John Deere MH72D Mulching Head

Double tap to zoom



Features

Designed for Durability and Flexibility

Designed for Durability and Flexibility

These mulching heads, built for John Deere and compatible loaders, feature a durable steel frame, efficient mulching chamber, and smooth rotor design that reduces drag and power use. An adjustable push bar and sealed rotor bearings enhance versatility and long-term performance.

Efficient Mulching Capabilities

Skid steer loader using a front-mounted mulching head to grind branches in a dry, brushy area in front of a house

Equipped with a two-speed hydraulic system and 36 double-carbide-tipped teeth, the mulching head efficiently processes up to 8-in. (20.3-cm) trees and 12-in. (30.5-cm) stumps. Its redesigned chamber optimizes material flow and reduces wear, delivering high-quality mulch quickly and effectively.

Prominent Pressure Gauge

Close-up of hydraulic pressure gauge mounted, showing color-coded pressure ranges in green, yellow, and red, with braided hoses and a warning label visible on the metal housing.

Prominently positioned pressure gauge that is visible from the cab lets operators easily monitor hydraulic operating pressure for optimized performance.

Specifications

Hydraulics

Hydraulics TypeHigh Flow
Minimum Flow91 L/min
Minimum Flow24 gpm
Maximum Flow170 L/min
Maximum Flow45 gpm
Maximum Operating Pressure28000 kPa
Maximum Operating Pressure4000 psi

Mulching Head

Overall Width2160 mm
Overall Width85 in.
Cutting Width1830 mm
Cutting Width72 in.
Height1600 mm
Height63 in.
Length1760 mm
Length69 in.
Weight1434 kg
Weight3155 lb.

Vehicle Compatibility

Hydraulic Connection19.05-mm (0.75-in.) quick connect couplers with 9.525-mm (0.375 in.) case drain coupler
Electrical Connection14-pin Duetsch connector
Compact Track Loaders333 P-Tier, 335 P-Tier
Skid Steer Loaders334 P-Tier

Cutting Tools

Cutting Tool Type, StandardDouble-carbide tipped tool
Cutting Tool Type, OptionalKnife tool
Number of Cutting Tools with Smooth Rotor30
