Features
Concealed Oil Lines for Protection
Wider tractor hoods have reduced space for traditional oil line routing along the boom, increasing the risk of damage. To address this, the oil lines are now routed through the boom arm and torque tube, enhancing protection and improving the loader’s appearance.
Boom Lockout for Easy Service
A hydraulic shut-off valve prevents the loader from lowering unexpectedly, enabling safe maintenance under the boom.
Single-Point Hydraulic Connection Saves Time
A single-point hydraulic connection saves operators time when attaching or detaching the loader. This system also includes connections for electrical needs and a hydraulic lockout valve, allowing for fast installation via a simple handle pull.
Specifications
Tractor
| Wheelbase | 92.52 in. |
| Wheelbase | 2350 mm |
| Rear Tire | 16.9R34 |
| Pump Capacity | 70 L/min |
| Pump Capacity | 18.49 gpm |
| Rated Pressure | 195 bar |
| Rated Pressure | 2828.24 psi |
| Model | 5M Tractor Series |
| Front Axle Configuration | MFWD |
| Front Tire | 13.6R24 |
Loader
| Boom Breakout Force - Measured At Pivot (Y) | 2243 kg |
| Boom Breakout Force - Measured At 800 mm Ahead Of Pivot (Z) | 1567 kg |
| At Maximum Height (VV) | 3688 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At 800 mm Ahead Of Pivot (X) | 1576 kg |
| Loader Lower | 3.18 seconds |
| Bucket Dump | 3.32 seconds |
| Dump Angle (E) | 63.75 degree (angle) |
| At 59-in. (1500 mm) Lift Height (XX) | 2712 kg |
| Maximum Lift Height (A) | 141.53 in. |
| Lift Capacity At Full Height - Measured At 800 mm Ahead Of Pivot | 2844 lb. |
| Bucket Used | 1850 mm / 73 in. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 2101 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 4246 lb. |
| At Maximum Height (VV) | 1673 kg |
| Base Weight | 1215.1 kg |
| Clearance At Full Height - Bucket Dumped | 100.94 in. |
| Reach - At Ground Level - Bucket Level | 93.88 in. |
| At 59-in. (1500 mm) Lift Height (XX) | 5979 lb. |
| Lift Capacity At Full Height - Measured At 800 mm Ahead Of Pivot | 1290 kg |
| Maximum Lift Height (A) | 3595 mm |
| Reach - At Maximum Height (D) | 31.26 in. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 4632 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 1926 kg |
| At Full Height - Bucket Level (B) | 3355 mm |
| Clearance At Full Height - Bucket Dumped | 2564 mm |
| Bucket Weight | 619 lb. |
| Reach - At Ground Level - Bucket Level | 2385 mm |
| Loader Raise | 4.25 seconds |
| Digging Depth (H) | 5.47 in. |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 2609 kg |
| Reach - At Maximum Height (D) | 794 mm |
| Rollback Angle (G) | 47 degree (angle) |
| Boom Breakout Force - Measured At Pivot (Y) | 4945 lb. |
| Boom Breakout Force - Measured At 800 mm Ahead Of Pivot (Z) | 3455 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At 800 mm Ahead Of Pivot (X) | 3474 lb. |
| Leveling Configuration | Non-Self Leveling (NSL) |
| At Full Height - Bucket Level (B) | 132.07 in. |
| Bucket Weight | 281 kg |
| Digging Depth (H) | 139 mm |
| Bucket Rollback | 2.23 seconds |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 5752 lb. |
