Features
Work Confidently in Tight, Congested Jobsites
A reduced‑tail‑swing design allows the 75 P‑Tier to maneuver easily in confined areas while maintaining stability—ideal for urban, roadside, and utility applications.
Get More Done With Increased Power and Performance
With ~67 hp, increased digging forces, and improved hydraulic pressure, this machine delivers the strength needed for trenching, lifting, and material movement without stepping into larger classes.
Stay Productive With Comfort and Visibility
An all‑new larger cab, 270° camera system, and intuitive controls help operators stay comfortable and aware—improving efficiency and confidence across long shifts
Specifications
Powertrain
| Powertrain type | 2-speed propel with automatic shift |
| Maximum travel speed low/slow (mph) | 1.9 mph |
| Maximum travel speed low/slow (km/h) | 3.1 km/h |
| Maximum travel speed high/fast (mph) | 3.1 mph |
| Maximum travel speed high/fast (km/h) | 5 km/h |
| Drawbar pull (kg) | 7240 kg |
| Drawbar pull (lb) | 15961 lb. |
Refill Capacities
| Fuel tank (gal.) | 33 gal. |
| Fuel tank (L) | 125 L |
| Cooling system (qt) | 14 qt |
| Cooling system (L) | 13.1 L |
| Engine oil with filter (qt) | 12.8 qt |
| Engine oil with filter (L) | 12.3 L |
| Hydraulic tank (gal.) | 14 gal. |
| Hydraulic tank (L) | 52 L |
| Hydraulic system (gal.) | 26 gal. |
| Hydraulic system (L) | 100 L |
| Propel gearbox (qt) | 1.3 qt |
| Propel gearbox (L) | 1.2 L |
Undercarriage
| Number of carrier rollers per side | 1 |
| Number of track rollers per side | 5 |
| Number of shoes per side | 40 |
| Track adjustment type | Hydraulic |
| Track chain type | Sealed and lubricated |
Engine
| Manufacturer | Yanmar |
| Model | 4TNV98CT |
| Non-road emission standards | EPA Final Tier 4/EU Stage IV |
| Net power (rpm) | 2000 rpm |
| Net power at net power rpm (ISO 9249) (hp) | 67.6 hp |
| Net power at net power rpm (ISO 9249) (kW) | 50.4 kW |
| Cylinders | 4 |
| Displacement (cu in.) | 202 cu in. |
| Displacement (L) | 3.3 L |
| Off-level capacity (%) | 70 % |
| Off-level capacity (degrees) | 35 degrees |
| Aspiration type | Turbocharger |
Hydraulics
| Hydraulics type | Open center, load sensing |
| Main pump type | 3 variable-displacement axial-piston pumps |
| Number of pumps | 2 |
| Main pump maximum rated flow per pump (gpm) | 15 gpm |
| Main pump maximum rated flow per pump (L/min) | 56 L/min |
| Pilot pump number of gears | 1 |
| Pilot pump maximum rated flow (gpm) | 5.3 gpm |
| Pilot pump maximum rated flow (L/min) | 20 L/min |
| Pilot pump pressure setting (psi) | 624 psi |
| Pilot pump pressure setting (kPa) | 4300 kPa |
| Implement circuits system operating pressure (psi) | 4061 psi |
| Implement circuits system operating pressure (kPa) | 28000 kPa |
| Travel circuits system operating pressure (psi) | 4583 psi |
| Travel circuits system operating pressure (kPa) | 31600 kPa |
| Swing circuits system operating pressure (psi) | 3785 psi |
| Swing circuits system operating pressure (kPa) | 26100 kPa |
| Controls type | Pilot levers, short stroke, low effort; hydraulic pilot controls with shutoff lever |
Cylinders
| Cylinders type | Heat-treated, chrome-plated, polished cylinder rods; hardened steel (replaceable bushings) pivot pins |
| Number of boom cylinders | 1 |
| Boom cylinder bore (in.) | 4.5 in. |
| Boom cylinder bore (mm) | 115 mm |
| Boom cylinder rod diameter (in.) | 2.8 in. |
| Boom cylinder rod diameter (mm) | 70 mm |
| Boom cylinder stroke (in.) | 34.8 in. |
| Boom cylinder stroke (mm) | 885 mm |
| Number of arm cylinders | 1 |
| Arm cylinder bore (in.) | 3.7 in. |
| Arm cylinder bore (mm) | 95 mm |
| Arm cylinder rod diameter (in.) | 2.4 in. |
| Arm cylinder rod diameter (mm) | 60 mm |
| Arm cylinder stroke (in.) | 35.4 in. |
| Arm cylinder stroke (mm) | 900 mm |
| Number of bucket cylinders | 1 |
| Bucket cylinder bore (in.) | 3.3 in. |
| Bucket cylinder bore (mm) | 85 mm |
| Bucket cylinder rod diameter (in.) | 2.2 in. |
| Bucket cylinder rod diameter (mm) | 55 mm |
| Bucket cylinder stroke (in.) | 28.7 in. |
| Bucket cylinder stroke (mm) | 730 mm |
Swing Mechanism
| Speed (rpm) | 10.1 rpm |
| Torque (lb-ft) | 16600 lb-ft |
| Torque (Nm) | 12244 Nm |
Electrical
| Battery voltage (V) | 12 V |
| Number of batteries | 2 |
| Battery capacity (CCA) | 450 CCA |
| Alternator rating (amp) | 60 amp |
| Work lights | 2 LED (1 mounted on boom, 1 on frame) |
Cooling
| Cooling system type | Variable-speed fan; viscous clutch |
