Features
42-in. Accel Deep™ Mower Deck With Optional MulchControl™
The 42-in. Accel Deep Mower Deck offers a stamped-steel, deep flat-top design that ensures excellent cut quality, productivity, and versatility. With the optional MulchControl system and MulchControl with one-touch technology, quickly transition from mulching performance, side discharge, or bagging modes. This system creates a beautiful lawn, reduces fertilizer needs, and prevents clippings from blowing onto operators or driveways.
Image shows X350 Lawn Tractor with Accel Deep™ 42A Mower Deck
Automotive Style Instrument Panel
Easy-to-read instrument panel keeps all of the information you need to mow at your best. Easy-to-read fuel gauge and battery voltage level indicator ensure you won’t get stuck far from home while a tachometer makes sure the engine RPMs are optimal for the best mowing performance. And always keep your tractor in top shape by help of the hour meter to tell you when maintenance is required.
Snow Removal Capability
Equip your machine with a snow blower or front blade. Designed to handle challenging winter conditions, this tractor helps you clear deep snow, getting the job done more quickly and you out of the cold.
Specifications
Mower Deck
| Type | Side discharge |
| Cutting Width | 107 cm |
| Cutting Width | 42 in. |
| Construction | Stamped steel deck shell |
| Mower Deck Material | 12 gauge |
| Mower Deck Material | 2.7 mm |
| Mower Deck Material | 0.105 in. |
| Mower Wash Port | Yes |
| Mower Drive System | Electric power take-off (PTO) clutch, in-line belt |
| Mower Wheels | Two |
| Mower Wheel Adjustment | Four-position, tool required |
| Mower Level Adjustment | Exact Adjust ports and onboard deck-leveling gauge |
Seat
| Type | Open-back design with grasp |
| Seat Back Height | 38 cm |
| Seat Back Height | 15 in. |
| Armrests | No |
| Fore-Aft Adjustment | 17 cm |
| Fore-Aft Adjustment | 6.6 in. |
| Seat Suspension | Tilt, two coil springs, three-position no-tools adjustment for operator weight |
Steering
| Type | Manual, sector and pinion |
| Four-Wheel Steer | Not available on this model |
| Steering Wheel | 35.6 cm |
| Steering Wheel | 14 in. |
| Tilt Steering Wheel | No |
| Turning Radius | 40.6 cm |
| Turning Radius | 16 in. |
| Uncut Circle Radius | 66 cm |
| Uncut Circle Radius | 26 in. |
Buyer's Notes
| Notes | Fully enclosed, molded-in color material reduces sound, will not rust or dent Durable E-coat primer and powder-paint finish |
| Warranty | 4 year/300 hour bumper-to-bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) |
Chassis
| Frame | Welded heavy-duty |
| Primer/Paint | E-coat/powder |
| Weight Bracket | Standard rear, optional front |
| Receiver Hitch | No |
| Front Axle | Cast iron front axle, front wheel ball bearings |
| Spindle Bushings | No |
| Front Tires | 15x6-6 |
| Rear Tires | 20x10-8 |
| Hood Material | Fully enclosed, molded-in color material reduces sound, will not rust or dent |
| Fender Deck Material | Stamped steel |
| Floor Mats | Sure-grip rubber |
| Storage | Yes, under seat and covered toolbox |
| Service Interval Decal | Yes |
| Fender Handles/Grips | No |
| Cup Holder | Yes |
| Equipment Mounting | Yes, heavy duty |
| Maximum Towing Capacity | 272 kg |
| Maximum Towing Capacity | 600 lb. |
Optional Equipment
| Mowers | 42A (standard) |
| Rear Bagger | 247 L |
| Rear Bagger | 7 bu |
| Mulching System | Yes, MulchControl™ |
| Front Blade | 111.8 cm |
| Front Blade | 44 in. |
