Features
Quick-Change Attachment Carrier
The quick-change attachment carrier allows for fast, easy removal and mounting of attachments without tools.
Optional Skid Steer Attachment Carrier
The skid steer attachment carrier is installed in place of the standard John Deere attachment carrier and allows for the use of skid steer attachments.
Quik-Park™ Loader Mounting
The 440R Loader can be mounted or removed from the tractor without tools, using a parking stand that is part of the loader itself. Once the latches are opened, moving the joystick to the raised position lowers the stand, allowing the loader to shift into park position.
Specifications
Tractor
| Model | 4044R, 4049R, 4052R, 4066R |
| Front Tire | 25x8-16 6PR R1 T1 |
| Rear Tire | 13.8-28 4PR R1 T1 |
| Wheelbase | 1846 mm |
| Wheelbase | 73 in. |
| Pump Capacity | 60.2 L/min |
| Pump Capacity | 15.9 gpm |
| Rated Pressure | 2499 psi |
Loader
| Base Weight | 302 kg |
| Leveling Configuration | Mechanical Self-Leveling (MSL) |
| Bucket Used | Materials - 73 in. |
| Bucket Weight | 146 kg |
| Bucket Weight | 321 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 1006 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 2213 lb. |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 1010 kg |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 2222 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 1263 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 2779 lb. |
| Lift Capacity at 59 in (1500 mm) - Measured at 500 mm Ahead of Pivot | 1201 kg |
| Lift Capacity at 59 in. (1500 mm) - Measured at 500 mm Ahead of Pivot | 2642 lb. |
| Boom Breakout Force - Measured At Pivot (Y) | 1743.7 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 3835 lb. |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 1517 kg |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 3337 lb. |
| At Maximum Height (VV) | 1542 kg |
| At Maximum Height (VV) | 3480 lb. |
| At 59-in. (1500 mm) Lift Height (XX) | 2249 kg |
| At 59-in. (1500 mm) Lift Height (XX) | 4948 lb. |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 2101 kg |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 4622 lb. |
| Maximum Lift Height (A) | 2796 mm |
| Maximum Lift Height (A) | 110 in. |
| At Full Height - Bucket Level (B) | 2590 mm |
| At Full Height - Bucket Level (B) | 102 in. |
| Clearance At Full Height - Bucket Dumped | 2178 mm |
| Clearance At Full Height - Bucket Dumped | 86 in. |
| Overall Length (I+F) | 3540 mm |
| Overall Length (I+F) | 140 in. |
| Overall Height In Carry Position | 1530 mm |
| Overall Height In Carry Position | 60 in. |
| Digging Depth (H) | 122 mm |
| Digging Depth (H) | 5 in. |
| Reach - At Maximum Height (D) | 755 mm |
| Reach - At Maximum Height (D) | 30 in. |
| Reach - At Ground Level - Bucket Level | 1703 mm |
| Reach - At Ground Level - Bucket Level | 67 in. |
| Dump Angle (E) | 46.6 degree (angle) |
| Rollback Angle (G) | 38.4 degree (angle) |
| Dump Angle, Ground | 129.54 degree (angle) |
| Loader Raise | 2.41 seconds |
| Loader Lower | 1.62 seconds |
| Bucket Dump | 2.46 seconds |
| Bucket Rollback | 1.65 seconds |
