Features
7-Iron™ PRO Deck
This mower is equipped with a 7-Iron PRO side-discharge deck stamped from 7-gauge steel, offering superior durability and performance. The deck design provides a high-quality cut with excellent material processing and discharge capabilities.
Fastback™ PRO Rear-Discharge Mower Deck
The Fastback™ PRO rear-discharge system improves safety and productivity by minimizing debris throw and allowing closer mowing near obstacles. Ideal for public spaces, it ensures a tidy operation with better debris control around the operator.
ComfortGlide™ Seat System
The ComfortGlide™ seat system features adjustable suspension, allowing operators to transition more smoothly over bumps. It can adjust fore and aft, absorbing impacts for reduced operator fatigue during long hours of operation.
Specifications
Mower Decks
| Mower Deck Size | 60-in. (152-cm) 7Iron™ PRO side-discharge; 60-in. (152-cm) 7Iron™ PRO Mulch On Demand™; 72-in. (183-cm) FastBack™ PRO rear-discharge |
| Deck Construction | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel; FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel |
| Discharge | Side-discharge, Mulch On Demand™, Rear-discharge |
| Height-Of-Cut Range | 1-5.5 in. |
| Height-Of-Cut Range | 2.54-14 cm |
| Height-Of-Cut Increments | 0.25 in. |
| Height-Of-Cut Increments | 0.64 cm |
| Cutting Width | 60/72 in. |
| Cutting Width | 152/183 cm |
Drivetrain
| Transmission | Hydrostatic |
| Wheel Motors | Tuff Torq heavy-duty integrated piston wheel motor with cross porting |
| Speed Range | 0-12 mph mph |
| Speed Range | 0-19.3 km/h km/h |
| Forward Speed | 0-12 mph mph |
| Forward Speed | 0-19.3 km/h km/h |
| Reverse Speed | 0-4.5 mph mph |
| Reverse Speed | 0-7.2 km/h km/h |
| Speed Direction And Control | Twin levers |
| Hydraulic Capacity | 5.9 U.S. qt |
| Hydraulic Capacity | 5.6 L |
| Filter | Internal, replaceable |
Dimensions
| Length | 60-in. deck: 87 in. (221 cm); 72-in. deck: 90 in. (229 cm) |
| Width - With Chute Down | 74 in. |
| Width - With Chute Down | 188 cm |
| Width - Rear Discharge | 75.8 in. |
| Width - Rear Discharge | 192.5 cm |
| Height - With ROPS Up | 73 in. |
| Height - With ROPS Up | 185 cm |
| Height - With ROPS Down | 47 in. |
| Height - With ROPS Down | 119 cm |
| Weight | 1437 - 1529 lb. |
| Weight | 652 - 694 kg |
Operation
| Rollover Protective Structure (ROPS) | Yes |
| Slope Operating Limit | 20 degree (angle) |
| Slope Operating Limit - With Material Collection System | 10 degree (angle) |
Wheels
| Caster Wheel Type | Flat free |
| Caster Wheels | 13x6.5-6 |
| Front Anti-Scalp Rollers | Left, center, right |
| Rear Anti-Scalp Rollers | 7Iron PRO: Left, center, right; FastBack PRO: Left, right |
Brakes
| Dynamic Braking | Twin levers |
| Park Brake | Internal wet disk integrated in the transmission |
| Park Brake Actuation | Foot brake |
Fuel System
| Fuel Type | Gasoline |
| Fuel Consumption | Under normal conditions, load, operation, and dependent on loads and operating conditions; 7Iron PRO side-discharge: 1.3 U.S. gal./hr (4.9 L/hr); FastBack PRO rear-discharge: 1.1 U.S. gal./hr (4.2 L/hr) |
| Fuel Tank Capacity | 11.5 U.S. gal. |
| Fuel Tank Capacity | 43.5 L |
| Fuel Tank Switch/Shut-Off Valve | No |
Engine
| Engine Manufacturer/Model | FX781V EVO EFI |
| Engine Power | Gross at 3,600 rpm: 30.5 hp (22.7 kW) |
| Displacement | 50.2 cu in. |
| Displacement | 822 cc |
| Cylinders | 2 |
| Crankcase Capacity | 2.2 U.S. qt |
| Crankcase Capacity | 2.1 L |
| Oil Filter | Full flow, replaceable |
| Lubrication | Full pressure |
| Cooling | Forced air, with integrated clean out ports and oil cooler |
| Air Cleaner | Heavy-duty canister type with safety element |
| Pre-Cleaner | Yes |
Tires
| Drive Wheels | 24x12-12 |
| Load Rating | 4 PR |
Additional Information
| Date Collected | 10/01/2024 00:00:00 |
Blades
| Length | Varies by deck size |
| Thickness | 7Iron PRO: 0.25 in. (6.4 mm); FastBack PRO: 0.31 in. (8 mm) |
| Blade Tip Speed | 7Iron PRO: Approximately 18,500 fpm; 72-in. (183-cm) FastBack: Approximately 18,000 fpm |
| Number | 3 |
PTO
| Type | Electro-magnetic, 225 lb-ft (305 Nm) |
| Drive | V-belt |
Electrical System
| Charge System | 30 amp |
| Battery Voltage | 12 V |
| Cold Cranking Amp | 300 amp |
| Hour Meter | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics |
| Operator Presence Starting System | Brake-N-Go (foot) |
Buyer's note
| Warranty | 36 months or 1500 hours, whichever comes first; First 24 months, no hour limitation |
