Features
Helping You Harvest with Confidence
Changing harvest conditions can be overwhelming. John Deere automation takes the pressure off by optimizing combine settings, guiding precise turns, and managing unloads on the go—protecting yield, reducing grain loss, delivering clean samples, and keeping you focused on feeding the machine, and less on adjusting, steering, or unloading.
Make Every Minute of the Harvest Window Count
John Deere delivers harvesting solutions matched to your operation, with a full portfolio of combines and front end equipment to hit your harvest window. Automation like Machine Sync, Auto Unload, and Predictive Ground Speed boost productivity, while integrated technology, parts, and Precision Upgrades help your combine adapt to changing crops and conditions—season after season.
Analyze Key Insights for Better Decisions Next Year
Harvest data becomes next season’s advantage. Yield maps, grain quality, and machine analytics in John Deere Operations Center help refine seed placement, fertility plans, and hybrid selections. Combined with precision upgrades and automation, insights turn into consistent execution—setting the stage for better results next year.
Specifications
Dimensions
| Approximate Overall Width | With 50.8-cm (20-in.) row spacing: 6.5 m (21.17 ft); With 55.9-cm (22-in.) row spacing: 7 m (23 ft) |
| Approximate Overall Width - With 30-in. (76.2 cm) Row Spacing | 9.14 m (30 ft0 |
| Approximate Overall Width - With 36-in. (91.4 cm) Row Spacing | 10.9 m (35.8 ft) |
| Approximate Overall Width - With 38-in. (96.5 cm) Row Spacing | 11.4 m (37.4 ft) |
| Points In Operating Position (Lowered) | With 50.8-cm (20-in.) row spacing: 2.97 m (9.75 ft); With 55.9-cm (22-in.) row spacing: 2.97 m; With 76.2-cm (30-in.) row spacing: 3.2 m (10.58 ft); With 91.4-cm (36-in.) row spacing: 3.2 m; With 96.5-cm (38-in.) row spacing: 3.2 m |
| Points Folded Up (Service Position) | With 50.8-cm (20-in.) row spacing: 2.3 m (7.58 ft); With 55.9-cm (22-in.) row spacing: 2.3 m |
| Points Folded Up - With 30-in. (76.2 cm) Row Spacing | 2.6 m (8.58 ft) |
| Points Folded Up - With 36-in. (91.4 cm) Row Spacing | 2.6 m (8.58 ft) |
| Points Folded Up - With 38-in. (96.5 cm) Row Spacing | 2.6 m (8.58 ft) |
| Points In Operating Position (Lowered) | With 50.8-cm (20-in.) row spacing: 2.97 m (9.75 ft); With 55.9-cm (22-in.) row spacing: 2.97 m; With 76.2-cm (30-in.) row spacing: 3.2 m (10.58 ft); With 91.4-cm (36-in.) row spacing: 3.2 m; With 96.5-cm (38-in.) row spacing: 3.2 m |
| Approximate Shipping Weight (Includes Shipping Skid) - non StalkMaster | With 50.8-cm (20-in.) row spacing: 4534 kg (9996 lb); With 55.9-cm (22-in.) row spacing: 4620 kg (10,185 lb); With 76.2-cm (30-in.) row spacing: 3490 kg (7694 lb); With 91.4-cm (36-in.) row spacing: 5416 kg (11,940 lb); With 96.5-cm (38-in.) row spacing: 5149 kg (11,352 lb) |
| Approximate Shipping Weight (Includes Shipping Skid) - StalkMaster | With 50.8-cm (20-in.) row spacing: 4534 kg (9996 lb); With 55.9-cm (22-in.) row spacing: 4620 kg (10,185 lb); With 76.2-cm (30-in.) row spacing: 3490 kg (7694 lb); With 91.4-cm (36-in.) row spacing: 5416 kg (11,940 lb); With 96.5-cm (38-in.) row spacing: 5149 kg (11,352 lb) |
| Row Spacings | 50.8, 55.9, 76.2, 91.4, or 96.5 cm (20, 22, 30, 36, or 38 in.) |
| Standard Weight - non StalkMaster | With 50.8-cm (20-in.) row spacing: 3561 kg (7851 lb); With 55.9-cm (22-in.) row spacing: 3667 kg (8084 lb); With 76.2-cm (30-in.) row spacing: 3871 kg (8534 lb); With 91.4-cm (36-in.) row spacing: 4132 kg (9110 lb); With 96.5-cm (38-in.) row spacing: 4216 kg (9295 lb) |
| Standard Weight - StalkMaster | With 50.8-cm (20-in.) row spacing: 3965 kg (8741 lb); With 55.9-cm (22-in.) row spacing: 3490 kg (7694 lb); With 76.2-cm (30-in.) row spacing: 4275 kg (9425 lb); With 91.4-cm (36-in.) row spacing: 4534 kg (9996 lb); With 96.5-cm (38-in.) row spacing: 4620 kg (10185 lb) |
Corn Head
| Gathering Points | Four-position, low-profile floating type hinged above gathering chains |
| Center And Outer Gatherings | Hinged, quickly removable |
| Gathering Chains | Heavy-duty, 620, endless steel roller chain with chromed pins (no master connecting link) |
| Minimum Clearance Between Gathering Chains And Ground | 1.25 in. |
| Minimum Clearance Between Gathering Chains And Ground | 32 mm |
| Row Unit Drive | Enclosed, submerged-in-lubricant gearbox, driven by single input hexagon shaft |
| Gathering Chain Adjustment | Spring loaded, self-adjusting |
| Stalk Rolls | Opposed, intermeshing, and chopping (two per row-unit) |
| Deck Plate Adjustment | Hydraulic adjustment |
| Slip Clutch | One per row-unit plus auger drive |
| Trash Knives | Full-length, one-piece, heat-treated steel |
| Stalk Deflectors | Factory-installed option |
Additional Information
| Date Collected | 2020-06-15 |
