Features
ProTouch Harvest
Start harvesting faster than ever with ProTouch Harvest. Preconfigured for corn, grass, and whole crop silage, ProTouch Harvest uses just one click to engage six harvester functions in an adjustable sequence.
Engineered for Powerful Kernel Crushing and Crop Conditioning
Choose between the Ultimate250™ KP and XStream305™ KP advanced kernel processors that are designed to crush corn kernels and condition crop material for higher-quality silage. Both systems increase processing surface area and optimize crop flow to improve feed value and consistency.
Ground Speed Automation
Say goodbye to constantly adjusting your speed according to field conditions. Ground Speed Automation automatically adjusts harvester speed and engine RPM according to your preset limits on engine load. Automatically optimizing your speed helps to reduce fuel use and improve productivity.
Specifications
Operator Station
| Tilt and Extend Steering Column | Standard |
| Air Conditioning and Heater | Standard |
| Cool Box | Optional |
| Instructional Seat | Standard |
| Primary Display | Standard |
| Seat Suspension | Optional |
| Side Window Wiper | Optional |
| Electric Adjust and Heated | Optional |
| Rearview Mirrors | Standard |
| Panoramic View Windows | Standard |
Blower/Crop Accelerator
| Rotor Diameter | 620 mm |
| Rotor Diameter | 24.4 in. |
| Housing Width | 560 mm |
| Housing Width | 22 in. |
| Number of Blades | 10 |
| Speed (Option) | 1985 rpm |
Header Connection
| Infinitely Variable Header Drive | Standard |
| Lateral Pivoting Frame | Standard |
| Multicoupler | Standard |
| Auto PTO Coupler | Optional |
| Header Drive | Standard |
| Header Height Control | Optional Automatic Header Control (AHC) |
| Grass Pickups (Transport Width) | 3.0, 3.49, 4.0, 4.5, 4.6 m |
| Grass Pickups (Transport Width) | 9.84, 11.45, 13.12, 14.76, 15.09 ft |
| Maize Headers | 6, 8, 10 or 12 row |
| Maize Headers Working Widths | 4.5, 6.0, 7.5, 9.0 m |
| Maize Headers Working Widths | 14.8, 19.7, 24.6, 29.5 ft |
Dimensions & Weights
| Overall Length | 6.87 m |
| Overall Length | 22.53 ft |
| Transport Height | 3.93 m |
| Transport Height | 9.84 ft |
| Overall Height | 3.8 m |
| Overall Height | 12.46 ft |
| Base Machine Weight | 18500 kg |
| Base Machine Weight | 40785 lb. |
Engine
| Engine Make | John Deere |
| Engine Model | JD18X 6180 |
| Emissions Certifications | Final Tier 4 / Stufe V |
| Displacement | 18 L |
| Displacement | 1098 cu in. |
| Number of Cylinders | 6 |
| Rated Engine Speed | 1800 rpm |
| Rated Engine Power | 603 kW |
| Rated Engine Power | 809 hp |
| Rated Engine Power | 820 PS |
| Maximum Engine Power | 625 kW |
| Maximum Engine Power | 838 hp |
| Maximum Engine Power | 850 PS |
| Cooling Fan Drive | Fixed fan drive |
| Air Compressor | Optional / 1 Cylinder 350cc, water cooled / 2 Cylinder 720cc, water cooled |
| Turbocharger | Dual-stage turbo (DST) |
John Deere Premium KP
| Lubrication | John Deere Ultimate250 KP: Grease |
| Roll Diameter | 250 mm |
| Roll Diameter | 10 in. |
| Speed Differential / Roll Speed (Lower) | 32%, 40%, or 50% |
| Available KP Rolls | Sawtooth or Xcut |
Harvest Channel
| Harvest Channel Width | 830 mm |
| Harvest Channel Width | 32.68 in. |
Length Of Cut
| 40 Knife Cutterhead | 7-25 mm LOC in 1 mm steps/ 1,170 rpm |
| 48 Knife Cutterhead | 6-21 mm LOC in 1 mm steps/ 1,170 rpm |
| 56 Knife Cutterhead | 4-18 mm LOC in 1 mm steps/ 1,170 rpm |
| 64 Knife Cutterhead | 3-16 mm LOC in 1 mm steps/ 1,170 rpm |
Cutterhead
| Cutterhead Housing Width | 850 / 670 mm |
| Cutterhead Housing Width | 33.5 / 26.4 in. |
| Speed at Rated Engine Speed | 1,170 / 1,350 (Option) rpm |
| Knife Types Available (Crop) | Straight (grass / universal), Curved (Maize) |
| Number of Knives | 40 – 48 – 56 – 64 |
| Shear Bar, Reversible | Yes |
| Shear Bar Adjust | Long Adjustment or Short Adjustment |
| Shear Bar Options | Grass, Corn, DuraLine |
John Deere XStream KP
| Lubrication | John Deere XStream305 KP: Oil |
| Roll Diameter | 305 mm |
| Roll Diameter | 12 in. |
| Speed Differential / Roll Speed (Lower) | 40%, 50% |
| Bearing Temperature Monitoring System | Standard |
| Available KP Rolls | Sawtooth, Xcut, Small Grains |
Knife Sharpening System
| Reverse Rotation | Standard |
| Automatic from Cab | Remote from cab |
| Sharpening Modes | Grinding and finishing |
Technology Integration
| Yield Monitoring | Harvest Monitor™ - Optional |
| Documentation | Harvest Doc™ - Optional |
| Crop Analysis | Optional with HarvestLab™ |
| Length-of-Cut Control Based on Crop Parameter | AutoLoc™ - Optional with HarvestLab™ |
| Assisted Steering Systems | Optional: AutoTrac™ / Manual RowSense™ / AutoTrac™ RowSense™/Machine Sync |
Additional Information
| Date Collected | 2025-08-01 |
Feedrolls
| Feedroll Frame Opening | Swing away, 37-45 degree (angle) / V-Opening |
| Number of Feedrolls | 4 |
| Stone Detector | Optional |
| Metal Detector | Standard |
| Feeding Channel Width, Front | 830 mm |
| Feeding Channel Width, Front | 32.7 in. |
| Standard Feedroll Drive | Variable |
Kernel Processor
| Kernel Processor Type | Ultimate250™ KP, XStream305™ KP |
| Quick KP Removal | Crane with remote controlled electric hoist |
Serviceability
| Rotary Radiator Screen Cleaner | Rotary radiator screen with active suction blower |
| Automatic Lubrication System | Standard / Central Grease System |
| Interval for Engine Oil Change | 750 hr |
Driveline
| Main Clutch | Hydraulically operated dry-type disk clutch with 3 clutch disks |
| Main Driveband | 8 grooves |
| Belt Tensioning | Hydraulic |
Capacities
| Fuel Tank Capacity | 1500 L |
| Fuel Tank Capacity | 396 gal. |
Electrical System
| Battery Capacity | 1x 154 Ah 2x 154 Ah (in series) amp-hr |
| Alternator Capacity | 12 V, 200 A / 24 V, 140 A |
Transmission
| Transmission Type | Two-speed transmission (ProDrive™) |
| Maximum Travel Speed | 24.8 mph (40 km/h) |
Rear Axle
| Rear Axle Type | Heavy-duty (11.5 t) four-wheel drive / Heavy-duty (11.5 t) two-wheel drive / Heavy-duty (11.5 t) two-wheel drive (4WD ready) |
Spout
| Rotation, Degrees | 210 degree (angle) |
