John Deere 300R
Double tap to zoom
300R
Front Loaders
Overview:
The 300R Loader highlights its efficiency and performance across various tasks. Equipped with a Quik-Park™ mounting system, it allows for easy removal and attachment without tools. It boasts end-of-pin lubrication for easy maintenance and quick-change attachments for versatility.
- Compatible With 3R Series Tractors
- Quik-Park™ Mounting System for Efficient Attachment and Removal
- Easy Maintenance for Increased Uptime
- 999 lb. (453 kg) Lift Capacity
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Loan Calculator
Use the Loan Calculator to help you determine the financing and payment options that are best for you.
**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Share This Product:
Features
End-of-Pin Lubrication
Grease fittings accessible from the loader’s side make maintenance easier.
Quick-Change Attachment Carrier
The quick-change attachment carrier allows for fast, easy removal and mounting of attachments without tools.
Quik-Park™ Loader Mounting System
This system allows for the quick removal and reattachment of the loader without needing any tools. The integrated parking stand lowers by joystick action, transitioning the loader swiftly to a parked position once unlocked, enhancing operational convenience.
Specifications
Tractor
| Model | 3120, 3320, 3520, 3720, 3033R, 3039R, 3046R |
| Front Tire | 7.00-14 6PR R1 |
| Rear Tire | 11.2-24 6PR R1 |
| Wheelbase | 1727 mm |
| Wheelbase | 68 in. |
| Pump Capacity | 8.6 gpm |
| Rated Pressure | 2500 psi |
Loader
| Base Weight | 257.21 kg |
| Bucket Weight | 93.8 kg |
| Bucket Weight | 207 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 617 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 1360 lb. |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 453 kg |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 999 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 771 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 1700 lb. |
| Lift Capacity at 59 in (1500 mm) - Measured at 500 mm Ahead of Pivot | 595 kg |
| Lift Capacity at 59 in. (1500 mm) - Measured at 500 mm Ahead of Pivot | 1312 lb. |
| Boom Breakout Force - Measured At Pivot (Y) | 1295 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 2855 lb. |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 922 kg |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 2032 lb. |
| At Maximum Height (VV) | 1205 kg |
| At Maximum Height (VV) | 2657 lb. |
| At 59-in. (1500 mm) Lift Height (XX) | 1518 kg |
| At 59-in. (1500 mm) Lift Height (XX) | 3347 lb. |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 1188 kg |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 2619 lb. |
| Maximum Lift Height (A) | 2284 mm |
| Maximum Lift Height (A) | 90 in. |
| At Full Height - Bucket Level (B) | 2123 mm |
| At Full Height - Bucket Level (B) | 83.5 in. |
| Clearance At Full Height - Bucket Dumped | 1743 mm |
| Clearance At Full Height - Bucket Dumped | 69 in. |
| Overall Length (I+F) | 3122 mm |
| Overall Length (I+F) | 123 in. |
| Digging Depth (H) | 76 mm |
| Digging Depth (H) | 2.9 in. |
| Reach - At Maximum Height (D) | 773 mm |
| Reach - At Maximum Height (D) | 30.4 in. |
| Reach - At Ground Level - Bucket Level | 1381 mm |
| Reach - At Ground Level - Bucket Level | 54.4 in. |
| Dump Angle (E) | 43 degree (angle) |
| Rollback Angle (G) | 25 degree (angle) |
| Loader Raise | 2.76 seconds |
| Loader Lower | 1.69 seconds |
| Bucket Dump | 2.91 seconds |
| Bucket Rollback | 1.72 seconds |
