cruise Control Use selection: all settings are passcode protected |
| Storage | Cup holder; two-way radio located in CommandARM; large operator storage located on left hand side of operator station |
Cutting Units
| Number | 5 |
| Cutting Unit Size | Quick Adjust QA7: 66 or 76 cm (26 or 30 in.) |
| Cutting Width | 130 in. |
| Cutting Width | 330.2 cm |
| Height-Of-Cut | QA7: 6.3-50.8 mm (0.25-2.0 in.) |
| Frequency of clip (FOC Reels) OR Blade tip speed (decks) | 10 Blade: 1.06 mm/km/h (0.067 in./mph); 8 Blade: 1.33 mm/km/h (0.084 in./mph) |
| Rollers | Front and rear: 76.2 mm (3 in.) |
| Reel Diameter | 17.8 cm |
| Reel Diameter | 7 in. |
| Bedknife Adjustment | Reel to bedknife |
| Backlapping | Standard; pressure sensing flow compensating backlap valve; manual reel speed adjustment |
Vehicle
| Drive Pump | Tandem gear pump |
| Cutting Units Drive | Hydraulic motor to each cutting unit |
| Hydraulic System Capacity | 37.8 L |
| Hydraulic System Capacity | 10 U.S. gal. |
| Fuel Tank Capacity | 60.6 L |
| Fuel Tank Capacity | 16 U.S. gal. |
| Steering | Hydraulic power with double acting steering cylinder |
| Front Drive Tires | 26.5x14-12 turf |
| Steering Tires | 20x12X10-8 turf |
| Ground Pressure | 93 kPa |
| Ground Pressure | 12 psi |
| Brakes | Internal hydraulic wet disc brakes with dynamic braking through closed loop hydrostatic system |
| ROPS | Standard; meets ISO 21299 Standard |
Engine
| Type | Direct inject turbocharged diesel |
| Compliant Emission Regulation | Tier 4 |
| Maximum Engine Power | 2800 rpm |
| Maximum Engine Power | 41.1 kW |
| Maximum Engine Power | 55.1 hp |
| Cylinders | 4 |
| Displacement | 2.091 L |
| Displacement | 127.6 cu in. |
| Air Cleaner | 2-stage dry element |
| Fuel | Diesel up to B20 compliant |
| Cooling System | Liquid centrifugal pump; forward machine location for optimum cooling |
Warranty
| Type | Two-year limited |
Certification
| Type | ANSI B71.4-2012 |
Sound Levels
| Measuring Standard | ISO 11201 |
| Attachments Installed | FTCs, reels engaged |
Fuel Economy
| Actual Fuel Usage Will Vary Depending On Course Conditions, Operation, Turf And Fuel Quality | 25% load: 3.63 L/hr (0.96 gph); 40% load: 5.64 L/hr (1.49 gph); 50% load: 6.85 L/hr (1.81 gph) |
Operating Weight
| Cutting Units Lowered | Full fluids, no operator, 66-cm (26-in.) Quick Adjust QA7 cutting units lowered: 1239 kg (2725 lb); Full fluids, no operator, 76-cm (30-in.) Quick Adjust QA7cutting units lowered: 1270 kg (2795 lb) |
