John Deere BR84C Rigid Pick-Up Broom

Double tap to zoom



Features

No Tools Required for Bristle Replacement

A front-end loader with a brom attachment sweeping a dusty surface outside an industrial building, with other construction equipment parked in the background under a blue sky

Brush-core removal for bristle replacement is quick and easy, with no tools required. Motor and bearing separate from the brush core without having to disconnect any hydraulic hoses, eliminating the risk of oil spills or contamination.

Ideal for Many Applications

Front view of a BP84C pick-up broom with optional roof-mounted water tank cleaning the street along a curb on the front of a skid steer

John Deere BP and BR model brooms are ideal for light- to heavy-duty construction clean-up, street clean-up, and a variety of ag applications. Pick-up style brooms are designed to remove and carry debris for later disposal.

Less Dumping With Increased Hopper Capacity

Side‑view schematic showing material moving through a machine housing toward a rotating brush

Adjustable baffle on BP and BR models increases hopper capacity by 22 percent for greater sweeping impact in each pass. With increased hopper capacity, dumping is required less often.

Specifications

Broom

Overall Length1550 mm
Overall Length61 in.
Overall Width2370 mm
Overall Width93 in.
Sweeping Width2130 mm
Sweeping Width84 in.
Overall Height790 mm
Overall Height31 in.
Weight500 kg
Weight1090 lb.
Hopper Capacity0.56 m³
Hopper Capacity20 cu ft
Bolt-On Cutting Edge, StandardDouble bevel, 15.9 x 152 mm (0.625 x 6 in.)

Options

Gutter Brush Diameter510 mm
Gutter Brush Diameter20 in.
Gutter Brush Mounting LocationRight/left
Gutter Brush Bristle Material, StandardAll wire bristles
Gutter Brush Bristle Material, OptionalAll polypropylene bristles
Broom-Mounted Water Tank Capacity95 L
Broom-Mounted Water Tank Capacity25 gal.
Broom-Mounted Water Tank Pump Flow7.9 L/min
Broom-Mounted Water Tank Pump Flow2.1 gpm
Roof-Mounted Water Tank Capacity114 L
Roof-Mounted Water Tank Capacity30 gal.
Roof-Mounted Water Tank Pump Flow6.8 L/min
Roof-Mounted Water Tank Pump Flow1.8 gpm

Brush

Brush Diameter660 mm
Brush Diameter26 in.
Core Diameter200 mm
Core Diameter8 in.
Numbers of Wafers49
Brush Segments, Standard50/50 poly and wire mix
Brush Segments, OptionalAll polypropylene bristles

Hydraulics

Minimum Hydraulic Flow57 L/min
Minimum Hydraulic Flow15 gpm
Maximum Hydraulic Flow95 L/min
Maximum Hydraulic Flow25 gpm
Motor Pressure Relief Setting17000 kPa
Motor Pressure Relief Setting2500 psi

Vehicle Compatibility

Electrical ConnectionNone
Hydraulic Connection1/2 in. quick connect couplers
Compact Track Loader325G, 331G, 333G
Compact Wheel Loader (Requires Skid Steer Style Quick Coupler for Operation)204L, 244L, 304L, 324L
Skid Steer Loader320G, 324G, 330G, 332G
