Liquid-Cooled Diesel Engine
The liquid-cooled, 3-cylinder diesel engine delivers strong, dependable power with exceptional fuel economy and long-lasting durability. Smooth, quiet operation and high torque make it well-suited for demanding mowing and commercial-grade tasks. Easy starting and consistent performance provide confidence and efficiency season after season.
Comfortable, Large Operator Station
A 21-in. (53-cm), high-back cut-and-sewn seat with four-bar adjustable seat suspension and seat recline delivers a comfortable, smooth ride and excellent support. Instrument display has the look and feel of a modern automobile, with simple and intuitive controls. Twin Touch™ foot pedals with a hydrostatic transmission allow you to maneuver with precision without shifting or lifting your foot off the platform.
Snow Removal and Yard Care Attachments
Snow removal and yard work are easy with support for a wide range of attachments. The front quick-hitch system allows fast, tool-free changes between a snow blower, front blade, or rotary broom, helping you adapt quickly to changing conditions. This versatility lets you handle seasonal tasks efficiently and keep your property looking its best year-round.
Image shows a 54-in. (137-cm) Snow Blower with optional cab on an X739 Tractor
Specifications
Mower Deck
| Type | Side discharge |
| Cutting Width | 122/137/152 cm |
| Cutting Width | 48/54/60 in. |
| Construction | Forged steel deck shell |
| Mower Wash Port | Yes |
| Mower Drive System | Hydraulic clutch, shaft |
| Mower Wheels | 48A, four and center front roller / 54 and 60 HC, four with optional center front roller |
| Mower Wheel Adjustment | Spring-loaded pin |
| Mower Level Adjustment | Exact Adjust ports and onboard deck-leveling gauge |
Seat
| Type | Two-piece adjustable seat with brand embroidery |
| Seat Back Height | 53.3 cm |
| Seat Back Height | 21 in. |
| Armrests | Optional |
| Fore-Aft Adjustment | 17.8 cm |
| Fore-Aft Adjustment | 7 in. |
| Seat Suspension | Six-position parallel arm |
Steering
| Type | Hydraulic power |
| Four-Wheel Steer | Not available on this model |
| Steering Wheel | 35.6 cm |
| Steering Wheel | 14 in. |
| Tilt Steering Wheel | Standard, six position |
| Turning Radius | 63.5 cm |
| Turning Radius | 25 in. |
Buyer's Notes
| Notes | Styled alloy wheels are standard equipment One-piece hood for easy engine access Hydraulic modulated PTO clutch for smooth mower and implement engagement |
| Warranty | 4 year/700 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) |
Chassis
| Frame | Welded heavy-duty |
| Primer/Paint | E-coat/powder |
| Weight Bracket | Standard front - holds up to four Quik-Tatch weights, 42 lb / 19 kg |
| Receiver Hitch | Yes, front |
| Front Axle | JDM BA8 nodular iron casting |
| Spindle Bushings | Metal, replaceable |
| Front Tires | 18x8.5-8 turf |
| Rear Tires | 26x12-12 turf |
| Hood Material | Noryl GTX902, painted |
| Fender Deck Material | Stamped steel |
| Floor Mats | Sure-grip rubber |
| Storage | Covered toolbox |
| Service Interval Decal | Yes |
| Fender Handles/Grips | Handles |
| Cup Holder | Yes |
| Equipment Mounting | Optional category 1 3-point hitch |
| Maximum Towing Capacity | 454 kg |
| Maximum Towing Capacity | 1000 lb. |
Optional Equipment
| Mowers | 48A, 54 HC, 60 HC |
| Rear Bagger | 670 L |
| Rear Bagger | 19 bu |
| Powered Material Collection | Power Flow, 7, 14, 19 bu / 250, 500, 670 L |
| Mulching System | Yes, MulchControl™ |
| Front Thatcher | 137.2 cm |
| Front Thatcher | 54 in. |
| Front Blade | 137.2 cm |
| Front Blade | 54 in. |
| Snow Blower | 137.2 cm |
| Snow Blower | 54 in. |
| Rotary Broom | 152.4 cm |
| Rotary Broom | 60 in. |
| Rotary Tiller | 121.9 cm |
| Rotary Tiller | 48 in. |
