John Deere 2956G

New Products / John Deere / John Deere Products / Forestry Equipment / Swing Machines / 2956G

Double tap to zoom



Features

TimberMatic™ Maps and TimberManager™

A rugged touchscreen monitor displaying a GPS field map with highlighted rows, guidance paths, and machine location

TimberMatic™ Maps offers a real-time production view, optimized routes, and shared machine connectivity, enhancing jobsite awareness. TimberManager™ allows web-based jobsite monitoring, enabling progress tracking and fleet optimization to streamline communication and boost efficiency.

Easy-to-Reach Serviceability

Industrial machine with open access panels revealing the engine compartment, hydraulic components, steps, and service platforms.

The G-Series features easy-to-open doors for quick access to scheduled maintenance areas, and a variable-speed hydraulic reversing fan that helps purge debris from the cooling system. Additionally, it offers excellent access to the hydraulic system on the right-hand side and complete access to the cooling system on the left-hand side for cleaning and inspection.

Undercarriage Structure

Side view of a swing machine's undercarriage, featuring one black track frame

John Deere G-Series Swing Machines feature an "X" lower structure that ensures excellent load distribution and reduces stress on weld joints, while the track frames provide a smooth ride and stability across all terrains. These machines also offer tractive effort for challenging conditions, multiple track pad configurations, two-speed automatic shift travel motors, and optional tri-tracks to minimize track twisting.

Specifications

Operating Dimensions, Live-Heel Log Loader Arm

Maximum Reach at Ground Level11.67 m
Maximum Working Depth3.73 m
Tail Swing Radius3.45 m
Maximum Log-Level Height (Verify Attachment Dependency)9.08 m
Maximum Reach39, 1 ft, in.
Maximum Working Height13.95 m
Minimum Swing Radius4.58 m
Maximum Reach at Ground Level38.3 ft, in.
Maximum Working Depth12, 3 ft, in.
Tail Swing Radius11, 4 ft, in.
Maximum Log-Level Height (Verify Attachment Dependency)29, 9 ft, in.
Conditions for Measuring Operating DimensionsWith standard equipment, 700-mm (28 in.) shoes, 5917-kg (13,045 lb.) counterweight, full fuel tank, and 79-kg (175 lb.) operator
Maximum Reach11.91 m
Maximum Working Height45, 9 ft, in.
Minimum Swing Radius15, 0 ft, in.

Operating Weights, Processor

Side-Entry Cab, Optional Component, Add Weight-1480 lb.
Side-Entry Cab, Optional Component, Add Weight-671 kg
SAE Operating Weight, EPA FT4/EU Stage IV85894 lb.
2.92-m Undercarriage678 kg
9-ft, 7-in. Undercarriage1778 lb.
SAE Operating Weight, EPA FT4/EU Stage IV38961 kg
Rear-Entry Cab - Cab Forward, Optional Component, Add Weight150 lb.
Rear-Entry Cab - Cab Forward, Optional Component, Add Weight68 kg
Conditions for Measuring Operating WeightsWith full fuel tank, 79-kg (175 lb.) operator, 60-in. riser, rear-entry forestry cab, 5917-kg (13,045 lb.) counterweight, 700-mm (28 in.) double-grouser shoes, and 2.69-m (8 ft. 10 in.) undercarriage; no attachment included

Operating Dimensions, VIH Log Loader Arm

Maximum Reach at Ground Level10.5 m
Maximum Working Depth2.6 m
Tail Swing Radius3.45 m
Maximum Log-Level Height (Verify Attachment Dependency)8.88 m
Maximum Reach35, 9 ft, in.
Maximum Working Height13.07 m
Minimum Swing Radius3.84 m
Maximum Reach at Ground Level34, 5 ft, in.
Maximum Working Depth8, 6 ft, in.
Tail Swing Radius11, 4 ft, in.
Maximum Log-Level Height (Verify Attachment Dependency)29, 2 ft, in.
Conditions for Measuring Operating DimensionsWith standard equipment, 700-mm (28 in.) shoes, 5917-kg (13,045 lb.) counterweight, full fuel tank, and 79-kg (175 lb.) operator
Maximum Reach10.9 m
Minimum Swing Radius12, 7 ft, in.
Maximum Working Height42, 11 ft, in.

