Features
Electrohydraulic (EH) Controls
Electrohydraulic (EH) controls provide enhanced functionality, allowing operators to customize machine operations. This includes soft hydraulic stops and programmable joystick buttons. These features empower operators with increased productivity across various jobsite tasks.
Vision and Detection Systems
Active jobsites present many operational challenges, including multiple machines, crew members, and bystanders. The John Deere Advanced Vision System (AVS) and SmartDetect™ can help enhance operator awareness to confidently navigate busy work areas.
Payload Weighing Systems
SmartWeigh delivers dynamic weighing without slowing down the job—no workflow interruption or boom reset needed. Easily viewed on the onboard monitor and integrated with the John Deere Operations Center, it’s available as a factory or field‑installed option.
Specifications
Engine
| Manufacturer | John Deere |
| Model | PowerTech™ PSS 4045 |
| Non-Road Emission Standards | EPA Final Tier 4/EU Stage V |
| Cylinders | 4 |
| Valves Per Cylinder | 4 |
| Displacement | 4.5 L |
| Displacement | 276 cu in. |
| Net Peak Power | 2100 rpm |
| Net Peak Power At Rated RPM (ISO 9249) | 92.5 kW |
| Net Peak Power At Rated RPM (ISO 9249) | 124 hp |
| Gross Peak Power | 1800 rpm |
| Gross Peak Power At Rated RPM (ISO 9249) | 103 kW |
| Gross Peak Power At Rated RPM (ISO 9249) | 138 hp |
| Net Peak Torque | 1400 rpm |
| Net Peak Torque At Rated RPM (ISO 9249) | 531.5 Nm |
| Net Peak Torque At Rated RPM (ISO 9249) | 392 lb-ft |
| Gross Peak Torque | 1400 rpm |
| Gross Peak Torque At Rated RPM (ISO 9249) | 549 Nm |
| Gross Peak Torque At Rated RPM (ISO 9249) | 405 lb-ft |
| Net Torque Rise | 34 % |
| Fuel System (Electronically Controlled) | High-Pressure common rail |
| Lubrication | Full-flow spin-on filter and integral cooler |
| Aspiration | Turbocharged, charge air cooled |
| Air Cleaner | Under-hood, dual-element dry type, restriction indicator in cab monitor for service |
Transmission System
| Type | Countershaft-type PowerShift™ |
| Torque Converter | Single-stage, single-phase |
| Shift Control | Electronically modulated, adaptive, load and speed dependent |
| Operator Interface | Steering-column or joystick-mounted F-N-R and gear-select lever; kick-down button on hydraulic lever |
| Shift Modes | Manual/auto (1st-D or 2nd-D); Quick shift button with 2 selectable modes: kick-down or kick-up/down; and 4 clutch cutoff setting |
Serviceability
| Fuel Tank (With Lockable Cap) Refill Capacity | 227.1 L |
| Fuel Tank (With Lockable Cap) Refill Capacity | 60 gal. |
| Cooling System Refill Capacity | 23.7 L |
| Cooling System Refill Capacity | 25 qt |
| Diesel-Exhaust Fluid (DEF) Refill Capacity | 15.6 L |
| Diesel-Exhaust Fluid (DEF) Refill Capacity | 16.5 qt |
| Engine Oil With Vertical Spin-On Filter Refill Capacity | 14.5 L |
| Engine Oil With Vertical Spin-On Filter Refill Capacity | 15.3 qt |
| Transmission Reservoir With Vertical Filter Refill Capacity | 73.8 L |
| Transmission Reservoir With Vertical Filter Refill Capacity | 19.5 gal. |
| Axle Oil Without Coolers (Front And Rear, Each) Refill Capacity | 87.1 L |
| Axle Oil Without Coolers (Front And Rear, Each) Refill Capacity | 23 gal. |
| Hydraulic Reservoir With Filter Refill Capacity | 82.2 L |
| Hydraulic Reservoir With Filter Refill Capacity | 21.7 gal. |
| Parking Brake Oil (Wet Disc) Refill Capacity | 0.35 L |
| Parking Brake Oil (Wet Disc) Refill Capacity | 12 oz. |
Wheels And Tires
| Tire Size Used To Measure | Michelin 17.5 R 25, 1 Star L-3 |
| Tread Width On Standard Tires | 1900 mm |
| Tread Width On Standard Tires | 74.8 in. |
| Width Over Tires On Standard Tires | 2415.5 mm |
| Width Over Tires On Standard Tires | 95.1 in. |
Maximum Forward Travel Speeds (Standard 5-Speed With Lockup Torque Converter)
| Tire Size Used To Measure Travel Speeds | 17.5R25 |
| Range 1 | 7.4 km/h |
| Range 1 | 4.6 mph |
| Range 2 | 12.2 km/h |
| Range 2 | 7.6 mph |
| Range 3 | 23.3 km/h |
| Range 3 | 14.5 mph |
| Range 4 | 35.2 km/h |
| Range 4 | 21.9 mph |
Axles And Brakes
| Final Drives | Heavy-duty mid-board planetary |
| Standard Differentials Front | Hydraulic locking |
| Standard Differentials Rear | Conventional |
| Optional Differentials Front | Dual locking |
| Optional Differentials Rear | Dual locking |
| Tire Size Used To Measure Oscillation | 17.5 R 25 |
| Rear Axle Oscillation, Stop To Stop, With 17.5 R 25 Tires | 24 degrees |
| Rear Axle Oscillation, Distance Each Direction | 12 degrees |
| Service Brakes (ISO 3450) | Outboard, forced oil cooled, multi disc |
| Parking Brake (ISO 3450) | Automatic spring applied, hydraulically released, driveline mounted, sealed wet multi disc |
Electrical And Lighting
| System Type | 24 volt with 100-amp alternator (140 amp alternator optional) |
| Battery Voltage | 12 V |
| Number Of Batteries | 2 |
| Battery Capacity Per Each | 950 CCA |
| Standard Alternator Rating | 100 amp |
| Optional Alternator Rating | 140 amp |
Hydraulic System And Steering
| Pump Type And System (Loader And Steering) | Variable-displacement, axial-piston pump; closed-center, pressure-compensating system |
| Rated RPM | 2350 rpm |
| System Pressure At Max Rated Flow | 6894.8 kPa |
| System Pressure At Max Rated Flow | 1000 psi |
| Max Rated Flow At Rated RPM | 136.3 L/min |
| Max Rated Flow At Rated RPM | 36 gpm |
| System Relief Pressure (Loader And Steering) | 24821.2 kPa |
| System Relief Pressure (Loader And Steering) | 3600 psi |
| Loader Controls | Two-function valve; joystick control or fingertip controls; hydraulic function enable/disable; optional third with roller or auxiliary lever and fourth function valve with dual roller |
| Steering Type (ISO 5010) | Power, fully hydraulic |
| Steering Articulation Full Arc Angle | 80 degrees |
| Steering Articulation Angle Each Direction | 40 degrees |
| Turning Radius (Measured To Centerline Of Outside Tire) | 4.75 m |
| Turning Radius (Measured To Centerline Of Outside Tire) | 15.58 ft, in. |
| Hydraulic Raise Cycle Time | 5.8 seconds |
| Hydraulic Dump Cycle Time | 1.4 seconds |
| Hydraulic Lower (Power Down) Cycle Time | 4 seconds |
| Hydraulic Total Cycle Time | 11.2 seconds |
Cooling
| Fan Drive Type | Hydraulically Driven, Proportionally Controlled, Fan Aft of Coolers |
