Features
56-Volt, 240 amp Alternator Powers Brushless Electric Reel Motors
Providing excellent mowing and verticutting performance while completely eliminating any chances of hydraulic leaks from the reel circuit, the 56-V, 240 amp smart alternator powers a fully electric reel drive system. Belt-driven from the engine, the alternator ensures no additional batteries are needed to power the reel drive circuit.
Excellent Maneuverability and After Cut Appearance
A light stance with smooth tires sized to minimize ground pressure provides an after cut appearance similar to what you would normally expect from a triplex greens mower. The standard GRIP All-Wheel Drive traction system improves traction capabilities in undulating conditions. The 3-wheel stance improves productivity with tighter turning at the end of mowed passes.
Passcode-Protected TechControl Display Puts the Supervisor in Control
Set maximum mow speed, turn speed, and transport speed to assist in providing consistency of performance from operator to operator. These settings are passcode-protected within the TechControl display, putting the supervisor in more control of each operator's cut quality and performance. Achieve more consistency from machine to machine and from operator to operator for a more uniform appearance across the course.
Specifications
Engine
| Type | Indirect inject diesel |
| Engine Type | Tier 4 |
| Maximum Engine Power | 3000 rpm |
| Maximum Engine Power | 17.8 kW |
| Maximum Engine Power | 23.9 hp |
| Cylinders | 3 |
| Displacement | 1.267 L |
| Displacement | 77.32 cu in. |
| Air Cleaner | Two-stage dry element |
| Fuel | Diesel up to B20 compliant |
| Cooling System | Liquid centrifugal pump; forward machine location for optimum cooling |
Vehicle
| Drive Pump | Axial piston, electronically controlled hydrostatic traction pump; single gear pump for steering, lift, and charge; electric reel drive |
| Hydraulic System Capacity | 37.8 L |
| Hydraulic System Capacity | 10 U.S. gal. |
| Fuel Tank Capacity | 60.6 L |
| Fuel Tank Capacity | 16 U.S. gal. |
| Steering | Hydraulic power with double-acting steering cylinder |
| Front Drive Tires | 26.5x14-12 smooth |
| Steering Tires | 24x13-12 smooth |
| Ground Pressure | 69 kPa |
| Ground Pressure | 10 psi |
| Brakes | Internal hydraulic wet disc brakes with dynamic braking through closed loop hydrostatic system |
| ROPS | Standard; meets ISO 21299 Standard |
Controls
| Throttle | Hand throttle |
| Forward/Reverse | Two pedal |
| Mower Lift | One-touch single handle |
| Parking Brake | Electric switch on CommandARM for internal wet disk brakes |
| Seat | Suspension seat with seat belts and armrest, fore/aft adjustment, and weight and lumbar adjustment |
| PTO | Electric switch on CommandARM |
| Tilt Steering | Left-foot operated for easy adjustment |
| Operator Display | TechControl display located on CommandARM: machine warnings, onboard electrical diagnostics, service timers on large easy-to-read screen, quick on-the-go settings for mow and transport speed, Turn Speed, LoadMatch, and ON/OFF cruise control use selection. All settings passcode protected. |
| Storage | Cup holder, two-way radio, and large operator storage located on left-hand side of operator station |
Cutting Units
| Cutting Width | 100 in. |
| Cutting Width | 254 cm |