| Snow Blower | 111.8 cm |
| Snow Blower | 44 in. |
| Sprayer - Tow-Behind | 94.6 L |
| Sprayer - Tow-Behind | 25 U.S. gal. |
| Sprayer - Mounted | 25 U.S. gal. |
| Spreader - Tow-Behind | 79.4 kg |
| Spreader - Tow-Behind | 175 lb. |
| Spreader - Mounted | 125 lb. |
| Front Bumper | Styled bumper option |
| Brush Guard | Yes |
| Weather Protection | Weather enclosure |
| Sun Canopy | Yes |
| Bucket Holder | Yes, double bucket |
| Grass Striping | Lawn striping kit |
| Tractor Shovel | 101.6 cm |
| Tractor Shovel | 40 in. |
| Tow-Behind Tools | 16 |
Lift System
| Lift System Type | Foot pedal with optional adjustable spring assist kit |
| Hydraulic Outlets | No |
| Mower Cut Height - Minimum | 2.5 cm |
| Mower Cut Height - Minimum | 1 in. |
| Mower Cut Height - Maximum | 10.2 cm |
| Mower Cut Height - Maximum | 4 in. |
| Cut Height Increments | 0.64 cm |
| Cut Height Increments | 0.25 in. |
| Preset Cut Height | Yes |
Dimensions
| Height | 1171 mm |
| Height | 46.1 in. |
| Overall Length | 1817 mm |
| Overall Length | 71.5 in. |
| Wheelbase | 1255 mm |
| Wheelbase | 49.4 in. |
| Width With Mower | 1283 mm |
| Width With Mower | 50.5 in. |
| Width With Mower (Deflector Raised For Storage) | 1300 mm |
| Width With Mower (Deflector Raised For Storage) | 51.2 in. |
| Width Without Mower | 964 mm |
| Width Without Mower | 38 in. |
| Weight | 246 kg |
| Weight | 542 lb. |
Electrical System
| Battery Voltage | 12 V |
| Battery Cold Crank Amps | 340 CCA |
| Charging System | Flywheel alternator, regulated |
| Charging System | 14 amp |
| Engine Starter | Bendix |
| Hour Meter | Yes |
| Headlights | Two standard, incandescent, 27 W |
| Taillights Or Reflector | No |
| Backup Lights | No |
| Rear Work Lights | No |
| 12-V Outlet | Optional |
Fuel System
| Type | Gasoline |
| Fuel Delivery | Pulse pump, carburetor |
| Fuel Gauge | Gauge on dash |
| Fuel Tank Location | Rear |
| Fuel Fill Opening | On left fender |
| Fuel Fill Opening | 7.6 cm |
| Fuel Fill Opening | 3 in. |
| Fuel Tank Capacity | 12.5 L |
| Fuel Tank Capacity | 3.3 U.S. gal. |
Safety
| Meets ANSI Standard | Yes |
| Meets OPEI Standard | Yes |
| Backup Protection | Reverse Implement Option (RIO) |
| Safety Video | Yes |
Transaxle
| Transaxle Type | K46 hydrostatic integrated with transaxle |
| Transaxle Control | Twin Touch™ pedals |
| Cruise Control | Yes, button on dash |
| Oil Cooler | Fins and fan on transaxle |
| Oil Filter | Internal, not replaceable |
| Differential Lock | No |
| Forward Speed | 8.9 km/h |
| Forward Speed | 5.5 mph |
| Reverse Speed | 6.4 km/h |
| Reverse Speed | 4 mph |
| Brakes | Internal wet disc |
Additional Information
| Manufacturing Location | Horicon, Wisconsin, USA |
| Date Collected | 10/03/2022 00:00:00 |
Engine
| Engine Power | 16.4 kW |
| Engine Power | 22 hp |
| Displacement | 724 cc |
| Displacement | 44.2 cu in. |
| Engine Manufacturer/Model | 44J6 Cyclonic |
| Engine Type | Overhead valve, full-pressure lube, oil filter |
| Cylinders | V-twin, cast-iron liners |
| Governor | Mechanical |
| Choke/Speed Control | Separate levers, automatic choke return |
| Cooling Method | Air |
| Air Cleaner | Dry, replaceable |
| Oil Change | No-tools oil drain hose with replaceable filter |
Mower Attachability
| Type | Slide under tractor |
| Front Draft Arms | Attached with spring pins at two points |
| Rear Draft Arms | Two pins and spring clips |
| Mower Wheels Rotate | No |
| Drive System | Single belt |