| 3-Point Hitch | Category 1 |
| Rear Power Take-Off | 540 rpm |
| Plow, Moldboard | 35.6 cm |
| Plow, Moldboard | 14 in. |
| Box Scraper | 121.9 cm |
| Box Scraper | 48 in. |
| Cultivator | 116.8 cm |
| Cultivator | 46 in. |
| Rear Blade | 152.4 cm |
| Rear Blade | 60 in. |
| Disk Harrow | 132.1 cm |
| Disk Harrow | 52 in. |
| Landscape Rake | 152.4 cm |
| Landscape Rake | 60 in. |
| Sprayer - Tow-Behind | 170.3 L |
| Sprayer - Tow-Behind | 45 U.S. gal. |
| Sprayer - Mounted | 94.6 L |
| Sprayer - Mounted | 25 U.S. gal. |
| Spreader - Tow-Behind | 79.4 kg |
| Spreader - Tow-Behind | 175 lb. |
| Spreader - Mounted | 57.7 kg |
| Spreader - Mounted | 125 lb. |
| Front Bumper | Standard bumper/weight bracket |
| Brush Guard | Yes |
| Weather Protection | Hard-side cab, weather enclosure |
| Bucket Holder | Yes, double bucket |
| Grass Striping | Grass groomer kit, 48-in. (122-cm) mower only |
| Tractor Shovel | 137.2 cm |
| Tractor Shovel | 54 in. |
| Front Loader | Not available |
| Tow-Behind Tools | 21 |
Lift System
| Lift System Type | Two-function hydraulic |
| Hydraulic Outlets | Four, standard |
| Mower Cut Height - Minimum | 2.5 cm |
| Mower Cut Height - Minimum | 1 in. |
| Mower Cut Height - Maximum | 13.3 cm |
| Mower Cut Height - Maximum | 5.25 in. |
| Cut Height Increments | 0.64 cm |
| Cut Height Increments | 0.25 in. |
| Preset Cut Height | Yes |
Dimensions
| Height | 1384 mm |
| Height | 54.5 in. |
| Overall Length | 1905 mm |
| Overall Length | 75 in. |
| Wheelbase | 1384 mm |
| Wheelbase | 54.5 in. |
| Width Without Mower | 1195 mm |
| Width Without Mower | 47 in. |
| Weight | 427 kg |
| Weight | 942 lb. |
Electrical System
| Battery Voltage | 12 V |
| Battery Cold Crank Amps | 500 CCA |
| Charging System | Engine-mounted alternator, regulated |
| Charging System | 40 amp |
| Engine Starter | Solenoid shift |
| Hour Meter | Yes |
| Headlights | Two standard, halogen, 37 W |
| Taillights Or Reflector | Taillights |
| Backup Lights | Yes |
| Rear Work Lights | Yes |
| 12-V Outlet | Yes |
Fuel System
| Type | Diesel |
| Fuel Delivery | In-line indirect injection |
| Fuel Gauge | Gauge on dash |
| Fuel Tank Location | Rear |
| Fuel Fill Opening | On left fender |
| Fuel Fill Opening | 7.6 cm |
| Fuel Fill Opening | 3 in. |
| Fuel Tank Capacity | 19.7 L |
| Fuel Tank Capacity | 5.2 U.S. gal. |
Safety
| Meets ANSI Standard | Yes |
| Meets OPEI Standard | Yes |
| Backup Protection | Reverse Implement Option (RIO) |
| Safety Video | Yes |
Transaxle
| Transaxle Type | K90 hydrostatic integrated with transaxle |
| Transaxle Control | Twin Touch™ pedals |
| Cruise Control | Yes |
| Oil Cooler | Yes |
| Oil Filter | Replaceable suction side 10 micron |
| Differential Lock | Standard |
| Forward Speed | 13.7 km/h |
| Forward Speed | 8.5 mph |
| Reverse Speed | 9.7 km/h |
| Reverse Speed | 6 mph |
| Brakes | Internal wet disc |
Additional Information
| Manufacturing Location | Horicon, Wisconsin, USA |
| Date Collected | 08/01/2023 00:00:00 |
Engine
| Engine Power | 17.9 kW |
| Engine Power | 24 hp |
| Displacement | 993 cc |
| Displacement | 60.6 cu in. |
| Engine Manufacturer/Model | 3TNM74F |
| Engine Type | Diesel, overhead valve, full-pressure lube, oil filter |
| Cylinders | Three, cast-iron liners |
| Governor | Mechanical |
| Choke/Speed Control | One lever |
| Cooling Method | Liquid |
| Air Cleaner | Paper dry-type with primary and secondary elements |
| Oil Change | No tools |
Mower Attachability
| Type | Roll under tractor (48A) / Drive-over deck (54, 60 HC) |
| Front Draft Arms | Overcenter |
| Rear Draft Arms | V-align |
| Mower Wheels Rotate | Yes, 90 degrees for easy mower removal (48A), N/A (54 HC, 60 HC) |
| Drive System | Shaft or AutoConnect |