Serviceability

Engine Crankcase (Including Filter) Capacity20.5 L
Hydraulic Tank Oil Capacity52 gal.
Hydraulic Tank Oil Capacity195 L
Engine Crankcase (Including Filter) Capacity5.4 qt
Fuel Tank Capacity800 L
Fuel Tank Capacity211 gal.
Cooling System Capacity9.5 gal.
Cooling System Capacity36 L
Diesel-Exhaust Fluid (DEF) Tank (FT4) Capacity11.2 gal.
Diesel-Exhaust Fluid (DEF) Tank (FT4) Capacity42.4 L

Operating Dimensions, Processor Arm

Maximum Reach at Ground Level10.72 m
Maximum Working Depth2.8 m
Tail Swing Radius3.45 m
Maximum Log-Level Height (Verify Attachment Dependency)10 m
Maximum Reach36, 3 ft, in.
Maximum Working Height13.22 m
Minimum Swing Radius3.68 m
Maximum Reach at Ground Level35, 2 ft, in.
Maximum Working Depth9, 2 ft, in.
Tail Swing Radius11, 4 ft, in.
Maximum Log-Level Height (Verify Attachment Dependency)32, 10 ft, in.
Conditions for Measuring Operating DimensionsWith standard equipment, 700-mm (28 in.) shoes, 5917-kg (13,045 lb.) counterweight, full fuel tank, and 79-kg (175 lb.) operator
Maximum Reach11.05 m
Minimum Swing Radius12, 1 ft, in.
Maximum Working Height43, 4 ft, in.

Ground Pressure, VIH Log Loader

Standard Undercarriage Gauge9, 7 ft, in.
Standard Undercarriage Gauge2.92 m
Ground Pressure With 700-mm Double-Grouser Shoes and Option One Gauge and Standard-Duty Undercarriage67.1 kPa
Ground Pressure With 28-in. Double-Grouser Shoes and Option One Gauge and Standard-Duty Undercarriage9.73 psi

Operating Weights, VIH Log Loader

Side-Entry Cab, Optional Component, Add Weight-1480 lb.
Side-Entry Cab, Optional Component, Add Weight-671 kg
SAE Operating Weight, EPA FT4/EU Stage IV38184 kg
SAE Operating Weight, EPA FT4/EU Stage IV84181 lb.
Rear-Entry Cab - Cab Forward, Optional Component, Add Weight150 lb.
Rear-Entry Cab - Cab Forward, Optional Component, Add Weight68 kg
Conditions for Measuring Operating WeightsWith full fuel tank, 79-kg (175 lb.) operator, 60-in. riser, rear-entry forestry cab, 5917-kg (13,045 lb.) counterweight, 700-mm (28 in.) double-grouser shoes, and 2.69-m (8 ft. 10 in.) undercarriage; no attachment included

Final Tier 4/EU Stage V Engine

Off-Level Capacity70 %
Engine Speed Used for Net Rated Power1900 rpm
Non-Road Emission StandardsEPA Final Tier 4 (FT4)/EU Stage IV
Engine Displacement6.8 L
Engine Displacement415 cu in.
AspirationTurbocharged, air-to-air charge-air cooler
Oil Filter, Remote MountedFull-flow spin-on filter
Off-Level Capacity35 degree (angle)
Net Rated Power at Engine Speed223 hp
Cylinders6
Net Rated Power at Engine Speed166 kW
ManufacturerJohn Deere PowerTech™ PSS 6.8 L

