Features
Weave Automation
This smart feature automatically guides your baler left and right along the windrow, creating consistently well-shaped bales without constant operator input. In addition, the active hitch automatically follows curved windrows, even in corners. The baler precisely tracks the windrow, eliminating missed crop and reducing tractor maneuvers.
Consistent Bales with Little Manual Effort
Baler Automation helps streamline operation by coordinating tractor and baler functions to optimize feeding, bale shape, and density. It helps reduce manual input, minimizes plugging, and improves consistency, allowing operators to maintain efficient, high-quality baling during a long day.
Compatible with specific tractors
High-Capacity Pickup
With a high-capacity pickup system, this baler is designed to deliver increased feeding capacity and efficient crop collection. It offers a 33% increase over the MegaWide(TM) Pickup so you can increase your output per day by 80+ bales.
Available on R Spec Balers only. Compared to previous models.
Specifications
Regular Pickup
| Width - Inside | 1.56 m |
| Width - Inside | 5.17 ft |
| Width - Flare | 1.8 m |
| Width - Flare | 5.92 ft |
| Regular Pick-Up Bars | 4 |
| Number Of Teeth | 96 |
| Tooth Spacing | 6 cm |
| Tooth Spacing | 2.6 in. |
| Lift Control | Adjustable height control |
| Gauge Wheels | Semi-pneumatic |
| Stripper Diameter | 25.4 cm |
| Stripper Diameter | 10 in. |
High-Capacity Pickup
| Type | High Capacity and Cutting (HC) |
| Width - Inside | 1.96 m |
| Width - Inside | 6.42 ft |
| Width - Flare | 2.21 m |
| Width - Flare | 7.25 ft |
| Number Of Middle Teeth | 120 |
| Number Of Mega Teeth | 8 |
| Gauge Wheels | Semi-pneumatic |
| Stripper Diameter | 25.4 cm |
| Stripper Diameter | 10 in. |
Bale
| Size | 1.5 x 1.8 m |
| Size | 5 x 6 ft |
| Diameter | 0.81-1.83 m |
| Diameter | 2.67-6 ft |
| Width | 1.57 m |
| Width | 5.15 ft |
| Full-Size Bale In Dry Crop | 998 kg |
| Full-Size Bale In Dry Crop | 2200 lb. |
| Maximum Allowable For Silage Bale | 1089 kg |
| Maximum Allowable For Silage Bale | 2500 lb. |
Monitor
| Oversize Bale | Yes, audible and mechanical alerts |
| Monitor Console For Tractor | G5e |
| Gate Closed | Symbol on monitor |
| Bale Forming | G5e |
| Bale Size | Mechanical and digital |
| Near Full Bale | Audible, adjustable alert |
| Full Bale | Audible, adjustable alert |
| Twine Arm Position Indicator | Mechanical |
| Auto Wrap | Activates when bale reaches preset size |
Wide Pickup
| Width- Inside | 1.96 m |
| Width- Inside | 6.42 ft |
| Width- Flare | 2.21 m |
| Width- Flare | 7.25 ft |
| Number Of Regular Teeth | 120 |
| Number Of Mega Teeth | 8 |
| Gauge Wheels | Semi-pneumatic |
Tire Size
| Standard | Premium - XL high-flotation 21.5L-16.1, 8 PR |
| Optional | With HC |
Wrapping System
| Control | Automatic to preset to bale size |
| Type- Standard | Electric |
| Twine Arms | 2 |
| Twine Ball Capacity | 10 |
Baler
| Weight - Shipping | 3393 kg |
| Weight - Shipping | 7482 lb. |
| Weight - Shipping Precutter | 4239 kg |
| Weight - Shipping Precutter | 9346 lb. |
| Length - Gate Closed | 3.71 m |
| Length - Gate Closed | 12.17 ft |
| Length - Gate Open | 4.75 m |
| Length - Gate Open | 15.58 ft |
| Height- Gate Closed | 2.79 m |
| Height- Gate Closed | 9.17 ft |
| Height- Gate Open | 3.68 m |
| Height- Gate Open | 12.08 ft |
| Width- With Standard Tires | 2.26 m |
| Width- With Standard Tires | 7.42 ft |
| Width- With Optional Tires (Hi-Flotation) | 2.85 m |
| Width- With Optional Tires (Hi-Flotation) | 9.33 ft |
Tractor Requirements
| Minimum PTO - Dry Hay And Silage | 56 kW |
| Minimum PTO - Dry Hay And Silage | 75 hp |
| Minimum PTO - HC | 93 kW |
| Minimum PTO - HC | 125 hp |
| Hydraulic Selective Control Valves (H-SCV) | One tractor selective control valve (SCV) is required when baler is equipped with electric twine wrap. Two tractor SCVs are required when baler is equipped with hydraulic twine wrap. Three tractor SCVs are required when baler is equipped with hydraulic twine wrap and a hydraulic pickup lift. |
Driveline
| Drive Protection | Premium - cut out clutch |
| PTO Speed | 540, 1000 rpm |
| Type | Constant-velocity (CV) |
| PTO Lockback Collar On Tractor Hookup | Yes |
| PTO 60-Degree Free Rotation | Yes |
Bale Forming
| Belts-Other | DiamondTough, triple-weave, single-ply belts |
| Belts- Number | 8 |
| Belts- Width | 17.8 cm |
| Belts- Width | 7 in. |
| Belts- Texture | Diamond Tread friction surface belts |
| Density Control | Hydraulic |
| Bale Size Indication | Electronic display on monitor |
Additional Information
| Date Collected | 2023-08-22 |
