Features

Capture More From Every Acre with Confidence

Large green cotton harvester moving through a field of mature cotton plants, with multiple yellow picking units at the front collecting white cotton bolls under an overcast sky

Cotton harvest is where yield turns into profit, and every pass matters. John Deere cotton pickers, strippers, and headers are designed to maximize cotton capture while protecting fiber quality - helping you reduce losses, maintain consistency, and harvest a cleaner crop so you can protect both yield potential and market value.

Keep Harvest Moving When Timing Matters

Green agriculture machinery harvesting cotton in a field, featuring multiple yellow picking heads collecting white cotton bolls under a clear sky

Cotton doesn’t wait for perfect conditions, and neither can your operation. With high-capacity machines, reliable harvesting components, and efficient crop flow from row unit to module, John Deere cotton solutions help you maintain productivity, reduce downtime, and keep harvest moving - so you can finish in the optimal window and avoid costly delays.

Turn Every Pass into Better Decisions

Person working at a desk using a keyboard and mouse while viewing a large monitor displaying a detailed map interface; a laptop and desk lamp sit nearby in a bright workspace

Cotton harvest generates more than bales - it generates insight. With integrated technology and connectivity, John Deere cotton pickers and strippers capture key data on yield, moisture, and module performance. That information flows into John Deere Operations Center™, helping you track results, improve decisions, and better manage your crop from harvest through ginning.

Specifications

Row Units

Number Of Rows8
Spacings36 in. (91.4 cm), 38 in. (96.5 cm), 40 in. (101.6 cm), Six-row single skip: 40 in. (101.6 cm)
FrameRigid
Cross Auger TypeHigh-capacity with single flight auger: 13 in. (33.2 cm)
Cross Auger Diameter13 in.
Cross Auger Diameter33.2 cm
Brush Roll Diameter6 in.
Brush Roll Diameter15.2 cm
Brush Roll Length40 in.
Brush Roll Length101.6 cm
Unit Auger Diameter5.75 in.
Unit Auger Diameter14.6 cm
Cross Auger Speed (Forward)500-700 rpm
Cross Auger Speed (Reverse)300 rpm
Brush Roll Speed500-700 rpm
Unit Auger Speed500-700 rpm

Stripping Units

Stripping Unit StyleBat/brush stripping units
Stripping Unit Drive ProtectionSlip clutch, one per unit