Operating Weights, Live-Heel Log Loader Arm

Side-Entry Cab, Optional Component, Add Weight-1480 lb.
Side-Entry Cab, Optional Component, Add Weight-671 kg
SAE Operating Weight, EPA FT4/EU Stage IV85989 lb.
SAE Operating Weight, EPA FT4/EU Stage IV39004 kg
Rear-Entry Cab - Cab Forward, Optional Component, Add Weight68 kg
Rear-Entry Cab - Cab Forward, Optional Component, Add Weight150 lb.
Conditions for Measuring Operating WeightsWith full fuel tank, 79-kg (175 lb.) operator, 60-in. riser, rear-entry forestry cab, 5917-kg (13,045 lb.) counterweight, 700-mm (28 in.) double-grouser shoes, and 2.69-m (8 ft. 10 in.) undercarriage; no attachment included

Final Tier 4/EU Stage V Electrical

Standard Service Lights With Side-Entry Cab5 LEDs (compartments)
Standard Access Lights1 LED (right rear cab)
Standard Work Lights14 LEDs
Alternator Rating150 amp
Standard Service Lights With Rear-Entry Cab6 LEDs (compartments and riser)
System Voltage24 V

Ground Pressure, Processor

Ground Pressure With 28-in. Double-Grouser Shoes and Option Two Gauge and Standard-Duty Undercarriage9.92 psi
Ground Pressure With 700-mm Double-Grouser Shoes and Option Two Gauge and Standard-Duty Undercarriage68.4 kPa
Ground Pressure With 28-in. Double-Grouser Shoes and Option One Gauge and Standard-Duty Undercarriage9.75 psi
Ground Pressure With 700-mm Double-Grouser Shoes and Option One Gauge and Standard-Duty Undercarriage67.2 kPa
Option One - Standard-Duty Undercarriage Gauge8, 10 ft, in.
Option One - Standard-Duty Undercarriage Gauge2.69 m
Option Two - Standard-Duty Undercarriage Gauge9, 7 ft, in.
Option Two - Standard-Duty Undercarriage Gauge2.92 m

Hydraulics

ControlsPilot levers; short-stroke, low-effort hydraulic pilot with shutoff lever
Main Pumps Type2 variable-displacement pumps
Main Pumps Maximum Rated Flow, Per 2 Pumps65.5 gpm
Main Pumps Maximum Rated Flow, Per 2 Pumps248 L/min
TypeOpen center, pilot operated
Power Boost System Operating Pressure38000 kPa
Power Boost System Operating Pressure5511 psi
Implement Circuits System Operating Pressure4975 psi
Implement Circuits System Operating Pressure34300 kPa

Powertrain

Drawbar Pull30350 kgf
Drawbar Pull66910 lbf
Maximum Travel Speed High2.4 mph
Maximum Travel Speed High3.9 km/h
Maximum Travel Speed Low1.6 mph
Type2-speed propel with automatic shift
Maximum Travel Speed Low2.5 km/h

Undercarriage, Standard

Pitch With Standard-Duty Undercarriage8.5 in.
Pitch With Standard-Duty Undercarriage216 mm
Track Rollers Per Side9
Carrier Rollers Per Side2
Shoes, Double Grousers, Per Side48

Ground Pressure, Live-Heel Log Loader

Standard Undercarriage Gauge9, 7 ft, in.
Standard Undercarriage Gauge2.92 m
Ground Pressure With 28-in. Double-Grouser Shoes and Option One Gauge and Standard-Duty Undercarriage9.93 psi
Ground Pressure With 700-mm Double-Grouser Shoes and Option One Gauge and Standard-Duty Undercarriage68.5 kPa

Swing Mechanism

Swing Speed8.7 rpm
Swing Torque120000 Nm
Swing Torque88507 lb-ft

Operator Station

Operator Height From Ground (Eye Level) in Rear-Entry Log Loader Cab4441 mm
Operator Height From Ground (Eye Level) in Rear-Entry Log Loader Cab14, 7 ft, in.
Operator Height From Ground (Eye Level) in Side-Entry Forestry Cab3095 mm
Operator Height From Ground (Eye Level) in Side-Entry Forestry Cab10, 2 ft, in.

Cooling

Fan DriveCool-on-demand hydraulic-driven, suction-type fan with remote-mounted drive with standard reversing fan
