Features
Automatic Mast Latch for Easy Removal
The loader is equipped with an automatic mast latch system, simplifying the process of attaching and detaching the loader. This system allows for easy parking and enhances operational uptime by enabling the loader to latch with minimal effort.
Concealed Oil Lines for Protection
The R Series Loaders are designed to route the oil lines and hydraulic lines through the boom arm and the torque tube. This internal routing ensures better protection of the lines from external damage and improves the overall appearance of the loader.
Single-Point Hydraulic Connection
The R Series Loaders feature a single-point hydraulic connection that streamlines the process of attaching and detaching the loader. This system combines all hydraulic and electrical connections into one location for efficient installation with a simple handle pull.
Specifications
Tractor
| Model | 6110R/M, 6120R/M, 6130R/M |
| Front Tire | 480/70R24 |
| Rear Tire | 520/70R38 |
| Front Axle Configuration | MFWD with Limited Slip Differential |
| Wheelbase | 2580 mm |
| Wheelbase | 101 in. |
| Pump Capacity | 114 L/min |
| Pump Capacity | 30.1 gpm |
| Rated Pressure | 200 bar |
| Rated Pressure | 2900 psi |
Loader
| Base Weight | 2072.3 kg |
| Base Weight | 4568.6 lb. |
| Leveling Configuration | Non-Self Leveling (NSL) |
| Bucket Used | Heavy-duty grapple 2450 mm / Heavy-duty grapple 96 in. |
| Bucket Weight | 375 kg |
| Bucket Weight | 826 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 2515 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 5545 lb. |
| Lift Capacity At Full Height - Measured At 800 mm Ahead Of Pivot | 1757 kg |
| Lift Capacity At Full Height - Measured At 800 mm Ahead Of Pivot | 3874 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 2654 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 5851 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At 800 mm Ahead Of Pivot (X) | 2080 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At 800 mm Ahead Of Pivot (X) | 4586 lb. |
| Boom Breakout Force - Measured At Pivot (Y) | 2814 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 6204 lb. |
| Boom Breakout Force - Measured At 800 mm Ahead Of Pivot (Z) | 2114 kg |
| Boom Breakout Force - Measured At 800 mm Ahead Of Pivot (Z) | 4661 lb. |
| At Maximum Height (VV) | 2509 kg |
| At Maximum Height (VV) | 5531 lb. |
| At 59-in. (1500 mm) Lift Height (XX) | 4301 kg |
| At 59-in. (1500 mm) Lift Height (XX) | 9482 lb. |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 4365 kg |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 9623 lb. |
| Maximum Lift Height (A) | 4151 mm |
| Maximum Lift Height (A) | 163 in. |
| At Full Height - Bucket Level (B) | 3911 mm |
| At Full Height - Bucket Level (B) | 154 in. |
| Clearance At Full Height - Bucket Dumped | 3141 mm |
| Clearance At Full Height - Bucket Dumped | 124 in. |
| Overall Length (I+F) | 5400 mm |
| Overall Length (I+F) | 211 in. |
| Digging Depth (H) | 53 mm |
| Digging Depth (H) | 2 in. |
| Reach - At Maximum Height (D) | 993 mm |
| Reach - At Maximum Height (D) | 39 in. |
| Reach - At Ground Level - Bucket Level | 2809 mm |
| Reach - At Ground Level - Bucket Level | 111 in. |
| Dump Angle (E) | 59 degree (angle) |
| Rollback Angle (G) | 52 degree (angle) |
| Dump Angle, Ground | 144 degree (angle) |
| Loader Raise | 3.5 seconds |
| Loader Lower | 2.63 seconds |
| Bucket Dump | 2.65 seconds |
| Bucket Rollback | 1.81 seconds |
