Features
High-Power Performance
Packed with 118 hp (87.9 kW), the 334 P‑Tier delivers the power operators need to tackle demanding tasks like grading, material handling, and site development with confidence.
Premium Operator Comfort and Controls
Standard features include a heated and ventilated seat, touchscreen display, adjustable controls, and EH dual leveling—helping operators stay comfortable, focused, and productive all day.
Productivity‑Driven Hydraulics and Uptime Features
High‑flow hydraulics, ride control, optimized cooling, and increased fuel and DEF capacity are designed to keep the machine running efficiently through long, demanding workdays.
Specifications
Machine Dimensions
| Length Without Bucket (in.) | 125.2 in. |
| Length Without Bucket (ft, in.) | 10, 5 ft, in. |
| Length With Foundry Bucket (in.) | 150.7 in. |
| Length With Foundry Bucket (ft in.) | 12, 7 ft, in. |
| Width Without Bucket (in.) | 76.6 in. |
| Width Without Bucket (ft in.) | 6, 5 ft, in. |
| Height To Top Of Rollover Protective Structure (ROPS) (in.) | 87 in. |
| Height To Top Of Rollover Protective Structure (ROPS) (ft in.) | 7, 3 ft, in. |
| Height To Hinge Pin (in.) | 131 in. |
| Height To Hinge Pin (ft in.) | 11, 0 ft, in. |
| Dump Height, Foundry Bucket (in.) | 106.7 in. |
| Dump Height, Foundry Bucket (ft in.) | 8, 11 ft, in. |
| Dump Reach, Foundry Bucket (in.) | 31.9 in. |
| Dump Reach, Foundry Bucket (ft in.) | 2, 8 ft, in. |
| Dump Reach, Construction Bucket (in.) | 37 in. |
| Dump Reach, Construction Bucket (ft in.) | 3,1 ft, in. |
| Wheelbase (in.) | 49.91 in. |
| Wheelbase (ft in.) | 4, 2 ft, in. |
| Ground Clearance (in.) | 9.7 in. |
| Ground Clearance (ft in.) | 0, 10 ft, in. |
| Angle Of Departure Degree | 23.5 degree (angle) |
| Front Turn Radius, Foundry Bucket (in.) | 84.3 in. |
| Front Turn Radius, Foundry Bucket (ft in.) | 7, 0 ft, in. |
| Dump Angle (Full Lift Height) Degree | 48 degree (angle) |
| Bucket Rollback (Ground Level) Degree | 35 degree (angle) |
| Advertised Tipping Load (lb) | 8000 lb. |
| Advertised SAE Rated Operating Capacity (lb) | 4000 lb. |
| Boom Breakout Foundry Bucket (lb) | 8500 lb. |
| Boom Breakout Construction Bucket (lb) | 7900 lb. |
| Bucket Breakout Foundry Bucket (lb) | 13800 lb. |
| Bucket Breakout Construction Bucket (lb) | 9500 lb. |
Hydraulics
| Standard Pump Flow (gpm) | 25 gpm |
| High Flow Option Total Pump Flow (gpm) | 44 gpm |
| System Pressure At Couplers (psi) | 3450 psi |
| Optional High Pressure System Pressure At Couplers (psi) | 4000 psi |
| Hydraulic Horsepower Standard Flow (calculated) (hp) | 50.32 hp |
| Hydraulic Horsepower High Flow (calculated) (hp) | 88.56 hp |
| Hydraulic Horsepower High Flow/High Pressure (calculated) (hp) | 102.68 hp |
Powertrain
| Controls Type | Electrohydraulic |
| Travel Speed High (mph) | 12 mph |
| Tractive Effort (lbf) | 9300 lbf |
| Final Drive | Chains high strength, adjustment free |
| Parking Brake Type | Spring applied, hydraulically released wet-disk park brake |
Operating Weight
| Machine Configuration That Will Produce Base Machine Weight (ISO 6016) | Base Machine |
| Base Machine Weight (lb) | 10264 lb. |
Serviceability
| Fuel Tank (gal.) | 35.5 gal. |
| Fuel Tank (L) | 35.5 L |
Monitoring
| Alternator, Low Voltage | Indicator light |
| Auxiliary Hydraulics | Indicator light |
| Battery Voltage | Digital |
| Diagnostics | Digital |
| Engine Air Filter Restriction Indicator | Indicator light |
| Engine Coolant Temperature | Indicator light, Gauge, Digital |
| Engine Oil Pressure | Indicator light |
| Engine RPM Indicator | Digital |
| Fuel Gauge | Gauge |
| Diesel Exhaust Fluid (DEF) Level Indicator | Audible warning, Gauge |
| Hourmeter | Digital |
| Hydraulic Oil Filter Restriction | Indicator light |
| Hydraulic Oil Temperature | Indicator light, Gauge, Digital |
| Park Brake Engaged | Indicator light |
| Warm-Up Indicator | Indicator light, Digital |
Engine
| Manufacturer | Yanmar® |
| Model | 4TNV94FHT |
| Non-Road Emission Standards | EPA Final Tier 4 |
| Engine Cylinders | 4 |
| Net Power (SAE J1349, ISO 9249) At 2500 RPM (HP) | 115.33 hp |
| Rated Gross Power (ISO 14396) At 2500 RPM (HP) | 118 hp |
| Peak Torque At 1700 RPM (lb-ft) | 291.34 lb-ft |
| Displacement (cu in.) | 186.33 cu in. |
| Rated Engine Speed (RPM) | 2500 rpm |
| Torque Rise At 1700 RPM (percent) | 39 % |
| Aspiration | Turbocharged, intercooled |
| Air Cleaner | Dry dual element |
Cylinders
| Cylinders Type | John Deere heat treated, chrome-plated, polished cylinder rods, hardened steel (replaceable bushings) pivot pins |
Electrical
| Voltage (V) | 12 V |
| Battery capacity (CCA) | 950 CCA |
| Alternator Rating (amp) | 120 amp |
| Lighting Options | Halogen, Two (2) Front and One (1) Rear |
Operator Station
| Structure | ROPS (ISO3471) FOPS (ISO3449) Structure with Quick Pivot |
Tires and Wheels
| Standard Tire Size | 14X17.5 14 PR Galaxy Hulk |
Cooling
| Fan Drive Type | Variable speed hydraulic drive |
