Features
Liquid Cooled V-Twin Engine with EFI and Electronic Throttle
The liquid-cooled V-twin engine with electronic fuel injection and electronic throttle delivers smooth, quiet, and reliable power for demanding mowing conditions. Consistent cooling and Intelligent Power Management help maintain performance under load while improving durability and efficiency. The result is confident operation, easier starting, and long-lasting performance you can rely on season after season.
Four Wheel Drive (4WD) with Twin Touch™ Control
Hydrostatic four-wheel drive (4WD) with Twin Touch™ foot controls delivers superior traction and confident control in challenging conditions. Smooth, automotive-style operation allows easy speed and direction changes without lifting your foot, while cruise control helps reduce fatigue during longer jobs. Built with heavy-duty components, the system provides durable, reliable performance for mowing, towing, and year-round property work.
Four-Wheel Power Steering and Hydraulic Lift
Power steering and hydraulic lift provide effortless automotive-like control. Combined with four-wheel power steer, these systems reduce operator fatigue, enhancing productivity by enabling a tight turning radius, helping you finish the job faster.
Specifications
Mower Deck
| Type | Side discharge |
| Cutting Width | 122/137/152 cm |
| Cutting Width | 48/54/60 in. |
| Construction | Forged steel deck shell |
| Mower Wash Port | Yes |
| Mower Drive System | Hydraulic clutch, shaft |
| Mower Wheels | 48A, four and center front roller / 54 and 60 HC, four with optional center front roller |
| Mower Wheel Adjustment | Spring-loaded pin |
| Mower Level Adjustment | Exact Adjust ports and onboard deck-leveling gauge |
Seat
| Type | Two-piece adjustable seat with brand embroidery |
| Seat Back Height | 53.3 cm |
| Seat Back Height | 21 in. |
| Armrests | Optional |
| Fore-Aft Adjustment | 17.8 cm |
| Fore-Aft Adjustment | 7 in. |
| Seat Suspension | Six-position parallel arm |
Steering
| Type | Hydraulic power |
| Four-Wheel Steer | Yes |
| Steering Wheel | 35.6 cm |
| Steering Wheel | 14 in. |
| Tilt Steering Wheel | Standard, six position |
| Turning Radius | 53.3 cm |
| Turning Radius | 21 in. |
Buyer's Notes
| Notes | Styled alloy wheels are standard equipment One-piece hood for easy engine access Hydraulic modulated PTO clutch for smooth mower and implement engagement |
| Warranty | 4 year/700 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) |
Chassis
| Frame | Welded heavy-duty |
| Primer/Paint | E-coat/powder |
| Weight Bracket | Standard front - holds up to four Quik-Tatch weights, 42 lb / 19 kg |
| Receiver Hitch | Yes, front |
| Front Axle | JDM BA8 nodular iron casting |
| Front Tires | 18x8.5-10 HDAP |
| Rear Tires | 26x12-12 HDAP |
| Hood Material | Noryl GTX902, painted |
| Fender Deck Material | Stamped steel |
| Floor Mats | Sure-grip rubber |
| Storage | Covered toolbox |
| Service Interval Decal | Yes |
| Fender Handles/Grips | Handles |
| Cup Holder | Yes |
| Equipment Mounting | Optional category 1 3-point hitch |
| Maximum Towing Capacity | 544 kg |
| Maximum Towing Capacity | 1200 lb. |
Optional Equipment
| Mowers | 48A, 54 HC, 60 HC |
| Rear Bagger | 670 L |
| Rear Bagger | 19 bu |
| Powered Material Collection | Power Flow, 7, 14, 19 bu / 250, 500, 670 L |
| Mulching System | Yes, MulchControl™ |
| Front Thatcher | 137.2 cm |
| Front Thatcher | 54 in. |
| Front Blade | 137.2 cm |
| Front Blade | 54 in. |
| Snow Blower | 137.2 cm |
| Snow Blower | 54 in. |
| Rotary Broom | 152.4 cm |
| Rotary Broom | 60 in. |
| Rotary Tiller | 121.9 cm |
| Rotary Tiller | 48 in. |
| 3-Point Hitch | Category 1 |
