John Deere RR72 Root Rake

Double tap to zoom



Features

Minimize Downtime with Rugged Design

Studio front left view of a black RR84 Root Rake, jaws closed

Constructed with alloy-steel and featuring replaceable pin-on teeth, the rake resists impact and reduces downtime. Its height and width provide protection against large debris, while a rake heel profile aids in tool storage and scarifying hard ground.

Finish the Job Quicker

Side right view of a 332G Skid Steer with RR84 Root Rake jaws open wide on a mound of dirt at a dirt-and-forested jobsite.

The root rake is designed for land clearing, ground leveling, and moving materials away from obstructions efficiently and economically, outperforming dozer blades. Its large tine spacing allows users to gather rocks and debris while permitting soil to pass through, minimizing site disturbance.

Compatibility Across Machines

Side left view of an RR84 Root Rake clutching logs on a 332G Skid Steer

This root rake is optimized for compatibility with John Deere G- and E-Series Skid Steers, Compact Track Loaders, and L-Series Compact Wheel Loaders. It is also adaptable for many competitive models, enhancing its utility across different equipment.

Specifications

Grapple

Grapple Width1780 mm
Grapple Width70 in.
Grapple Opening1295 mm
Grapple Opening51 mm

Dimensions

Overall Width1830 mm
Overall Width72 in.
Overall Height990 mm
Overall Height38.9 in.
Overall Length780 mm
Overall Length30.8 in.
Tooth Position635 mm
Tooth Position25 in.
Tine Spacing240 mm
Tine Spacing9.5 in.
Weight497 kg
Weight1095 lb.

Cylinders

Bore95 mm
Bore2.5 in.
Stroke230 mm
Stroke9 in.
Rod Diameter40 mm
Rod Diameter1.5 in.

Vehicle Compatibility

Compact Track Loader317G, 325G
Compact Wheel Loader (Requires Skid-Steer Style Quik-Tatch™ Coupler for Operation)204L, 304L
Skid Steer Loader318G, 320G, 324G, 330G
