John Deere R200

New Products / John Deere / John Deere Products / Hay and Forage Equipment / Mowing / R200

Double tap to zoom



Features

Heavy-Duty Cutterbar for Tough Conditions

Front studio view of a green R-series disc mower rotary disc cutterbar with black cover folded back

A heavy-duty cutterbar efficiently handles tough cutting conditions. Its rotary discs operate on a fully enclosed multi-V-belt drive system, promoting smooth and reliable operation while enhancing belt life with automatic tensioning.

Lift and Suspension System

Close-up of the location of a disc mower's green heavy floatation spring in studio

The mower uses a hydraulic cylinder to lift the cutterbar from cutting to transport position, where it automatically locks. With a cutting arc of +35 to -22 degrees, the system provides versatility and even flotation across varying field conditions.

Easy-to-Remove Disc Quill

Studio close-up of an R-series disc mower's removed gold-and-green disc quill resting on its housing

The mower's cutterbar is safeguarded against severe impacts. Should an obstacle be hit, the drive shaft shears, protecting internal components. Disc quills, which can be easily removed, improve serviceability and reduce maintenance costs with each featuring two replaceable knives.

Specifications

Mower

Number Of Disks5
Number Of Knives10
Width Of Cut6.58 ft
Width Of Cut2 m
Weight1025 lb.
Weight465 kg
Disk Speed2986 rpm
Cutting Arc+35 to -16 degree (angle)
Lift SystemHydraulic
Minimum PTO Power35 hp
Minimum PTO Power26 kW
PTO Speed540 rpm
