Features
Far From the Daily Grind
The hydraulically driven, variable-speed reversing fan optimizes cooling by adjusting speed based on conditions, which reduces fuel consumption. It also automatically or manually reverses to clear debris, and its side-by-side cooler design allows for efficient cooling and easy cleaning.
TimberMatic™ Maps and TimberManager™
TimberMatic™ Maps offers a real-time production view, optimized routes, and shared machine connectivity, enhancing jobsite awareness. TimberManager™ allows web-based jobsite monitoring, enabling progress tracking and fleet optimization to streamline communication and boost efficiency.
Intelligent Boom Control Smooths Boom Operation
Intelligent Boom Control (IBC) technology ensures smoother, more precise boom operations. This system automates the control of boom directions, greatly reducing operator fatigue while improving effectiveness and accuracy.
Specifications
Hydraulics
| Working Pressure Option 1 | 28 MPa |
| Working Pressure Option 1 | 4061 psi |
| Oil Flow @ 1700 RPM | 669 L/min |
| Working Pressure Option 2 | 35 MPa |
| Working Pressure Option 2 | 5076.3 psi |
| Hydraulic Tank | 302.83 L |
| Hydraulic Tank | 80 gal. |
Cabin
| Type | Rotating and Leveling Cabin |
| Rotating Angle | 220 degrees |
Boom
| Maximum Reach Length Option 1, Head Included | 8.6 m |
| Maximum Reach Length Option 1, Head Included | 28.2 ft |
| Maximum Reach Length Option 2, Head Included | 10 m |
| Maximum Reach Length Option 2, Head Included | 32.8 ft |
| Maximum Reach Length Option 3, Head Included | 11.7 m |
| Maximum Reach Length Option 3, Head Included | 38.4 ft |
| Gross Lifting Torque | 217.06 kNm |
| Gross Lifting Torque | 160050 lb-ft |
| Slewing Torque | 55.02 kNm |
| Slewing Torque | 40566 lb-ft |
| Slewing Angle | 220 degrees |
| Forward Tilt Angle | 28 degrees |
| Backward Tilt Angle | 20 degrees |
Electrical
| Number Of Batteries | 2 |
| Battery Capacity Per Each | 174 amp-hr |
Dimensions With 8 Wheels (8W)
| Length | 8.1 m |
| Length | 26.6 ft |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 4.45 m |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 14.6 ft |
| Front Tires | 26.5 in (673 mm) |
| Rear Tires | 26.5 in (673 mm) |
| Minimum Width With 710-Series Tires | 2750 mm |
| Outer Turning Radius - 710-Series Tires | 7100 mm |
| Transport Height | 3.87 m |
| Transport Height | 12.7 ft |
| Transport Length | 12.2 m |
| Ground Clearance - Middle Joint | 0.687 m |
| Ground Clearance - Middle Joint | 27.0472 in. |
| Minimum Machine Weight With Harvester Head | 26112 kg |
| Minimum Machine Weight With Harvester Head | 57568 lb. |
Transmission With 6-Wheel (6W) Model
| Tractive Force | 190 kN |
| Tractive Force | 42713 lbf |
Engine
| Manufacturer | John Deere |
| Model | JD9 |
| Speed Maximum Power Measured At | 2000 rpm |
| Maximum Power | 220 kW |
| Maximum Power | 295 hp |
| Speed Net Peak Torque Measured At | 1300 rpm |
| Net Peak Torque | 1443.95 Nm |
| Net Peak Torque | 1065 lb-ft |
| Fuel Tank Capacity | 465.61 L |
| Fuel Tank Capacity | 123 gal. |
| Diesel-Exhaust Fluid (DEF) Tank Total Capacity | 25 L |
| Diesel-Exhaust Fluid (DEF) Tank Total Capacity | 6.6 gal. |
| DEF Tank Usable Capacity | 25 L |
Transmission With 8-Wheel (8W) Model
| Tractive Force | 220 kN |
| Tractive Force | 49458 lbf |
Dimensions With 6 Wheels (6W)
| Length | 7.9 m |
| Length | 25.9 ft |
| Front Axle - Middle Joint | 14.6 m |
| Front Axle - Middle Joint | 4.5 ft |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 4.25 m |
| Wheelbase, Front Plus Rear Axle - Middle Joint | 13.9 ft |
| Front Tire Size - Option 1 | 673 mm |
| Front Tire Size - Option 1 | 26.5 in. |
| Front Tire Size - Option 2 | 710 mm |
| Rear Tire Size | 863.6 mm |
| Rear Tire Size | 34 in. |
| Minimum Width With 710-Series Tires | 2750 mm |
| Outer Turning Radius - 710-Series Tires | 6850 mm |
| Transport Height | 3.87 m |
| Transport Height | 12.7 ft |
| Transport Length | 11.9 m |
| Transport Length | 39 ft |
| Ground Clearance - Middle Joint | 0.687 m |
| Ground Clearance - Middle Joint | 27.047 in. |
| Minimum Machine Weight With Harvester Head | 23405 kg |
| Minimum Machine Weight With Harvester Head | 51600 lb. |
Measuring And Control System
| Type | TimberMatic™ H |
Harvester Heads
| Models | H225E, H424, H216, H425, H425HD, H427 |
Steering & Brakes
| Turning Angle | 44 degrees |
