Features
Reduce Additional Processing with Precutters
Precutters are designed to improve bale density and feed digestibility. This feature helps reduce the need for tub grinding so you can maintain feed quality. 5 ft balers have 20 knives, 4 ft balers have 14 knives.
Consistent Bales with Little Manual Effort
Baler Automation helps streamline operation by coordinating tractor and baler functions to optimize feeding, bale shape, and density. It helps reduce manual input, minimizes plugging, and improves consistency, allowing operators to maintain efficient, high-quality baling during a long day.
Compatible with specific tractors
High-Capacity Pickup System
The high-capacity pickup system is designed to handle large, abrasive windrows effortlessly. This system uses the MegaWide Plus technology, renowned for its ability to produce uniform bales quickly and efficiently, maintaining high performance in varying crop and field conditions.
Specifications
High-Capacity Pickup
| Type | High Capacity and Cutting (HC) |
| Width - Inside | 1.96 m |
| Width - Inside | 6.42 ft |
| Width - Flare | 2.21 m |
| Width - Flare | 7.25 ft |
| Number Of Middle Teeth | 120 |
| Number Of Mega Teeth | 8 |
| Gauge Wheels | Semi-pneumatic |
| Stripper Diameter | 25.4 cm |
| Stripper Diameter | 10 in. |
Bale
| Size | 1.2 x 1.5 m |
| Size | 4 x 5 ft |
| Diameter | 0.81-1.83 m |
| Diameter | 2.67-6 ft |
| Width | 1.17 m |
| Width | 3.83 ft |
| Full-Size Bale In Dry Crop | 449 kg |
| Full-Size Bale In Dry Crop | 1100 lb. |
| Maximum Allowable For Silage Bale | 794 kg |
| Maximum Allowable For Silage Bale | 1750 lb. |
Monitor
| Oversize Bale | Yes, audible and mechanical alerts |
| Monitor Console For Tractor | G5e |
| Gate Closed | Symbol on monitor |
| Bale Forming | G5e |
| Bale Size | Mechanical and digital |
| Near Full Bale | Audible, adjustable alert |
| Full Bale | Audible, adjustable alert |
| Twine Arm Position Indicator | Mechanical |
| Auto Wrap | Activates when bale reaches preset size |
Wrapping System
| Control | Automatic to preset to bale size |
| Type- Standard | Electric |
| Twine Arms | 2 |
| Twine Ball Capacity | 8 |
Tractor Requirements
| Minimum PTO - MegaWide HC | 63.4 kW |
| Minimum PTO - MegaWide HC | 85 hp |
| Hydraulic Selective Control Valves (H-SCV) | One tractor selective control valve (SCV) is required when baler is equipped with electric twine wrap. Two tractor SCVs are required when baler is equipped with hydraulic twine wrap. Three tractor SCVs are required when baler is equipped with hydraulic twine wrap and a hydraulic pickup lift. |
Baler
| Weight - Shipping Precutter | 3691 kg |
| Weight - Shipping Precutter | 8138 lb. |
| Length - Gate Closed | 3.61 m |
| Length - Gate Closed | 11.83 ft |
| Length - Gate Open | 4.55 m |
| Length - Gate Open | 14.92 ft |
| Height- Gate Closed | 2.6 m |
| Height- Gate Closed | 8.53 ft |
| Height- Gate Open | 3.25 m |
| Height- Gate Open | 10.67 ft |
| Width- With Standard Tires | 2.26 m |
| Width- With Standard Tires | 7.42 ft |
| Width- With Optional Tires (Hi-Flotation) | 2.44 m |
| Width- With Optional Tires (Hi-Flotation) | 8 ft |
Tire Size
| Standard | Premium - XL high-flotation 21.5L-16.1, 8 PR |
Driveline
| Drive Protection | Premium - cut out clutch |
| PTO Speed | 540, 1000 rpm |
| Type | Constant-velocity (CV) |
| PTO Lockback Collar On Tractor Hookup | Yes |
| PTO 60-Degree Free Rotation | Yes |
Bale Forming
| Belts-Other | DiamondTough, triple-weave, single-ply belts |
| Belts- Number | 6 |
| Belts- Width | 17.8 cm |
| Belts- Width | 7 in. |
| Belts- Texture | Diamond Tread friction surface belts |
| Density Control | Hydraulic |
| Bale Size Indication | Electronic display on monitor |
Additional Information
| Date Collected | 2023-08-22 |
Regular Pickup
| Gauge Wheels | Semi-pneumatic |
