Features
Transmission Offers High-Powered Performance
Equipped with a robust drivetrain, this mower offers speeds up to 9.5 mph (15.2 km/h) with dual Hydro-Gear® transmissions. This feature allows for efficient mowing and effective power distribution, ensuring durability and high-quality performance in demanding settings.
High Capacity PRO Mower Decks
The Z700 Series ZTrak™ is equipped with High Capacity PRO Mower Decks, available in 48-in., 54-in., and 60-in. (122-cm, 137-cm, and 152-cm) cutting widths. These decks deliver superior mowing performance and versatility, with options for MulchControl™ and material collection, providing unmatched effectiveness across various mowing conditions.
Operator Station is Adjustable for Superior Comfort
The mower features a highly ergonomic operator station designed for comfort and ease of use. It includes an adjustable foot platform and seat, along with user-friendly motion control levers and display, offering a tailored experience for various operators.
Specifications
Chassis
| Frame | Heavy-duty frame tubing |
| Primer/Paint | E-coat/powder |
| Front Caster Tires | 13x6.5-6 |
| Front Caster Bearings | Sealed ball bearings |
| Drive Tires | 23x9.5-12 (48-in. decks) / 23X10.5-12 (54- and 60-in. decks) |
| Hour Meter | Yes |
| Service Interval Decal | Yes |
| Storage Compartment | Yes |
| Cup Holder | Yes |
Lift System
| Type | Spring assisted foot lift |
| Mower Cut Height - Minimum | 3.8 cm |
| Mower Cut Height - Minimum | 1.5 in. |
| Mower Cut Height - Maximum | 12.7 cm |
| Mower Cut Height - Maximum | 5 in. |
| Cut Height Increments | 0.64 cm |
| Cut Height Increments | 0.25 in. |
| Preset Cut Height | Yes |
Operation
| Rollover Protective Structure (ROPS) | Yes |
| Slope 0perating Limit | Standard: 15 degrees; With Material Collection System: 10 degree (angle) |
| Operator Presence System | Yes |
| Park Brake Interlock | Yes |
| Operator Video | Yes |
Mower Deck
| Cutting Width | 122/137/152 cm |
| Cutting Width | 48/54/60 in. |
| Type | High-capacity (HC) PRO side discharge |
| Mower Deck Material | 9 gauge |
| Mower Deck Material | 3.8 mm |
| Mower Deck Material | 0.15 in. |
| Mower Drive System | V-belt |
Optional Attachments
| Mulching System | Optional MulchControl™ attachment |
| Rubber Floor Mat | Optional |
| Light Kit | Optional LED work and beacon lights |
| Material Collection System | 48 HC PRO, 54 HC PRO, and 60 HC PRO Power Flow™ rear bagger |
| Material Collection System | 229 L |
| Material Collection System | 6.5 bu |
Seat
| Seat Back Height | 57.1 cm |
| Seat Back Height | 22.5 in. |
| Fore-Aft Adjustment | 5.08 cm |
| Fore-Aft Adjustment | 2 in. |
| Seat Suspension | Two four-position springs with ComfortGlide™ fore/aft suspension |
Travel Speed
| Forward Speed | 15.3 km/h |
| Forward Speed | 9.5 mph |
| Reverse Speed | 6.4 km/h |
| Reverse Speed | 4 mph |
| Speed And Direction Control | Twin premium levers |
| Control Adjustment | 2-height/18 positions |
Engine
| Engine Power | 18.6 kW |
| Engine Power | 25 hp |
| Engine Model Number | HTR810 |
| Displacement | 810 cc |
| Displacement | 49.4 cu in. |
| Cylinders | V-twin |
| Lubrication | Full pressure with replaceable filter |
| Lubrication | 1.9 L |
| Lubrication | 2 U.S. qt |
| Type | Overhead valve |
| Battery Voltage | 12 V |
| Battery Cold Crank Amps | 340 CCA |
| Choke/Speed Control | Separate control levers |
| Cooling Method | Air |
| Fuel Tank Capacity | 30.2 L |
| Fuel Tank Capacity | 8 U.S. gal. |
| Fuel Gauge | Fuel level sight line |
Dimensions
| Wheelbase | 126.7 cm |
| Wheelbase | 49.9 in. |
| Overall Length | 208.4 cm |
| Overall Length | 82 in. |
| Width Without Mower | 123.5 cm |
| Width Without Mower | 48.6 in. |
Power Take-Off (PTO)
| Type | Electric |
| Type | 169 Nm |
| Type | 125 lb-ft |
| Drive | V-belt |
Additional Information
| Date Collected | 09/01/2022 00:00:00 |
Buyer's Notes
| Note 1 | Flip-up and adjustable foot platform for easy service access |
| Warranty | 4 year/750 hour bumper-to-bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) |
Drivetrain
| Dual Hydros | Hydro-gear ZT3200 with 1-in. (2.54-cm) axles |