| Rear Power Take-Off | 540 rpm |
| Plow, Moldboard | 35.6 cm |
| Plow, Moldboard | 14 in. |
| Box Scraper | 121.9 cm |
| Box Scraper | 48 in. |
| Cultivator | 116.8 cm |
| Cultivator | 46 in. |
| Rear Blade | 152.4 cm |
| Rear Blade | 60 in. |
| Disk Harrow | 132.1 cm |
| Disk Harrow | 52 in. |
| Landscape Rake | 152.4 cm |
| Landscape Rake | 60 in. |
| Sprayer - Tow-Behind | 170.3 L |
| Sprayer - Tow-Behind | 45 U.S. gal. |
| Sprayer - Mounted | 94.6 L |
| Sprayer - Mounted | 25 U.S. gal. |
| Spreader - Tow-Behind | 79.4 kg |
| Spreader - Tow-Behind | 175 lb. |
| Spreader - Mounted | 57.7 kg |
| Spreader - Mounted | 125 lb. |
| Front Bumper | Standard bumper/weight bracket |
| Brush Guard | Yes |
| Weather Protection | Hard-side cab, weather enclosure |
| Bucket Holder | Yes, double bucket |
| Grass Striping | Grass groomer kit, 48-in. (122-cm) mower only |
| Tractor Shovel | 137.2 cm |
| Tractor Shovel | 54 in. |
| Front Loader | Not available |
| Tow-Behind Tools | 21 |
Lift System
| Lift System Type | Two-function hydraulic |
| Hydraulic Outlets | Four, standard |
| Mower Cut Height - Minimum | 2.5 cm |
| Mower Cut Height - Minimum | 1 in. |
| Mower Cut Height - Maximum | 13.3 cm |
| Mower Cut Height - Maximum | 5.25 in. |
| Cut Height Increments | 0.64 cm |
| Cut Height Increments | 0.25 in. |
| Preset Cut Height | Yes |
Dimensions
| Height | 1384 mm |
| Height | 54.5 in. |
| Overall Length | 1905 mm |
| Overall Length | 75 in. |
| Wheelbase | 1415 mm |
| Wheelbase | 55.7 in. |
| Width Without Mower | 1245 mm |
| Width Without Mower | 49 in. |
| Weight | 469 kg |
| Weight | 1034 lb. |
Electrical System
| Battery Voltage | 12 V |
| Battery Cold Crank Amps | 340 CCA |
| Charging System | Flywheel alternator, regulated |
| Charging System | 20 amp |
| Engine Starter | Solenoid shift |
| Hour Meter | Yes |
| Headlights | Two standard, halogen, 37 W |
| Taillights Or Reflector | Taillights |
| Backup Lights | Yes |
| Rear Work Lights | Yes |
| 12-V Outlet | Yes |
Fuel System
| Type | Gasoline |
| Fuel Delivery | Electronic fuel injection |
| Fuel Gauge | Gauge on dash |
| Fuel Tank Location | Rear |
| Fuel Fill Opening | On left fender |
| Fuel Fill Opening | 7.6 cm |
| Fuel Fill Opening | 3 in. |
| Fuel Tank Capacity | 19.7 L |
| Fuel Tank Capacity | 5.2 U.S. gal. |
Safety
| Meets ANSI Standard | Yes |
| Meets OPEI Standard | Yes |
| Backup Protection | Reverse Implement Option (RIO) |
| Safety Video | Yes |
Transaxle
| Transaxle Type | K90 hydrostatic integrated with transaxle |
| Transaxle Control | Twin Touch™ pedals |
| Cruise Control | Yes |
| Oil Cooler | Yes |
| Oil Filter | Replaceable suction side 10 micron |
| Differential Lock | Standard |
| Forward Speed | 13.7 km/h |
| Forward Speed | 8.5 mph |
| Reverse Speed | 9.7 km/h |
| Reverse Speed | 6 mph |
| Brakes | Internal wet disc |
Additional Information
| Manufacturing Location | Horicon, Wisconsin, USA |
| Date Collected | 08/01/2023 00:00:00 |
Engine
| Engine Power | 19 kW |
| Engine Power | 25.5 hp |
| Displacement | 745 cc |
| Displacement | 45.5 cu in. |
| Engine Manufacturer/Model | FD750D EFI |
| Engine Type | Electronic fuel injection (EFI), overhead valve, full-pressure lube, oil filter |
| Governor | Mechanical |
| Choke/Speed Control | No choke required |
| Cooling Method | Liquid |
| Air Cleaner | Dry, replaceable with foam precleaner |
| Oil Change | No tools |
Mower Attachability
| Type | Roll under tractor (48A) / Drive-over deck (54, 60 HC) |
| Front Draft Arms | Overcenter |
| Rear Draft Arms | V-align |
| Mower Wheels Rotate | Yes, 90 degrees for easy mower removal (48A), N/A (54 HC, 60 HC) |
| Drive System | Shaft or AutoConnect |
