Features
TimberMatic™ Maps and TimberManager™
TimberMatic™ Maps offers a real-time production view, optimized routes, and shared machine connectivity, enhancing jobsite awareness. TimberManager™ allows web-based jobsite monitoring, enabling progress tracking and fleet optimization to streamline communication and boost efficiency.
Far From the Daily Grind
The hydraulically driven, variable-speed reversing fan optimizes cooling by adjusting speed based on conditions, which reduces fuel consumption. It also automatically or manually reverses to clear debris, and its side-by-side cooler design allows for efficient cooling and easy cleaning.
Intelligent Boom Control Smooths Boom Operation
Intelligent Boom Control (IBC) technology ensures smoother, more precise boom operations. This system automates the control of boom directions, greatly reducing operator fatigue while improving effectiveness and accuracy.
Specifications
Hydraulics
| Working Pressure Option 1 | 28 MPa |
| Working Pressure Option 1 | 4061 psi |
| Oil Flow @ 1700 RPM | 669 L/min |
| Working Pressure Option 2 | 35 MPa |
| Working Pressure Option 2 | 5076.3 psi |
| Hydraulic Tank | 302.8 L |
| Hydraulic Tank | 80 gal. |
Cabin
| Type | Rotating and Leveling Cabin |
| Rotating Angle | 220 degrees |
Boom
| Maximum Reach Length Option 1, Head Included | 8.6 m |
| Maximum Reach Length Option 1, Head Included | 28.2 ft |
| Maximum Reach Length Option 2, Head Included | 10 m |
| Maximum Reach Length Option 2, Head Included | 32.8 ft |
| Maximum Reach Length Option 3, Head Included | 11 m |
| Maximum Reach Length Option 3, Head Included | 36.1 ft |
| Gross Lifting Torque | 240 kNm |
| Gross Lifting Torque | 177014.6 lb-ft |
| Slewing Torque | 62 kNm |
| Slewing Torque | 45729 lb-ft |
| Slewing Angle | 220 degrees |
| Forward Tilt Angle | 25 degrees |
| Backward Tilt Angle | 18 degrees |
Electrical
| Number Of Batteries | 2 |
| Battery Capacity Per Each | 174 amp-hr |
Dimensions With 8 Wheels (8W)
| Length | 8.81 m |
| Length | 41.5 ft |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 4.85 m |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 15.9 ft |
| Front Tires | 26.5 in (673 mm) |
| Rear Tires | 26.5 in (673 mm) |
| Transport Height | 4 m |
| Transport Height | 13 ft |
| Ground Clearance - Middle Joint | 0.813 m |
| Ground Clearance - Middle Joint | 28.5 in. |
| Minimum Machine Weight With Harvester Head | 8576.32 kg |
| Minimum Machine Weight With Harvester Head | 63000 lb. |
Transmission With 6-Wheel (6W) Model
| Tractive Force | 210 kN |
| Tractive Force | 47210 lbf |
Engine
| Manufacturer | John Deere |
| Model | JD9 |
| Speed Maximum Power Measured At | 2000 rpm |
| Maximum Power | 220 kW |
| Maximum Power | 295 hp |
| Speed Net Peak Torque Measured At | 1400 rpm |
| Net Peak Torque | 1445 Nm |
| Net Peak Torque | 1065 lb-ft |
| Fuel Tank Capacity | 465.6 L |
| Fuel Tank Capacity | 123 gal. |
| Diesel-Exhaust Fluid (DEF) Tank Total Capacity | 25 L |
| Diesel-Exhaust Fluid (DEF) Tank Total Capacity | 6.6 gal. |
| DEF Tank Usable Capacity | 25 L |
Dimensions With 6 Wheels (6W)
| Length | 8.15 m |
| Length | 26.7 ft |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 4.4 m |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 14.4 ft |
| Front Tire Size - Option 1 | 650 mm |
| Front Tire Size - Option 1 | 26.5 in. |
| Front Tire Size - Option 2 | 723.9 mm |
| Front Tire Size - Option 2 | 28.5 in. |
| Rear Tire Size | 863.6 mm |
| Rear Tire Size | 34 in. |
| Minimum Width With 710-Series Tires | 3000 mm |
| Outer Turning Radius - 710-Series Tires | 7000 mm |
| Transport Height | 4 m |
| Transport Height | 13 ft |
| Transport Length | 12 m |
| Transport Length | 39.4 ft |
| Ground Clearance - Middle Joint | 0.804 m |
| Ground Clearance - Middle Joint | 31.65 in. |
| Minimum Machine Weight With Harvester Head | 24689 kg |
Transmission With 8-Wheel (8W) Model
| Tractive Force | 260 kN |
| Tractive Force | 58450 lbf |
Measuring And Control System
| Type | TimberMatic™ H |
Harvester Heads
| Models | H225E, H425,H425HD, H427, H216, H219, HTH616C Series III |
Steering & Brakes
| Turning Angle | 44 degrees |
