John Deere TR60B Trencher

New Products / John Deere / John Deere Products / Construction Equipment / Construction Attachments / TR60B Trencher

Double tap to zoom



Features

Heavy-Duty Planetary Drive

Front left view of a 300 series compact wheel loader using a TR series trencher at a dirt jobsite

The trencher features a heavy-duty planetary-drive design, leveraging more hydraulic horsepower from high-flow hydraulics. This design is optimal for high-duty cycles in commercial and heavy construction applications, offering robust performance.

Trencher Chain Options

Black and white computer sketch of a short strand of trencher chain

The trencher comes with varied chain options suitable for different digging conditions. The "standard cup every station" chain is designed for moderately compacted soils, while the 70/30 combination shark tooth chain is for heavier-duty applications like rocky soils.

Convenient Two-Position Manual Side Shift

Front view of a TR series trencher attached to a loader traveling down a street

Equipped with a two-position manual side shift, the trencher can trench close to structures. This feature enhances functionality and adaptability on commercial construction sites, allowing for precision trenching in tight spaces.

Specifications

Digging Chain

Chain TypeDouble standard anti-back flex
Chain Rating22680 kg
Chain Rating50000 lb.
Chain Pitch51 mm
Chain Pitch2 in.
Chain Width - Standard Cup Teeth Option 1152 mm
Chain Width - Standard Cup Teeth Option 16 in.
Chain Width - 70/30 Combo Shark Teeth152 mm
Chain Width - 70/30 Combo Shark Teeth6 in.

Dimensions

Weight606 kg
Weight1335 lb.
Length2388 mm
Length94 in.
Width1397 mm
Width55 in.
Height813 mm
Height32 in.

Operation

Trench Depth at 65-Degree Trenching Angle1524 mm
Trench Depth at 65-Degree Trenching Angle60 in.
Side Shift, Right of Center432 mm
Side Shift, Right of Center17 in.
Spoil-Discharge Reach610 mm
Spoil-Discharge Reach24 in.

Hydraulics

102-132 L/min (24-35 gpm) High-Flow Motor OptionOptional
136-167 L/min (36-44 gpm) High-Flow Motor OptionOptional
Maximum Operating Pressure24132 kPa
Maximum Operating Pressure3500 psi

Vehicle Compatibility

Hydraulic Connection (High Flow)12.7-mm (0.5-in.) quick-connect couplers with 9.525-mm (0.375-in.) case-drain coupler
Compact Track Loader325G, 331G, 333G
Skid Steer Loader320G, 324G, 330G, 332G
